AT C H I G H P O W E R R E S I S T O R P R O D U C T S
Chip Terminations
Style CT
General Specifications
•
Nominal Impedence:
50
Ω
•
Resistive Tolerance:
±5% Standard
(2% Available).
•
Operating Temp Range:
-55 to +150˚C
•
Temperature Coefficient:
±150 ppm/˚C
•
Resistive Elements:
Proprietary film.
•
Substrate Material:
Aluminum Nitride.
•
Terminals:
Silver
•
Reliability:
MIL-PRF-55342
ATC Part Number
CT11005T0050J
CT11206T0050J
CT11020T0050J
CT12010T0050J
CT12525T0050J
CT12525T0050J01
CT12335T0050J
CT12335T0050J01
CT13725T0050J
CT13725T0050J01
CT13737T0050J
CT13737T0050J01
Resistive
Area
Overcoat
Top
View
Side
View
W
L
T
A
B
±.010 ±.010 ±.005 ±.010 ±.007
.050
.060
.200
.100
.245
.245
.350
.350
.250
.250
.370
.370
.100
.120
.100
.200
.245
.245
.230
.230
.375
.375
.370
.370
.025
.025
.025
.040
.040
.040
.040
.040
.040
.040
.040
.040
.045
.055
.034
.050
.090
.050
.100
.100
.090
.050
.120
.130
.020
.020
.020
.020
.020
.020
.020
.020
.025
.025
.025
.025
Frequency
(GHz)
DC to 4.0
DC to 4.0
DC to 18.0
DC to 4.0
DC to 4.0
DC to 2.5
DC to 4.0
DC to 4.0
DC to 4.0
DC to 1.1
DC to 2.0
DC to 1.0
VSWR
(Typ.)
1.20:1
1.20:1
1.25:1
1.20:1
1.15:1
1.15:1
1.15:1
1.15:1
1.20:1
1.20:1
1.25:1
1.30:1
Power Max*
(Watts)
5W
15W
10W
30W
60W
100W
50W
100W
125W
150W
150W
250W
* Test Condition: Chip soldered to a large copper carrier whose surface is at 100° C; maximum rated power applied.
Specification: The resistance of the film shall change no more than <2% during and after a 1000-hr. Burn-in per Mil-PRF-55342
Power Derating
100%
ATC Part Number Code
CT1 2010 T 0050 J TR
Case Style
Packaging
TR - Tape & Reel
BK - Bulk
Tolerance
See table below.
Value
Resistive Tolerances
Power Dissipation
80
60
Rated Safe Operating Range
40
Case Size
Termination
20
0
-50˚C
-25˚C
0˚C
+25˚C
+50˚C
75˚C
100˚C
125˚C
150˚C
Heat Sink Temperature (°C)
Code
Tol.
G (%)
±2
J (%)
±5
Sales of ATC products are subject to the terms and conditions contained in American Technical Ceramics Corp. Terms and Conditions of Sale (ATC
document #001-992 Rev. A 7/03). Copies of these terms and conditions will be provided upon request. They may also be viewed on ATC's website at
www.atceramics.com/aboutatc/terms_conditions_sale.html
ATC has made every effort to have this information as accurate as possible. However, no responsibility is assumed by ATC for its use, nor for any infringements of rights of third par-
ties which may result from its use. ATC reserves the right to revise the content or modify its product line without prior notice.
© 2002 American Technical Ceramics. All Rights Reserved.
ATC 001-972 Rev. H; 6/06
