CECC16101-003-08-09 datasheet, PDF

Datasheet> All Categories > Mechanical and electronic products> relay> CECC16101-003-08-09

CECC16101-003-08-09: DescriptionPower/Signal Relay, DPDT, Momentary, 0.012A (Coil), 30VDC (Coil), 360mW (Coil), 1A (Contact), 28VDC (Contact), DC Input, DC Output, Through Hole-Straight Mount,; CategoryMechanical and electronic products relay; File Size234KB，2 Pages; ManufacturerHi-G Relays

Download Datasheet Parametric View All

CECC16101-003-08-09 Overview

Power/Signal Relay, DPDT, Momentary, 0.012A (Coil), 30VDC (Coil), 360mW (Coil), 1A (Contact), 28VDC (Contact), DC Input, DC Output, Through Hole-Straight Mount,

CECC16101-003-08-09 Parametric

Parameter Name	Attribute value
Reach Compliance Code	unknown
ECCN code	EAR99
body height	7.11 mm
Body length or diameter	9.4 mm
Maximum coil current (DC)	0.012 A
Coil operating voltage (DC)	22 V
Coil power	360 mW
Coil release voltage (DC)	1 V
Coil resistance	2500 Ω
Maximum coil voltage (DC)	30 V
Coil/Input Power Type	DC
Maximum contact current (DC)	1 A
Contact (DC) maximum rated R load	1A@28VDC
Maximum contact voltage (DC)	28 V
Contact/Output Power Type	DC
Electrical life	100000 Cycle(s)
JESD-609 code	e3
Installation features	THROUGH HOLE-STRAIGHT MOUNT
operating hours	4.5 ms
Maximum operating temperature	125 °C
Minimum operating temperature	-65 °C
Guideline	CECC
Relay action	MOMENTARY
Relay function	DPDT
Relay type	POWER/SIGNAL RELAY
release time	4 ms
seal	HERMETICALLY SEALED
surface mount	NO
Terminal surface	TIN
Termination type	SOLDER
