2.5mm pitch/Disconnectable Crimp style connectors
XNI
CONNECTOR
Specifications
–––––––––––––––––––
• Current rating: 3A AC, DC (AWG#22)
• Voltage rating: 250V AC, DC
• Temperature range: -25˚C to +85˚C
(including temperature rise in applying
electrical current)
• Contact resistance: Initial value/10mΩ max.
After environmental testing/20mΩ max.
• Insulation resistance: 1,000MΩ min.
• Withstanding voltage: 1,000V AC/minute
• Applicable wire: AWG #30 to #22
* Compliant with RoHS.
* Refer to "General Instruction and Notice when using
Terminals and Connectors" at the end of this catalog.
* Contact JST for details.
This connector is 2.5mm pitch wire-to-board
connector that has a mechanism to prevent
an incomplete mating by utilizing the inertial
force when mating connector.
In all circuits of connector, controlled key for
preventing mismatching of mating is added,
and two type connectors can be used in the
same model. (See table below.)
• Inertial lock structure
• Finger-friendly design
• Secure locking structure
Standards
––––––––––––––––––––––
1
Certified LR20812
2
J50148340
(7.95)
0
Recognized E 60389
PC board layout (viewed from component side) and Assembly layout
List of combinations
Resin color
(Header/Housing)
Key pattern
Natural
Polarizing key pattern A
Red
Polarizing key pattern B
A
2.5
2.6
±
0.05
±
0.05
±
0.05
1.7
±
0.05
φ0.9
φ1.3
+
0.1
0
+
0.1
0
Note: 1. Tolerances are non-cumulative:
±
0.05mm for all centers.
2. Hole dimensions differ according to the kind of PC board and
piercing method.
The dimensions above should serve as a guideline.
Contact JST for details.
(12.6)
Housing Model No.
Header Model No.
XNIRP-( )V-A-S
B( )B-XNI S K-A-1
XNIRP-( )V-B-R
B( )B-XNI R K-B-2
Contact
Model No.
SXNI-001T-P0.6
SXNI-003T-P0.6
8.4
2.9
2
1.6
Applicable wire
AWG#
mm
2
0.13
∼
0.33
0.05
∼
0.08
26
∼
22
30
∼
28
Insulation O.D.
(mm)
1.0
∼
1.7
0.65
∼
0.9
Q’ty /
reel
7,000
10,000
Material and Finish
Phosphor bronze, tin-plated (reflow treatment)
RoHS compliance
1.7
Contact
SXNI-001T-P0.6
SXNI-003T-P0.6
Crimping
machine Crimp applicator
AP-K2N
AP-K2N
MKS-L
–
MKS-L
–
Applicator
Dies
MK/SXNI-001-06
–
MK/SXNI-003-06
–
Crimp applicator with dies
APLMK SXNI001-06
–
APLMK SXNI003-06
–
1
XNI CONNECTOR
Housing
(2, 3 circuits)
B
A
2.5
Circuits
7.75
Model No.
XNIRP-02V-A-S
XNIRP-03V-A-S
XNIRP-04V-A-S
XNIRP-05V-A-S
XNIRP-06V-A-S
XNIRP-07V-A-S
XNIRP-08V-A-S
XNIRP-09V-A-S
XNIRP-10V-A-S
XNIRP-11V-A-S
XNIRP-15V-A-S
Dimensions (mm)
A
B
2.5
5.0
7.5
10.0
12.5
15.0
17.5
20.0
22.5
25.0
35.0
7.5
10.0
12.5
15.0
17.5
20.0
22.5
25.0
27.5
30.0
40.0
Q’ty /
bag
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
500
500
2
3
10.1
4
5
6
(4 to 11 circuits)
7
B
A
2.5
7.75
8
9
10
10.1
11
15
Material
(15 circuits)
B
A
2.5
7.75
Glass-filled PBT, UL94V-0, natural (white)
RoHS compliance
<For reference> As the color identification,
the following alphabet shall be put in the underlined part.
For availability, delivery and minimum order quantity, contact JST.
ex.
XNIRP-02V-A-S
S...natural (white)
R...red
Shrouded header
Circuits
Model No.
B02B-XNISK-A-1
B03B-XNISK-A-1
B04B-XNISK-A-1
B05B-XNISK-A-1
B06B-XNISK-A-1
B07B-XNISK-A-1
B08B-XNISK-A-1
B09B-XNISK-A-1
B10B-XNISK-A-1
B11B-XNISK-A-1
B15B-XNISK-A-1
10.1
(2 to 11 circuits)
B
A
2.5
6.8
Dimensions (mm)
A
B
2.5
5.0
7.5
10.0
12.5
15.0
17.5
20.0
22.5
25.0
35.0
7.5
10.0
12.5
15.0
17.5
20.0
22.5
25.0
27.5
30.0
40.0
Q’ty /
box
500
500
250
250
250
200
200
200
150
150
100
2
3
4
5
10.6
6
7
8
3.4
9
2.6
1.7
(15 circuits)
10
11
6.8
B
A
2.5
15
Material and Finish
Post: Copper alloy, copper-undercoated, tin-plated (reflow treatment)
Wafer: Glass-filled PA 66, UL94V-0, natural (ivory)
10.6
RoHS compliance
3.4
1.7
2.6
This product displays (LF)(SN) on a label.
<For reference> As the color identification,
the following alphabet shall be put in the underlined part.
For availability, delivery and minimum order quantity, contact JST.
ex.
B02B-XNISK-A-1
R...red
S...natural (ivory)
