圧
接
ZF
/
ZFW
CONNECTOR
1.5mm pitch/Disconnectable Insulation displacement connectors
Specifications –––––––––––––––––––
• Current rating: 0.7A AC, DC (AWG#28)
• Voltage rating: 50V AC, DC
• Temperature range:
-
25˚C to
+
85˚C
(including temperature rise in applying
electrical current)
• Contact resistance: Initial value/20m
Ω
max.
After environmental testing/40m
Ω
max.
• Insulation resistance: 500M
Ω
min.
• Withstanding voltage: 500V AC/minute
• Applicable wire: Conductor size/UL10272 AWG#28
Insulation O.D./0.78mm
• Applicable PC board thickness: 1.6mm
* Compliant with RoHS.
* Refer to "General Instruction and Notice when using
Terminals and Connectors" at the end of this catalog.
* Contact JST for details.
This is a 1.5mm pitch secure lock type
board-to-wire/insulation displacement
connector for the first time in the industry,
having the bearing force to unusual
external force.
• Twin U-slot insulation displacement section
• Superior operability (Low insertion force)
• Strain relief
• Secure locking structure
PC board layout (viewed from component side) and Assembly layout
Top entry type
(6.6)
Connector outline
A
±0.05
(2.1)
1.5
±0.05
1.3
±0.05
±0.05
Double-row type
(14.1)
A
1.5
±0.05
±0.05
(3)
Connector outline
Circuit No.1
(15.1)
2
±0.05
(4.4)
(2.25)
(B)
φ0.7
＋0.1
0
φ1.4
＋0.1
0
1.5
±0.05
(B)
Side entry type
〈2
to 5 circuits〉
(B)
2
±0.05
2
±0.05
(2.25)
Circuit No.1
φ0.7
＋0.1
0
〈6
to 20 circuits〉
(B)
(2.25)
Circuit No.1
(17.8)
φ0.7
＋0.1
0
1.5
±0.05
11.2
±0.05
A
(15.9)
±0.05
1.5
±0.05
(13.2)
11.2
±0.05
A
±0.05
0.75
±0.05
φ0.9
＋0.1
0
(15.9)
(13.2)
φ0.9
＋0.1
0
Connector outline
Connector outline
Note: 1. Tolerances are non-cumulative:
±
0.05mm for all centers.
2. Hole dimensions differ according to the kind of PC board and piercing method.
The dimensions above should serve as a guideline. Contact JST for details.
1
(7.2)
1.5
±0.05
φ0.6
＋0.1
0
(15.7)
5.6
Line A/
Circuit No.1
Line B/
Circuit No.1
φ1.4
＋0.1
0
ZF/ZFW CONNECTOR
Socket
Circuits
B
6.2
Model No.
02ZF-6S-P
03ZF-6S-P
04ZF-6S-P
05ZF-6S-P
06ZF-6S-P
07ZF-6S-P
08ZF-6S-P
09ZF-6S-P
10ZF-6S-P
11ZF-6S-P
12ZF-6S-P
13ZF-6S-P
14ZF-6S-P
15ZF-6S-P
16ZF-6S-P
17ZF-6S-P
18ZF-6S-P
19ZF-6S-P
20ZF-6S-P
Dimensions (mm)
A
B
−
3.0
4.5
6.0
7.5
9.0
10.5
12.0
13.5
15.0
16.5
18.0
19.5
21.0
22.5
24.0
25.5
27.0
28.5
4.5
6.0
7.5
9.0
10.5
12.0
13.5
15.0
16.5
18.0
19.5
21.0
22.5
24.0
25.5
27.0
28.5
30.0
31.5
Q’ty /
box
1,000
1,000
500
500
500
500
500
500
500
250
250
250
250
250
250
250
250
200
200
2
3
4
5
13.1
6
7
8
9
1.5
A
Circuit No.1
10
11
12
13
14
15
16
17
18
19
20
Material and Finish
Contact: Copper alloy, copper-undercoated, tin-plated (reflow treatment)
Housing: Glass-filled PA 66, UL94V-0, natural (ivory)
RoHS compliance
ZF connector shrouded header
Top entry type
B
Circuits
Circuit No.1
mark
6.4
2
3
4
5
6
7
8
9
3.1
10
1.2
□
0.4
1.5
A
11
12
2
1.3
13
14
15
16
17
18
19
20
Side entry type
〈2
to 5 circuits〉
Circuit No.1
B
15.9
Model No.
Side entry type
Top entry type
B02B-ZFSS-1
S02B-ZFSS-2
B03B-ZFSS-1
S03B-ZFSS-2
B04B-ZFSS-1
S04B-ZFSS-2
B05B-ZFSS-1
S05B-ZFSS-2
B06B-ZFSS-1
S06B-ZFSS-2
B07B-ZFSS-1
S07B-ZFSS-2
B08B-ZFSS-1
S08B-ZFSS-2
B09B-ZFSS-1
S09B-ZFSS-2
B10B-ZFSS-1
S10B-ZFSS-2
B11B-ZFSS-1
S11B-ZFSS-2
B12B-ZFSS-1
S12B-ZFSS-2
B13B-ZFSS-1
S13B-ZFSS-2
B14B-ZFSS-1
S14B-ZFSS-2
B15B-ZFSS-1
S15B-ZFSS-2
B16B-ZFSS-1
S16B-ZFSS-2
B17B-ZFSS-1
S17B-ZFSS-2
B18B-ZFSS-1
S18B-ZFSS-2
B19B-ZFSS-1
S19B-ZFSS-2
B20B-ZFSS-1
S20B-ZFSS-2
Dimensions (mm)
Q’ty / box
A
B
Top entry type Side entry type
−
3.0
4.5
6.0
7.5
9.0
10.5
12.0
13.5
15.0
16.5
18.0
19.5
21.0
22.5
24.0
25.5
27.0
28.5
6.0
7.5
9.0
10.5
12.0
13.5
15.0
16.5
18.0
19.5
21.0
22.5
24.0
25.5
27.0
28.5
30.0
31.5
33.0
8,400
6,720
5,544
4,704
4,200
3,696
3,360
3,024
2,688
2,520
2,352
2,184
2,016
1,848
1,848
1,680
1,680
1,512
1,512
4,800
3,840
3,168
2,688
2,400
2,112
1,920
1,728
1,536
1,440
1,344
1,248
1,152
1,056
1,056
960
960
864
864
7
13
Material and Finish
Post: Copper alloy, copper-undercoated, tin-plated (reflow treatment)
Wafer: Glass-filled PA 66, UL94V-0, natural (ivory)
Reinforcement: Copper alloy, tin-plated (reflow treatment)
2
3
□
0.4
1.5
A
11.2
13.2
RoHS compliance
This product displays (LF)(SN) on a label.
<For reference>
As the color identification,
the following alphabet shall be put in the underlined part.
For availability, delivery and minimum order quantity, contact JST.
ex.
B02B-ZFSS-1
S…natural (ivory) K…black R…red E…blue MG…moss green
〈6
to 20 circuits〉
Circuit No.1
B
15.9
3
7
□
0.4
1.5
A
11.2
13.2
2
2
ZF/ZFW CONNECTOR
ZFW connector Double-row shrouded header
Line A/Circuit No.1
Circuits
18
22
26
Line B/Circuit No.1
Model No.
B18B-ZFWKS-1
B22B-ZFWKS-1
B26B-ZFWKS-1
B30B-ZFWKS-1
B34B-ZFWKS-1
B38B-ZFWKS-1
B40B-ZFWKS-1
Dimensions (mm)
A
B
12.0
15.0
18.0
21.0
24.0
27.0
28.5
18.0
21.0
24.0
27.0
30.0
33.0
34.5
Q’ty /
box
1,008
882
756
693
630
567
504
30
34
38
40
B
14.1
14.3
Material and Finish
1.2
Post: Copper alloy, copper-undercoated, tin-plated (reflow treatment)
Wafer: Glass-filled PA 66, UL94V-0, black
2.7
RoHS compliance
This product displays (LF)(SN) on a label.
□
0.4
1.5
A
1.5
1.5
5.6
ZFW connector holder
Circuits
18
A
H JST
B
Model No.
ZFWH-18-K
ZFWH-22-K
ZFWH-26-K
ZFWH-30-K
ZFWH-34-K
ZFWH-38-K
ZFWH-40-K
Dimensions (mm)
A
B
12.0
15.0
18.0
21.0
24.0
27.0
28.5
18.0
21.0
24.0
27.0
30.0
33.0
34.5
Q’ty /
bag
300
300
250
150
150
100
100
22
Line B/
Circuit No.1 mark
26
30
34
38
40
Line A/
Circuit No.1 mark
B
14
14.1
Material
PBT, UL94V-0, black
1.5
A
5.6
RoHS compliance
3
