Couplers
500 Watt High Performance
Directional Couplers - N TNC Types
500 MHz to 18.0 GHz Frequency Range
Low VSWR - High Directivity
500 Watt High Power Capability
Individually Calibrated
.175 (4.4) DIA
THRU TYP
Midwest Microwave's series of High Power
Directional Couplers are useable for system or
testing where flat frequency response over
extended bandwidths is required. They pos-
sess high directivity and will withstand high
input power under extreme environmental con-
ditions. Standard units have stainless steel
Note: Case Style 7 has two mounting holes.
Type N female connectors but are also avail-
able with TNC connectors.
ELECTRICAL SPECIFICATIONS
Frequency
R an g e
(GH z )
C ase
Style
Model
N umber
C oupling
(dB )
(Incl Freq
Sensitivity)
Frequency
Sensitivity
(dB )
Insertion
L o ss
(dB ) max
D irectivity
(dB ) min
VSWR
max
Pow er (In)
Avg Avg Avg
In
R ef P eak
(W) (W) (kW)
1
.5-1.0
1
2
3
1.0-2.0
3
4
3
2.0-4.0
3
4
5
4.0-10.0
5
6
7
7.0-12.4
7
7
7
12.4-18.0
7
7
C PL-5044-10-N N N -79
C PL-5044-20-N N N -79
C PL-5044-30-N N N -79
C PL-5045-10-N N N -79
C PL-5045-20-N N N -79
C PL-5045-30-N N N -79
C PL-5046-10-N N N -79
C PL-5046-20-N N N -79
C PL-5046-30-N N N -79
C PL-5047-10-N N N -79
C PL-5047-20-N N N -79
C PL-5047-30-N N N -79
C PL-5048-10-N N N -79
C PL-5048-20-N N N -79
C PL-5048-30-N N N -79
C PL-5049-10-N N N -79
C PL-5049-20-N N N -79
C PL-5049-30-N N N -79
10 + 1.0
20 + 1.0
30 + 1.0
10 + 1.0
20 + 1.0
30 + 1.0
10 + 1.0
20 + 1.0
30 + 1.0
10 + 1.0
20 + 1.0
30 + 1.0
10 + .75
20 + .75
30 + .75
10 + .75
20 + .75
30 + .75
+ 0.75
+ 0.75
+ 0.75
+ 0.75
+ 0.75
+ 0.75
+ 0.75
+ 0.75
+ 0.75
+ 0.75
+ 0.75
+ 0.75
+ 0.75
+ 0.75
+ 0.75
+ 0.75
+ 0.75
+ 0.75
0.20
0.20
0.20
0.20
0.20
0.20
0.20
0.20
0.20
0.25
0.25
0.25
0.25
0.25
0.25
0.35
0.35
0.35
30
30
30
30
30
30
25
27
27
20*
20*
20*
15
15
15
15
15
15
1.15
1.15
1.15
1.15
1.15
1.15
1.15
1.15
1.15
1.20
1.20
1.20
1.25
1.25
1.25
1.30
1.30
1.30
200
500
500
200
500
500
200
500
500
200
500
500
200
500
500
200
500
500
50
500
500
50
500
500
50
500
500
50
500
500
50
500
500
50
500
500
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
MECHANICAL SPECIFICATIONS
-
C AS E
S TYLE
A
6.25 (158.8)
6.25 (158.8)
4.10 (104.1)
4.10 (104.1)
5.10 (129.5)
5.10 (129.5)
2.50 (63.5)
B
3.00 (76.2)
3.00 (76.2)
1.09 (27.7)
1.09 (27.7)
2.00 (50.8)
2.00 (50.8)
1.13 (28.7)
C
0.51 (13.0)
0.51 (13.0)
0.50 (12.7)
0.50 (12.7)
0.66 (16.8)
0.57 (14.5)
0.60 (15.2)
D
2.13 (54.0)
2.13 (54.0)
2.13 (54.0)
2.13 (54.0)
2.13 (54.0)
2.13 (54.0)
1.50 (38.1)
* Directivity is 17 dB from 8.0 - 10.0 GHz.
INCHES (mm)
E
F
1.687 (42.9)
1.687 (42.9)
1.687 (42.9)
1.687 (42.9)
1.687 (42.9)
1.687 (42.9)
1.093 (27.8)
WE IGH T
Lbs
Kg
1.2
1.2
1.0
1.0
1.1
1.1
0.8
0.52
0.52
0.45
0.45
0.50
0.50
0.40
1
2
3
4
5
6
7
0.87 (22.1)
0.69 (17.5)
0.87 (22.1)
0.69 (17.5)
0.57 (14.5)
0.69 (17.5)
0.60 (15.2)
Note: TNC or Type N output connectors are available by substituting "TNC" or "NNN" for "SMA" in the Model Number.
