PH
CONNECTOR
1
2
3
4
5
6
7
8
9
High box type
2.0mm pitch/Disconnectable Crimp style connectors
Specifications –––––––––––––––––––
• Current rating: 2A AC, DC (AWG #24)
• Voltage rating: 100V AC, DC
• Temperature range: -25˚C to +85˚C
(including temperature rise in applying
electrical current)
• Contact resistance: Initial value/ 10m
Ω
max.
After environmental testing/ 20m
Ω
max.
• Insulation resistance: 1,000M
Ω
min.
• Withstanding voltage: 800V AC/minute
• Applicable wire: AWG #30 to #24
• Applicable PC board thickness: 0.8 to 1.6mm
* Compliant with RoHS.
* Refer to "General Instruction and Notice when using
Terminals and Connectors" at the end of this catalog.
* Contact JST for details.
PH connector high box type, with 17.0mm
mounting height and with 4.5mm
thickness.
• Interchangeability
Standards ––––––––––––––––––––––
1
Certified LR20812
2
R75087
4.5
0
Recognized E60389
±0.05
2
＋0.1
0
φ0.8
＋0.1
φ1
0
17
±0.05
1.4
Note: 1. The above figure is the figure viewed from the connector mounting side.
2. Tolerances are non-cumulative:
±
0.05mm for all centers.
3. Hole dimensions differ according to the kind of PC board and piercing method. If PC boards made of hard material are used, the hole dimensions should
be larger. The hole dimensions shown above are reference values. Contact JST for details.
Contact
Model No.
SPH-002T-P0.5S
5.7
2.85
2.05
1
1.5
±0.05
15
Applicable wire
AWG #
mm
2
0.05∼0.22
30∼24
Insulation O.D.
(mm)
0.9∼1.5
Q'ty /
reel
8,000
Material and Finish
Phosphor bronze, tin-plated (reflow treatment)
RoHS compliance
2.08
Contact
1.5
Crimping
machine Crimp applicator
MKS-L
*MKS-SC
Applicator
Dies
Crimp applicator with dies
SPH-002T-P0.5S
AP-K2N
MK/SPH-002-05S APLMK SPH002-05S
SC/SPH-002-05S APLSC SPH002-05S
Note: *Strip-crimp applicator
1
PH CONNECTOR High box type
Housing
Circuits
2
3
4
5
6
7
8
B
1.9
2
A
0.5
4.5
Model No.
PHR-2
PHR-3
PHR-4
PHR-5
PHR-6
PHR-7
PHR-8
PHR-9
PHR-10
PHR-11
PHR-12
PHR-13
Dimensions (mm)
A
B
2.0
4.0
6.0
8.0
10.0
12.0
14.0
16.0
18.0
20.0
22.0
24.0
5.8
7.8
9.8
11.8
13.8
15.8
17.8
19.8
21.8
23.8
25.8
27.8
Q'ty /
box
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
9
10
11
12
13
6.35
Material
PA 66, UL94V-0, natural (white)
0.6
RoHS compliance
<For reference>
As the color identification,
the following alphabet shall be put in the underlined part.
For availability, delivery and minimum order quantity, contact JST.
ex.
PHR-2-oo-
(blank)…natural (white)
BK…black R…red TR…tomato red BL…blue Y…yellow
L…lemon yellow M…green D…orange N…brown P…purple
PK…pink H…gray LE…light blue FY…vivid yellow
Shrouded header
Circuits
2
3
4
5
1
1.3
2
A
0.5
1.7
4.5
Model No.
BH2B-PH
BH3B-PH
BH4B-PH
BH5B-PH
BH6B-PH
BH7B-PH
BH8B-PH
BH9B-PH
BH10B-PH
BH11B-PH
BH12B-PH
BH13B-PH
Dimensions (mm)
A
2.0
4.0
6.0
8.0
10.0
12.0
14.0
16.0
18.0
20.0
22.0
24.0
B
5.9
7.9
9.9
11.9
13.9
15.9
17.9
19.9
21.9
23.9
25.9
27.9
Q'ty /
box
800
480
400
390
300
240
240
200
200
150
150
100
6
7
8
9
10
11
12
13
15
Material and Finish
Post: Copper alloy, copper-undercoated, tin-plated (reflow treatment)
Wafer: PA 66, UL94V-0, natural (white)
RoHS compliance
This product displays (LF)(SN) on a label.
<For reference>
As the color identification,
the following alphabet shall be put in the underlined part.
For availability, delivery and minimum order quantity, contact JST.
ex.
BH2B-PH-oo-
(blank)…natural (white)
K…black R…red E…blue Y…yellow M…green N…brown
1.5
(3.6)
1.5
6
φ0.8
1.95
B
1.4
2
