MDT11P0122

、

General Description

This EPROM-Based 8-bit micro-controller

uses a fully static CMOS technology

process to achieve higher speed and

smaller size with the low power

consumption and high noise immunity. On

chip memory includes 4K words of

EPROM, and 176 bytes of static RAM.

The application areas of this MDT11P0122

range from appliance motor control and high

speed automotive to low power remote

transmitters/receivers

and

tele-

communications processors, such as

Remote controller, small instruments, toy,

automobile and keyboard … etc.

、

Features

RISC CPU

Fully static design

37 single word instructions

4K x 14 program memory.

176 bytes RAM for data

25 bi-directional I/O

Eight level hardware stacks

Watchdog timer with on-chip RC

oscillator.

Interrupt capability

Timer0 : 8-bit timer with 8-bit

prescaler

Timer1 : 16-bit timer

16-bit Timer1 compare register.

Sleep mode for power saving.

PB with port change wake-up interrupt.

LCD：29 Segments,4 commons.(27 x

4 at LQFP Package)

1/2,1/3,1/4 multiplex at 1/3,1/2 bias.

2 channel comparator

3. Applications

This specification are subject to be changed without notice. Any latest information please preview

http;//www.mdtic.com.tw

P.1

2007/11

VER 1.0
