F-208
BCS–108–L–D–HE
BCS–110–L–S–DE
BCS–110–L–S–HE
BCS–112–L–D–TE
BCS–112–L–D–PE
BOX CONNECTOR STRIPS
SPECIFICATIONS
For complete specifications
see www.samtec.com?BCS
Insulator Material:
Black Liquid
Crystal Polymer
Contact Material:
Phosphor Bronze
Plating:
Au or Sn over
50µ" (1,27µm) Ni
Current Rating:
3A @ 80°C ambient
(-TE/-DE/-PE mated with
TSM)
4A @ 80°C ambient
(-HE mated with TSW-D)
Voltage Rating:
475 VAC (-TE/-DE/-PE
mated with TSM)
450 VAC (-HE mated
with TSW)
Operating Temp Range:
-55°C to +125°C
Contact Resistance:
10 mΩ max
Insertion Depth:
(4,34mm) .171" to
(7,24mm) .285" from top,
(5,64mm) .222" plus board
thickness minimum
from bottom. –HE is
(4,34mm) .171" to
(6,35mm) .250"
Insertion Force:
(Single contact only) 5oz
(1,39N) avg. (.025"
(0,64mm) SQ pin)
Withdrawal Force:
(Single contact only) 3oz
(0,83N) avg. (.025"
(0,64mm) SQ pin)
RoHS Compliant:
Yes
BCS
SERIES
OTHER
OPTION
BCS
1
NO. PINS
PER ROW
PLATING
OPTION
ROW
OPTION
ENTRY
OPTION
Mates with:
TSW, MTSW, TSS,
ZSS, DW, EW, ZW,
HW, TSM, MTLW
–L
= 10µ" (0,25µm)
Gold on contact,
Matte Tin on tail
–S
= Single
–“XX”
= Polarized
Position
(–BE not
available)
–D
= Double
TSW
BCS
01 thru 50
–TE
= Top
Entry
(2,54)
.100
02
SSW
01
02
(2,54)
.100
(2,54) .100 x No. of Spaces
(0,25)
.010
(3,05)
.120
(5,08)
.200
(0,89) .035 SQ TYP
(2,54) .100 x No. of Positions
01
(2,54)
.100
–DE
(0,25)
.010
(1,78)
.070
(4,32)
.170
(3,05)
.120
= Top Entry
(For Bottom
Entry specify
–DE–BE)
Cannot be
used with plated
through-holes
(7,37)
.290
Processing:
Max Processing Temp:
230°C for 60 seconds, or
260°C for 20 seconds 3x
Lead–Free Solderable:
Yes
(0,48)
.019
(2,54)
.100
(0,51)
.020
–PE
= Pass
Through
Entry
(For Bottom
Entry specify
–PE–BE)
(0,89)
.035 SQ TYP
(8,13)
.320
(3,18)
.125
(0,25)
.010
APPLICATIONS
BCS
TSW
(2,79)
.110
–HE
= Horizontal
Entry
(3,18)
.125
(5,33)
.210
(5,72)
.225
HORIZONTAL
Note:
Some lengths, styles
and options are non-standard,
non-returnable.
(2,54)
.100
(0,51)
.020
(7,87)
.310
WWW.SAMTEC.COM
