Part Number

Search

9-106202-1

Description
CONNECTOR, 96 CONTACT(S), FEMALE, STRAIGHT TWO PART EURO CONNECTOR, PRESS FIT, RECEPTACLE
CategoryThe connector    The connector
File Size112KB,1 Pages
ManufacturerTE Connectivity
Websitehttp://www.te.com
Download Datasheet Parametric View All

9-106202-1 Overview

CONNECTOR, 96 CONTACT(S), FEMALE, STRAIGHT TWO PART EURO CONNECTOR, PRESS FIT, RECEPTACLE

9-106202-1 Parametric

Parameter NameAttribute value
Reach Compliance Codeunknow
Body/casing typeRECEPTACLE
Connector typeBOARD EURO CONNECTOR
Contact to complete cooperationNOT SPECIFIED
Contact point genderFEMALE
DIN complianceYES
Filter functionNO
IEC complianceNO
MIL complianceNO
Manufacturer's serial number106202
Mixed contactsNO
Installation methodSTRAIGHT
Installation typeBOARD
Number of rows loaded3
OptionsGENERAL PURPOSE
Termination typePRESS FIT
Total number of contacts96
UL Flammability Code94V-0
Base Number Matches1
My Account
Tyco Electronics
(C hange)
Se a rch by Ke yword or Pa rt #
Products
Documentation
Resources
My Account
Customer Support
Home
>
Products
>
By Type
>
Eurocard C onnectors
>
Product Feature Selector
> Product Details
9-106202-1 Product Details
Live Product Chat
Eurocard Type C
Not re vie we d for R oHS C om plia nce
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
9-106202-1
T E I nternal N umber: 9 - 1 0 6 2 0 2 - 1
Product Highlights:
l
Type C C onnectors
l
Receptacle
l
96 Positions
l
Rows Loaded = A, B, C
l
Terminate To Printed C ircuit Board
View all Features
Obsolete
C ontact Product Information C enter
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
None Available
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type
= Type C C onnectors
l
Gender
= Receptacle
l
Number of Positions
= 96
l
PC B Retention Feature
= Yes
l
PC B Mount Angle
= Vertical
l
PC B Thickness (Minimum) (mm [in])
= 1.60 [0.063]
l
Post Type
= C ompliant Post
l
Size
= Standard
l
Make First / Break Last
= No
l
Bus Type
= FUTUREBUS, MULTIBUS (II), NUBUS, VMEbus
l
DIN Level
= I
l
Mounting Ears
= With
l
Toolless (Flat Rock) = No
Termination Related Features:
l
Termination Post Length (mm [in])
= 21.50 [0.846]
Body Related Features:
l
Rows Loaded
= A, B, C
l
PC B Retention Method
= AC TION PIN (C ompliant) Posts
l
C ontact C ross Section (mm [in])
= 0.64 [.025] Sq.
Contact Related Features:
l
C ontact Base Material = Phosphor Bronze
Housing Related Features:
l
Housing Material = Thermoplastic - GF
l
Housing Flammability Rating = UL 94V-0
Industry Standards:
l
RoHS/ELV C ompliance
= Not reviewed for ELV/RoHS compliance
l
Lead Free Solder Processes
= Not reviewed for lead free solder
process
l
Flux-Tight C oating
= Without
Conditions for Usage:
l
Terminate To
= Printed C ircuit Board
l
High Temperature Housing
= No
Other:
l
Brand = AMP
