Model CB3 & CB3LV
HCMOS/TTL CLOCK OSCILLATOR
FEATURES
•
•
•
•
•
•
•
•
•
•
Standard 7.0x5.0mm Surface Mount Footprint
HCMOS/TTL Compatible
Fundamental and 3
RD
Overtone Crystals
Frequency Range 1.5 – 160 MHz
Frequency Stability, ±50 ppm Standard
(±25 ppm and ±20 ppm available)
+3.3Vdc or +5.0Vdc Operation
Operating Temperature to –40°C to +85°C
Output Enable Standard
Tape & Reel Packaging
RoHS/Green Compliant (6/6)
DESCRIPTION
The CB3/CB3LV is a ceramic packaged Clock
oscillator offering reduced size and enhanced
stability. The small size means it is perfect for
any application. The enhanced stability means it
is the perfect choice for today’s communications
applications that require tight frequency control.
ORDERING INFORMATION
CB3
SUPPLY VOLTAGE
LV = +3.3Vdc
Blank = +5.0Vdc
FREQUENCY STABILITY
6 = ± 20 ppm
5 = ± 25 ppm
1
-
-
M
FREQUENCY IN MHz
M - indicates MHz and decimal point.
3
OPERATING TEMPERATURE RANGE
C = -20°C to +70°C (standard)
I = -40°C to +85°C
7 = ± 32 ppm
3 = ± 50 ppm (standard)
2 = ± 100 ppm
2
2
1] 6I Stability/Temperature combination is not available.
2] These stabilities are not recommended for new designs.
3] Frequency is recorded with only leading significant digits before the ‘M’ and 4 - 6 significant digits after the ‘M’ (including zeros).
[Ex. XMXXXXXX (3M579545), XXMXXXXX (14M31818), XXXMXXXX (125M0000)]
4] CTS Distributors may add a -T or -1 at the end of the part number to indicate Tape and Reel packaging.
Not all performance combinations and frequencies may be available.
Contact your local CTS Representative or CTS Customer Service for availability.
Example Part Number: CB3LV-3C-32M7680 or CB3-3I-32M7680
Document No. 008-0256-0
Page 1 - 4
Rev. F
٠ ٠ ٠
CTS Electronic Components, Inc.
٠
171 Covington Drive
٠
Bloomingdale, IL 60108
٠ ٠ ٠
٠ ٠ ٠
www.ctscorp.com
٠ ٠ ٠
7.0x5.0mm Low Cost
HCMOS/TTL Clock Oscillator
Model CB3 & CB3LV
ELECTRICAL CHARACTERISTICS
PARAMETER
Maximum Supply Voltage
Storage Temperature
Frequency Range
CB3
CB3LV
Frequency Stability
Aging
Operating Temperature
Commercial
Industrial
Supply Voltage
CB3
CB3LV
Supply Current
CB3
I
CC
CB3LV
SYMBOL
V
CC
T
STG
f
O
∆f/f
O
∆f
T
A
V
CC
± 10 %
Frequency Range, Tested load condition noted
for typical values.
Absolute Maximums
CONDITIONS
-
-
-
-
See Note 1 and Ordering Information
First year
-
MIN
-0.5
-55
1.5
1.5
-
-
-20
-40
4.5
3.0
-
-
-
-
-
-
-
-
-
10
TTL
0.9*V
CC
V
CC
-0.6V
-
-
-
45
-
-
-
-
-
-
-
2.0
-
-
-
-
-
-
TYP
-
-
-
-
-
3
25
5.0
3.3
10
30
40
7
20
30
-
-
-
-
-
-
-
-
8
5
2.5
6
3
1.5
-
-
-
-
-
-
-
-
MAX
7.0
125
107
160
20, 25 or
50
5
70
85
5.5
3.6
25
50
80
12
40
60
50
30
15
-
0.1*V
CC
0.4
-16/-8
+16/+8
55
10
8
5
8
5
3
10
-
0.8
10
10
50
5
1
UNIT
V
°C
MHz
± ppm
± ppm
°C
V
Output Load
Electrical and Waveform Parameters
C
L
Output Voltage Levels
Logic '1' Level
Logic '0' Level
Output Current
Logic '1' Level
Logic '0' Level
Output Duty Cycle
Rise and Fall Time
CB3
1.5 MHz to 20 MHz
20.1 MHz to 80 MHz
80.1 MHz to 107 MHz
1.5 MHz to 20 MHz
20.1 MHz to 80 MHz
80.1 MHz to 160 MHz
1.5 MHz to 50 MHz
50.1 MHz to 80 MHz
80.1 MHz to 160 MHz
CMOS Load
TTL LOAD
CMOS
Load
V
OH
= 3.9V/2.2V
V
OL
= 0.4V
@ 50% Level
C
L
=50pF
C
L
=50pF
C
L
=15pF
C
L
=15pF
C
L
=15pF
C
L
=15pF
mA
pF
V
OH
V
OL
I
OH
I
OL
SYM
V
V
CC
= 4.5V/3.0V
V
CC
= 4.5V/3.0V
mA
%
@ 10% - 90% Levels, Tested load condition
noted for typical values.
T
R
, T
F
CB3LV
Start Up Time
Enable Function
Enable Input Voltage
Disable Input Voltage
Enable Time
Standby Current
Period Jitter, Pk-Pk
Period Jitter, RMS
Phase Jitter, RMS
T
S
V
IH
V
IL
T
PLZ
I
ST
-
-
-
1.5 MHz to 20 MHz
20.1 MHz to 80 MHz
80.1 MHz to 160 MHz
1.5 MHz to 20 MHz
20.1 MHz to 80 MHz
80.1 MHz to 160 MHz
Application of V
CC
Pin
Pin
Pin
Pin
1
1
1
1
Logic
Logic
Logic
Logic
C
L
=50pF
C
L
=50pF
C
L
=15pF
C
L
=15pF
C
L
=15pF
C
L
=15pF
ns
ms
V
ms
µA
ps
'1', Output Enabled
'0', Output Disabled
'1'
'0', Output Disabled
-
-
Bandwidth 12 kHz - 20 MHz
Notes:
1. Inclusive of calibration @ 25°C, operating temperature range, supply voltage variation, load variation, and first year aging.
Document No. 008-0256-0
Page 2 - 4
Rev. F
٠ ٠ ٠
CTS Electronic Components, Inc.
٠
171 Covington Drive
٠
Bloomingdale, IL 60108
٠٠٠
7.0x5.0mm Low Cost
HCMOS/TTL Clock Oscillator
CMOS/TTL OUTPUT WAVEFORM
Tr
Tf
Model CB3 & CB3LV
TEST CIRCUIT, CMOS LOAD
V
OH
90%, 80%, 2.4V
+
mA
-
4
+
+
VM
-
1
3
D.U.T.
2
C
L
Including probe
capacitance.
50%, 1.5V
.01uF
POWER
SUPPLY
-
10%, 20%, 0.5V
UPTIME (t)
PERIOD (T)
V
OL
Enable Input
DUTY CYCLE = t/T x 100 (%)
ENABLE TRUTH TABLE
PIN 1
Logic ‘1’
Open
Logic ‘0’
PIN 3
Output
Output
High Imp.
D.U.T. PIN ASSIGNMENTS
PIN
1
2
3
4
SYMBOL
EOH
GND
Output
V
CC
DESCRIPTION
Enable Input
Circuit & Package Ground
RF Output
Supply Voltage
MECHANICAL SPECIFICATIONS
PACKAGE DRAWING
(7.0 ±0.2)
0.276 ±0.008
(1.4)
0.055
(1.2)
0.047
MARKING INFORMATION
1. ** – Manufacturing Site Code.
[Note a dash may follow the site code and is acceptable.]
PIN 1 IDENTIFIER
2. XXXMXXXXXX – Frequency is marked with
only leading significant digits before the ‘M’
and 4 - 6 digits after the ‘M’ (including zeros).
Ex. XMXXXXXX (3M579545)
XXMXXXXX (14M31818)
XXXMXXXX (125M0000)
CTS ** CB3
XXXMXXXXXX
●
YYWW STV
(5.0 ±0.2)
0.197 ±0.008
(3.7)
0.146
3
4
2
1
(5.08)
0.200
3. YYWW – Date code, YY – year, WW – week.
4. ST – Frequency stability/temperature code.
(Refer to Ordering Information.)
5. V – Voltage code. 3 = 3.3V, 5 = 5.0V.
NOTES
1. Termination pads (e4). Barrier-plating is
nickel (Ni) with gold (Au) flash plate.
2. Reflow conditions per JEDEC J-STD-020.
(1.7)
MAX
0.067
Key:
(mm)
Inch
SUGGESTED SOLDER PAD GEOMETRY
.071 [1.80]
C
BYPASS
4
.079 [2.00]
3
.165 [4.20]
1
.200 [5.08]
2
Key:
[mm]
Inch
C
BYPASS
should be
≥
0.01 uF.
Document No. 008-0256-0
Page 3 - 4
Rev. F
٠ ٠ ٠
CTS Electronic Components, Inc.
٠
171 Covington Drive
٠
Bloomingdale, IL 60108
٠٠٠
7.0x5.0mm Low Cost
HCMOS/TTL Clock Oscillator
Model CB3 & CB3LV
TAPE AND REEL INFORMATION
Standard packaging is tape and reel for this product family. Device quantity is 1,000 pieces per 180mm reel.
DIMENSIONS IN MILLIMETERS
17.5
Ø13
2.0
4.0
8.0
Ø1.50
1.75
2.40
2.10
120°
8.40
7.90
16.0
Ø60
Ø180
5.70
5.40
DIRECTION OF FEED
Ø23
ENVIRONMENTAL SPECIFICATIONS
Temperature Cycle:
Mechanical Shock:
Sinusoidal Vibration:
Gross Leak:
Fine Leak:
Resistance to Solder Heat:
High Temperature Operating Bias:
Frequency Aging:
Moisture Sensitivity Level:
400 cycles from –55°C to +125°C, 10 minute dwell at each temperature, 1
minute transfer time between temperatures.
1,500g’s, 0.5mS duration, ½ sinewave, 3 shocks each direction along 3
mutually perpendicular planes (18 total shocks).
0.06 inches double amplitude, 10 to 55 Hz and 20g’s, 55 to 2,000 Hz, 3 cycles
each in 3 mutually perpendicular planes (9 times total).
No leak shall appear while immersed in an FC40 or equivalent liquid at
+125°C for 20 seconds.
Mass spectrometer leak rates less than 2x10
-8
ATM cc/sec air equivalent.
Product must survive 3 reflows of +260°C peak, 10 seconds maximum.
2,000 hours at +125°C, maximum bias, disregarding frequency shift.
1,000 hours at +85°C, full bias, less than ±5 ppm shift.
Level 1 per JEDEC J-STD-020.
Document No. 008-0256-0
Page 4 - 4
Rev. F
٠ ٠ ٠
CTS Electronic Components, Inc.
٠
171 Covington Drive
٠
Bloomingdale, IL 60108
٠٠٠
