POWER SPLITTERS
2 Way 90°
POWER SPLITTERS - 2 WAY 90°
Features
• Broadband frequency range
Operating characteristics
• Operating and storage temperature:
Case drawings
- 55° C / + 100° C
• Soldering heat:
10 s at 265° C
• High isolation
• Surface Mount package available
FP2
SMM1
Model
N°
F53008-01
F53008-05
F53008-09
F53008-08
F53008-22
F53008-07
F53008-03
F53008-04
F53008-10
F53008-20
F53008-25
F53008-16
C53008-01
C53008-05
C53008-09
C53008-08
C53008-22
C53008-07
C53008-03
C53008-04
C53008-10
C53008-20
C53008-25
Freq. range
(MHz)
min.
20
30
30
40
50
66
80
100
110
120
250
1000
20
30
30
40
50
66
80
100
110
120
250
max.
40
60
90
80
130
78
160
200
250
160
500
2000
40
60
90
80
130
78
160
200
250
160
500
Insertion loss
(dB)
typ.
0.3
0.6
0.6
0.3
0.75
0.6
0.5
0.6
0.75
0.5
0.2
0.2
0.3
0.6
0.6
0.3
0.75
0.6
0.5
0.6
0.75
0.5
0.2
max.
0.5
0.75
0.8
0.5
1
0.75
0.75
0.75
1
0.75
0.5
0.3
0.5
0.75
0.8
0.5
1
0.75
0.75
0.75
1
0.75
0.5
Amplitude
unbalance
(dB)
typ.
0.5
0.5
0.6
0.4
0.9
0.1
0.6
0.6
0.7
0.2
0.5
0.5
0.5
0.5
0.6
0.4
0.9
0.1
0.6
0.6
0.7
0.2
0.5
max.
0.75
0.75
1
0.75
1
0.2
1
1
1
0.4
1
1
0.75
0.75
1
0.75
1
0.2
1
1
1
0.4
1
Quadrature
deviation
(degree)
typ.
0.5
1
1.1
1
1
1
1
0.5
1
0.8
1
1
0.5
1
1.1
1
1
1
1
0.8
1
0.8
1
max.
2
2
2
2
2
2
2
2
2
2
2
3
2
2
2
2
3
2
2
2
2
2
3
Isolation
(dB)
typ.
30
28
25
25
22
25
30
25
25
25
25
25
30
28
25
25
22
25
30
25
25
25
25
min.
20
20
18
20
16
20
20
20
20
20
20
20
20
20
18
20
16
20
20
20
20
20
20
Package
FP2
FP2
FP2
FP2
FP2
FP2
FP2
FP2
FP2
FP2
FP2
FP2
SMM1
SMM1
SMM1
SMM1
SMM1
SMM1
SMM1
SMM1
SMM1
SMM1
SMM1
