MCP1801T-6002I/OT datasheet, PDF

Datasheet> All Categories > MCP1801T-6002I/OT

MCP1801T-6002I/OT: DescriptionLDO Regulator Pos 6V 0.15A 5-Pin SOT-23 T/R; File Size355KB，28 Pages; ManufacturerMicrochip; Websitehttps://www.microchip.com; Environmental Compliance

Download Datasheet Download user manual Parametric Compare View All

MCP1801T-6002I/OT Overview

LDO Regulator Pos 6V 0.15A 5-Pin SOT-23 T/R

MCP1801T-6002I/OT Parametric

Parameter Name	Attribute value
EU restricts the use of certain hazardous substances	Compliant
ECCN (US)	EAR99
Part Status	Active
Type	LDO
Number of Outputs	1
Polarity	Positive
Accuracy (%)	±2
Output Type	Fixed
Output Voltage (V)	6
Maximum Output Current (A)	0.15(Min)
Minimum Input Voltage (V)	2
Maximum Input Voltage (V)	10
Maximum Dropout Voltage @ Current (V)	0.09@30mA\|0.25@100mA\|0.35@100mA\|0.12@30mA
Line Regulation	0.2%/V
Load Regulation	50mV
Maximum Quiescent Current (mA)	0.05
Maximum Power Dissipation (mW)	250
Junction to Ambient	256°C/W
Junction to Case	81°C/W
Special Features	Shutdown\|Current Limit
Minimum Operating Temperature (°C)	-40
Maximum Operating Temperature (°C)	85
Packaging	Tape and Reel
Supplier Package	SOT-23
Pin Count	5
Standard Package Name	SOT-23
Mounting	Surface Mount
Package Height	1.3(Max)
Package Length	2.9
Package Width	1.6
PCB changed	5
Lead Shape	Gull-wing

User Manual

Preview

Download Datasheet

View All

MCP1801

150 mA, High PSRR, Low Quiescent Current LDO

Features:

•

150 mA Maximum Output Current

Low Dropout Voltage, 200 mV typical @ 100 mA

25 µA Typical Quiescent Current

0.01 µA Typical Shutdown Current

Input Operating Voltage Range: 2.0V to 10.0V

Standard Output Voltage Options:

- 0.9V, 1.2V, 1.8V, 2.5V, 3.0V, 3.3V, 5.0V, 6.0V

Output Voltage Accuracy:

- ±2% (V

> 1.5V), ±30 mV (V



1.5V)

Stable with Ceramic Output Capacitors

Current Limit Protection

Shutdown Pin

High PSRR: 70 dB typical @ 10 kHz

Description:

The MCP1801 is a family of CMOS low dropout (LDO)

voltage regulators that can deliver up to 150 mA of

current while consuming only 25 µA of quiescent

current (typical). The input operating range is specified

from 2.0V to 10.0V, making it an ideal choice for two to

six primary cell battery-powered applications, 9V

alkaline and one or two cell Li-Ion-powered

applications.

The MCP1801 is capable of delivering 100 mA with

only 200 mV (typical) of input to output voltage

differential (V

OUT

= 3.3V). The output voltage tolerance

of the MCP1801 at +25°C is typically ±0.4% with a

maximum of ±2%. Line regulation is ±0.01% typical at

+25°C.

The LDO output is stable with a minimum of 1 µF of

output capacitance. Ceramic, tantalum, or aluminum

electrolytic capacitors can all be used for input and

output. Overcurrent limit with current foldback provides

short-circuit protection. A shutdown (SHDN) function

allows the output to be enabled or disabled. When

disabled, the MCP1801 draws only 0.01 µA of current

(typical).

The MCP1801 is available in a SOT-23-5 package.

Applications:

•

Battery-powered Devices

Battery-powered Alarm Circuits

Smoke Detectors

Detectors

Pagers and Cellular Phones

Wireless Communications Equipment

Smart Battery Packs

Low Quiescent Current Voltage Reference

PDAs

Digital Cameras

Microcontroller Power

Solar-Powered Instruments

Consumer Products

Battery Powered Data Loggers

Package Types

SOT-23-5

OUT

Related Literature:

• AN765,

“Using Microchip’s Micropower LDOs”,

DS00765, Microchip Technology Inc., 2002

• AN766,

“Pin-Compatible CMOS Upgrades to

BiPolar LDOs”,

DS00766,

Microchip Technology Inc., 2002

• AN792,

“A Method to Determine How Much

Power a SOT23 Can Dissipate in an Application”,

DS00792, Microchip Technology Inc., 2001

SHDN



2010 Microchip Technology Inc.

DS22051D-page 1

MCP1801T-6002I/OT Related Products

	MCP1801T-6002I/OT	MCP1801T-0902I/OT	MCP1801T-1802I/OT	MCP1801T-2502I/OT	MCP1801T-5002I/OT	MCP1801T-1202I/OT	MCP1801T-3002I/OT	MCP1801T-3302I/OT
Description	LDO Regulator Pos 6V 0.15A 5-Pin SOT-23 T/R	LDO Regulator Pos 0.9V 0.15A 5-Pin SOT-23 T/R	LDO Regulator Pos 1.8V 0.15A 5-Pin SOT-23 T/R	LDO Regulator Pos 2.5V 0.15A 5-Pin SOT-23 T/R	LDO Regulator Pos 5V 0.15A 5-Pin SOT-23 T/R	LDO Regulator Pos 1.2V 0.15A 5-Pin SOT-23 T/R	LDO Regulator Pos 3V 0.15A 5-Pin SOT-23 T/R	LDO Regulator Pos 3.3V 0.15A 5-Pin SOT-23 T/R
EU restricts the use of certain hazardous substances	Compliant	Compliant	Compliant	Compliant	Compliant	Compliant	Compliant	Compliant
ECCN (US)	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99
Part Status	Active	Active	Active	Active	Active	Active	Active	Active
Type	LDO	LDO	LDO	LDO	LDO	LDO	LDO	LDO
Number of Outputs	1	1	1	1	1	1	1	1
Polarity	Positive	Positive	Positive	Positive	Positive	Positive	Positive	Positive
Accuracy (%)	±2	±2	±2	±2	±2	±2	±2	±2
Output Type	Fixed	Fixed	Fixed	Fixed	Fixed	Fixed	Fixed	Fixed
Output Voltage (V)	6	0.9	1.8	2.5	5	1.2	3	3.3
Maximum Output Current (A)	0.15(Min)	0.15(Min)	0.15(Min)	0.15(Min)	0.15(Min)	0.15(Min)	0.15(Min)	0.15(Min)
Minimum Input Voltage (V)	2	2	2	2	2	2	2	2
Maximum Input Voltage (V)	10	10	10	10	10	10	10	10
Maximum Dropout Voltage @ Current (V)	0.09@30mA\|0.25@100mA\|0.35@100mA\|0.12@30mA	0.09@30mA\|0.25@100mA\|0.12@30mA\|0.35@100mA	0.09@30mA\|0.25@100mA\|0.12@30mA\|0.35@100mA	0.09@30mA\|0.25@100mA\|0.12@30mA\|0.35@100mA	0.09@30mA\|0.25@100mA\|0.12@30mA\|0.35@100mA	0.09@30mA\|0.25@100mA\|0.12@30mA\|0.35@100mA	0.09@30mA\|0.25@100mA\|0.12@30mA\|0.35@100mA	0.09@30mA\|0.25@100mA\|0.12@30mA\|0.35@100mA
Line Regulation	0.2%/V	0.2%/V	0.2%/V	0.2%/V	0.2%/V	0.2%/V	0.2%/V	0.2%/V
Load Regulation	50mV	50mV	50mV	50mV	50mV	50mV	50mV	50mV
Maximum Quiescent Current (mA)	0.05	0.05	0.05	0.05	0.05	0.05	0.05	0.05
Maximum Power Dissipation (mW)	250	250	250	250	250	250	250	250
Junction to Ambient	256°C/W	256°C/W	256°C/W	256°C/W	256°C/W	256°C/W	256°C/W	256°C/W
Junction to Case	81°C/W	81°C/W	81°C/W	81°C/W	81°C/W	81°C/W	81°C/W	81°C/W
Special Features	Shutdown\|Current Limit	Current Limit\|Shutdown	Current Limit\|Shutdown	Current Limit\|Shutdown	Shutdown\|Current Limit	Current Limit\|Shutdown	Current Limit\|Shutdown	Current Limit\|Shutdown
Minimum Operating Temperature (°C)	-40	-40	-40	-40	-40	-40	-40	-40
Maximum Operating Temperature (°C)	85	85	85	85	85	85	85	85
Packaging	Tape and Reel	Tape and Reel	Tape and Reel	Tape and Reel	Tape and Reel	Tape and Reel	Tape and Reel	Tape and Reel
Supplier Package	SOT-23	SOT-23	SOT-23	SOT-23	SOT-23	SOT-23	SOT-23	SOT-23
Pin Count	5	5	5	5	5	5	5	5
Standard Package Name	SOT-23	SOT-23	SOT-23	SOT-23	SOT-23	SOT-23	SOT-23	SOT-23
Mounting	Surface Mount	Surface Mount	Surface Mount	Surface Mount	Surface Mount	Surface Mount	Surface Mount	Surface Mount
Package Height	1.3(Max)	1.3(Max)	1.3(Max)	1.3(Max)	1.3(Max)	1.3(Max)	1.3(Max)	1.3(Max)
Package Length	2.9	2.9	2.9	2.9	2.9	2.9	2.9	2.9
Package Width	1.6	1.6	1.6	1.6	1.6	1.6	1.6	1.6
PCB changed	5	5	5	5	5	5	5	5
Lead Shape	Gull-wing	Gull-wing	Gull-wing	Gull-wing	Gull-wing	Gull-wing	Gull-wing	Gull-wing
HTS	-	-	-	8542.39.00.01	8542.39.00.01	8542.39.00.01	8542.39.00.01	8542.39.00.01
