Crystal Units
Surface Mount Type CX2016SB
2.0×1.6mm for Mobile Communications
Features
• Reference frequency for
telecommunication systems
• Reflow compatible
• Using ceramic package resulting in high
reliability
• Small and low profile
How to Order
CX2016SB 26000
□□ □ □ □ □□
①
②
③ ④⑤⑥ ⑦
①
Series
③
Load Capacitance
B0
D0
FF
LJ
6 pF
8 pF
—
Std.
②
Frequency
④
Frequency Stability
F
G
±10×10
-6
±15×10
-6
±10×10
-6
±15×10
-6
Std.
—
—
Std.
Applications
• Mobile Communications, Bluetooth,
Wireless LAN
⑤
Operating Temp. Range
⑥
Frequency Temp. Stability
-20
to
+70°C
-30
to
+85°C
Pb Free
RoHS Compliant
⑦
Individual Specification
Specifications
Item
Frequency Range
Overtone Order
Load Capacitance
Frequency Stability
Motional Series Resistance
Drive Level
Operating Temp. Range
Storage Temp. Range
Frequency Temp. Characteristics
Symbol
f
_nom
OT
CL
f
_tol
R1
DL
T
_use
T
_stg
f
_tem
Specification
26000 to 60000
Fundamental
8
±10
Table 1
Table 2
-30
to
+85
-40
to
+85
±15
Units
kHz
―
pF
×10
-6
ohm
µW
°C
°C
×10
-6
Freq. deviation from the value at 25°C
25°C±3°C
Remarks
Typical Frequencies and Part Numbers
Frequency (kHz)
26000.000
27120.000
32000.000
36000.000
38400.000
40000.000
44000.000
54000.000
Part Number
CX2016SB26000D0FLJZ1
CX2016SB27120D0FLJZ1
CX2016SB32000D0FLJZ1
CX2016SB36000D0FLJZ1
CX2016SB38400D0FLJZ1
CX2016SB40000D0FLJZ1
CX2016SB44000D0FLJZ1
CX2016SB54000D0FLJZ1
*
Please contact us for other specifications.
Table1 Motional Series Resistance
Frequency Range
26000 to 35999kHz
36000 to 39999kHz
40000 to 60000kHz
Motional Series Resistance
80W max.
60W max.
50W max.
Table2 Level of Drive
Frequency Range
26000 to 60000kHz
Level of Drive
10µW (100µW max.)
Dimensions
4 R0.1
#4
#3
1.60 0.10
(Unit: mm)
Recommended Land Pattern
(Unit: mm)
1 Product Thickness
0.30 0.05mm is also available.
0.40 0.05
4 0.10 0.1
0.15 0.05
#1
2.00 0.10
#2
1
#1
8 0.10 0.1
#2
C 0.20
#4
GND
(NC)
#3
4 0.59 0.1
GND
#4
4 0.67 0.1
#3
#1
#2
CONNECTION
(TOP VIEW)
