CMF160ATR13 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> diode> CMF160ATR13

CMF160ATR13: DescriptionTrans Voltage Suppressor Diode, 160V V(RWM), Unidirectional,; CategoryDiscrete semiconductor diode; File Size739KB，3 Pages; ManufacturerCentral Semiconductor

Download Datasheet Parametric View All

CMF160ATR13 Overview

Trans Voltage Suppressor Diode, 160V V(RWM), Unidirectional,

CMF160ATR13 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Reach Compliance Code	not_compliant
ECCN code	EAR99
Breakdown voltage nominal value	187.5 V
Maximum clamping voltage	259 V
Diode type	TRANS VOLTAGE SUPPRESSOR DIODE
JESD-609 code	e0
polarity	UNIDIRECTIONAL
Maximum repetitive peak reverse voltage	160 V
surface mount	YES
Terminal surface	Tin/Lead (Sn/Pb)
Base Number Matches	1

Preview

Download Datasheet

View All

CMF5.0A

THRU

CMF170A

UNI-DIRECTIONAL SURFACE MOUNT

TRANSIENT VOLTAGE SUPPRESSOR

200 WATTS, 5.0 THRU 170 VOLTS

Central

DESCRIPTION:

Semiconductor Corp.

The CENTRAL SEMICONDUCTOR CMF5.0 Series of Transient

Voltage Suppressors are designed to protect sensitive electronic

components from high voltage, high-energy transients. High

surge capability, low impedance, low clamping voltage, fast

response time and small size make this an excellent choice for

industrial/consumer applications, such as cell phones, power

supplies and portable devices.

Specified

STAND-OFF

VOLTAGE

MARKING CODE: SEE ELECTRICAL

CHARACTERISTICS TABLE

SOD-123F CASE

APPLICATIONS:

FEATURES:

•

DIGITAL CAMERAS

•

CELL PHONES AND ACCESSORIES

•

DESKTOP AND LAPTOP COMPUTERS

•

PDAs

MAXIMUM RATINGS:

(TA=25°C)

Peak Pulse Power (10/1000μs Waveform)

ESD Voltage (HBM)

Operating and Storage Junction Temperature

•

STAND-OFF VOLTAGE 5 - 170 VOLTS

•

VERY LOW LEAKAGE CURRENT

•

LOW CLAMPING VOLTAGE

•

200 WATT PEAK POWER DISSIPATION

•

SMALL, HIGH THERMAL EFFICIENCY,

SOD-123F FLAT LEAD PACKAGE

SYMBOL

PPP

VESD

TJ, Tstg

200

-65 to +150

UNITS

°C

ELECTRICAL CHARACTERISTICS:

(TJ=25°C unless otherwise noted)

Reverse

Stand-Off

Voltage

Type

VRWM

(V)

5.0

6.0

6.5

7.0

7.5

8.0

8.5

9.0

Breakdown

Voltage

VBR @ IT

MIN

MAX

(V)

6.4

7.0

6.67

7.37

7.22

7.98

7.78

8.6

8.33

9.21

8.89

9.83

9.44

10.4

11.1

12.3

12.2

13.5

13.3

14.7

14.4

15.6

16.7

17.8

18.9

15.9

17.2

18.5

19.7

20.9

22.1

Test

Current

(mA)

1.0

Reverse

Leakage

Current

IR @ VRWM

(μA)

400

250

100

5.0

2.5

1.0

Maximum

Clamping

Voltage

VC @ IPP

(V)

9.2

10.3

11.2

12.9

13.6

14.4

15.4

18.2

19.9

21.5

23.2

24.4

27.6

29.2

Peak

Pulse

Current

IPP

(A)

21.7

19.4

17.9

16.7

15.5

14.7

13.9

11.8

10.1

9.3

8.6

8.2

7.7

7.2

6.8

Marking

Code

CMF5.0A

CMF6.0A

CMF6.5A

CMF7.0A

CMF7.5A

CMF8.0A

CMF8.5A

CMF9.0A

CMF10A

CMF11A

CMF12A

CMF13A

CMF14A

CMF15A

CMF16A

CMF17A

CMF18A

CM05A

CM06A

CM065

CM07A

CM075

CM08A

CM085

CM09A

CM10A

CM11A

CM12A

CM13A

CM14A

CM15A

CM16A

CM17A

CM18A

R2 (6-May 2009)
