CY23S08ZXC-1H datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > logic> logic> CY23S08ZXC-1H

CY23S08ZXC-1H: Description23S SERIES, PLL BASED CLOCK DRIVER, 8 TRUE OUTPUT(S), 0 INVERTED OUTPUT(S), PDSO16, 4.40 MM, LEAD FREE, TSSOP-16; Categorylogic logic; File Size1011KB，14 Pages; ManufacturerRochester Electronics; Websitehttps://www.rocelec.com/

Download Datasheet Parametric Compare View All

CY23S08ZXC-1H Overview

23S SERIES, PLL BASED CLOCK DRIVER, 8 TRUE OUTPUT(S), 0 INVERTED OUTPUT(S), PDSO16, 4.40 MM, LEAD FREE, TSSOP-16

CY23S08ZXC-1H Parametric

Parameter Name	Attribute value
Parts packaging code	TSSOP
package instruction	TSSOP,
Contacts	16
Reach Compliance Code	unknown
series	23S
Input adjustment	STANDARD
JESD-30 code	R-PDSO-G16
length	5 mm
Logic integrated circuit type	CLOCK DRIVER
Number of functions	1
Number of inverted outputs
Number of terminals	16
Actual output times	8
Maximum operating temperature	70 °C
Minimum operating temperature
Output characteristics	3-STATE
Package body material	PLASTIC/EPOXY
encapsulated code	TSSOP
Package shape	RECTANGULAR
Package form	SMALL OUTLINE, THIN PROFILE, SHRINK PITCH
propagation delay (tpd)	0.275 ns
Certification status	COMMERCIAL
Same Edge Skew-Max（tskwd）	0.25 ns
Maximum seat height	1.1 mm
Maximum supply voltage (Vsup)	3.6 V
Minimum supply voltage (Vsup)	3 V
Nominal supply voltage (Vsup)	3.3 V
surface mount	YES
technology	CMOS
Temperature level	COMMERCIAL
Terminal surface	NOT SPECIFIED
Terminal form	GULL WING
Terminal pitch	0.65 mm
Terminal location	DUAL
width	4.4 mm
minfmax	133.3 MHz
Base Number Matches	1
