SHLD
CONNECTOR
Emboss Tape
1.0mm pitch/Disconnectable Crimp style connectors
Specifications –––––––––––––––––––
Developed for PDP, LCD or small
electronics equipment.
This is a dual-row small crimp type
connector with a secure locking system or
without-designed for different applications.
The PC board layout is compatible with
that of existing SHD connector, which
allows for replacement of the above
existing connector.
• Secure housing lock structure (for locking type)
• Prevent deformation of contacts
• A contact lock structure
• Strong structure against external force
• Current rating: 1.0A AC, DC (AWG #28)
• Voltage rating: 50V AC, DC
• Temperature range:
-
25˚C to
+
85˚C
(including temperature rise in applying
electrical current)
• Contact resistance: Initial value/30m
Ω
max.
After environmental testing/40m
Ω
max.
• Insulation resistance:
100M
Ω
min.
• Withstanding voltage: 500V AC/minute
* Compliant with RoHS.
* Refer to "General Instruction and Notice when using
Terminals and Connectors" at the end of this catalog.
* Contact JST for details.
Standards ––––––––––––––––––––––
0
Recognized E60389
PC board layout (viewed from component side) and Assembly layout
Top entry type
1
±0.1
0.6 0.9
±0.1
0.85
±0.1
6.6
(5.8)
5.4
4.6
Side entry type
1
±0.1
1.6
0.6
（9.05）
6.7
Circuit No.1
Connector outline
1.8
±0.1
5.4
1.8
±0.1
4
4.1
（6.15）
7.2
(7.3)
4.2
1.6
Circuit No.1
0.85
±0.1
1.25
±0.1
Note: 1. Tolerances are non-cumulative:
±
0.1mm for all centers.
2. The dimensions above should serve as a guideline. Contact JST for details.
Contact
Model No.
4.75
2.0
0.5
0.8
2.35
0.8
0.4
Applicable wire
mm
2
AWG#
32∼28
0.9
Insulation O.D. (mm)
0.4∼0.8
5.6
0.5
Q'ty / reel
30,000
SSHL-003GA1-P0.2
0.032∼0.08
Material and Finish
Phosphor bronze, nickel-undercoated, Mating part; gold-plated, Crimping part; gold-plated
RoHS compliance
Applicator
Dies
Crimp applicator with dies
MK/SSH/L-003-02 APLMK SSH/L003-02
SC/SSH/L-003-02 APLSC SSH/L003-02
Contact
Crimping
machine Crimp applicator
MKS-L-10-3
*MKS-SC
SSHL-003GA1-P0.2
AP-K2N
Note: *Strip-crimp applicator
Contact JST for applicable wires in case that it is not usable due to wire size.
1
SHLD CONNECTOR
Housing
Circuits
B
A
1.0
2.6
Model No.
SHLDP-20V-S(B)
SHLDP-30V-S(B)
SHLDP-40V-S(B)
SHLDP-50V-S(B)
A
9.0
14.0
19.0
24.0
Dimensions (mm)
B
C
11.4
16.4
21.4
26.4
13.0
18.0
23.0
28.0
Q'ty / bag
3,500
2,500
2,000
1,500
20
30
40
5.7
50
N-1
Circuit No.1 mark
C
Polarity rib
4.6
5.4
Material
PBT, UL94V-0, natural (white)
RoHS compliance
With secure lock type
B
A
1.0
2.6
With secure lock type
Circuits
20
30
40
50
5.7
6.0
Model No.
SHLDP-20V-S-1(B)
SHLDP-30V-S-1(B)
SHLDP-40V-S-1(B)
SHLDP-50V-S-1(B)
A
9.0
14.0
19.0
24.0
Dimensions (mm)
B
C
14.7
19.7
24.7
29.7
15.7
20.7
25.7
30.7
Q'ty / bag
3,000
2,000
1,500
1,200
Material
PBT, UL94V-0, natural (white)
N-1
Circuit No.1 mark
C
Polarity rib
4.6
5.4
RoHS compliance
Shrouded header
Top entry type
Circuits
20
30
4.05
40
50
Model No.
Dimensions (mm)
Q'ty / reel
Top entry type
Side entry type
A
B
BM20B-SHLDS-G-TFT SM20B-SHLDS-G-TF
1,000
9.0
13.0
BM30B-SHLDS-G-TFT SM30B-SHLDS-G-TF
14.0
1,000
18.0
BM40B-SHLDS-G-TFT SM40B-SHLDS-G-TF
19.0
1,000
23.0
BM50B-SHLDS-G-TFT SM50B-SHLDS-G-TF
24.0
28.0
1,000
Material and Finish
Contact: Phosphor bronze, nickel-undercoated, gold-plated
Wafer: PA, UL94V-0, natural (ivory)
Solder tab: Brass, copper-undercoated, tin-plated (reflow treatment)
0.2
1.0
A
B
1.5
5.0
0.8
RoHS compliance
This product displays (LF)(SN) on a label.
Side entry type
Circuit No.1
0.2
A
B
1.0
1.45
0.75
1.5
5.4
5.45
0.55
2
