Type MEXY
Class X2 and Y2/X2, Polyester Film Capacitors
Metallized
Box Style, Vac Rated
Interference Suppression and
Across-the-line Vac Applications
The Type MEXY metallized polyester class X2 and
Y2/X2 film capacitors are ideal for across-the-line
and line-to-ground interference suppression circuit
applications. This product features the self-healing
capabilities associated with metallized polyester,
compact design and flame retardant construction
meets UL 94V0.
Specifications
Voltage Range:
275 Vac/250 Vac, 60 Hz
Dielectric Strength:
Capacitance Range:
0.001 µF - 2.2 µF
Between terminals:
575 Vac, 1768 Vdc 60 s
Capacitance Tolerance:
±10% Std. ±20% Optl.
Between terminals:
1500 Vac, 2121 Vdc 60 s
Operating Temperature Range:
–40 °C to 100 °C
(0.001 to 0.0068 µF)
Dissipation Factor:
1.0% max. (20 ºC, 1kHz)
Between terminals to enclosure:
2050 Vac 60 s
Insulation Resistance:
C≤0.33
µF: 15000 MΩ min. (20 ºC 100 Vdc 60 s)
C>0.33 µF: 5000 MΩ x µF min. (20 ºC 500 Vdc 60 s)
2000 MΩ min. (20 ºC 100 Vdc 60 s)
Pulse Capability
Body Length (L)
Rated AC
Voltage
275/250
15 mm
118
17.5 mm 25.5 mm 30.5 mm
62
33
29
S
dV/dt - volts per microsecond, maximum
Agency Approvals
Agency
UL
Specification #
UL 1414
UL 1283 (4th Ed)
CSA C22.2 No. 1-94
CSA
CSA C22.2
No.8-M1986
IEC60384-14, 1993
EN132400
Agency/CDE
File #
E171988
E223166
218093
218095
40004840
Application
Across-the-line Capacitors
Antenna-coupling and Line-bypass Capacitors
Electromagnetic Interference (EMI) Filters
Across-the-line Capacitors
Antenna-isolation and Line-by-pass Capacitors
Electromagnetic Interference (EMI) Filters
Class Y2/X2
Class X2
RoHS Compliant
Voltage
250 Vac
250 Vac
250 Vac
250 Vac
250 Vac
275 Vac
275 Vac
Capacitance Range
.001 to 1.0 µF
.001 to 1.0 µF
1.2 to 2.2 µF
.001 to 1.0 µF
1.2 to 2.2 µF
0.001 to 0.0068 µF
0.0082 to 2.2 µF
VDE
CDE Cornell Dubilier • 1605 E. Rodney French Blvd. • New Bedford, MA 02744 • Phone: (508)996-8561 • Fax: (508)996-3830 • www.cde.com
Type MEXY
Class X2 and Y2/X2, Polyester Film Capacitors
Ratings
Cap.
(µF)
Catalog
Part Number
T
±.020 (0.5)
(inches) (mm)
H
±0.020 (0.5)
(inches) (mm)
L
± .020 (0.5)
(inches) (mm)
S
± .015 (0.4)
(inches)
(mm)
d
(inches)
(mm)
RoHS Compliant
275 Vac (IEC384 - 14) 250Vac (UL/CSA)
0.0010
0.0012
0.0015
0.0018
0.0022
0.0027
0.0033
0.0039
0.0047
0.0056
0.0068
0.0082
0.010
0.012
0.015
0.018
0.022
0.027
0.033
0.039
0.047
0.056
0.068
0.082
0.100
0.120
0.150
0.180
0.220
0.270
0.330
0.390
0.470
0.560
0.680
0.820
1.000
1.200
1.500
1.800
2.200
MEXY2A102K
MEXY2A122K
MEXY2A152K
MEXY2A182K
MEXY2A222K
MEXY2A272K
MEXY2A332K
MEXY2A392K
MEXY2A472K
MEXY2A562K
MEXY2A682K
MEXY2A822K
MEXY2A103K
MEXY2A123K
MEXY2A153K
MEXY2A183K
MEXY2A223K
MEXY2A273K
MEXY2A333K
MEXY2A393K
MEXY2A473K
MEXY2A563K
MEXY2A683K
MEXY2A823K
MEXY2A104K
MEXY2A124K
MEXY2A154K
MEXY2A184K
MEXY2A224K
MEXY2A274K
MEXY2A334K
MEXY2A394K
MEXY2A474K
MEXY2A564K
MEXY2A684K
MEXY2A824K
MEXY2A105K
MEXY2A125K
MEXY2A155K
MEXY2A185K
MEXY2A225K
0.197
0.197
0.197
0.197
0.197
0.197
0.197
0.197
0.197
0.197
0.197
0.197
0.197
0.197
0.197
0.197
0.197
0.197
0.236
0.236
0.236
0.177
0.177
0.217
0.217
0.256
0.256
0.315
0.315
0.374
0.374
0.335
0.335
0.413
0.413
0.472
0.472
0.650
0.650
0.748
0.748
(5.0)
(5.0)
(5.0)
(5.0)
(5.0)
(5.0)
(5.0)
(5.0)
(5.0)
(5.0)
(5.0)
(5.0)
(5.0)
(5.0)
(5.0)
(5.0)
(5.0)
(5.0)
(6.0)
(6.0)
(6.0)
(4.5)
(4.5)
(5.5)
(5.5)
(6.5)
(6.5)
(8.0)
(8.0)
(9.5)
(9.5)
(8.5)
(8.5)
(10.5)
(10.5)
(12.0)
(12.0)
(16.5)
(16.5)
(19.0)
(19.0)
0.453
0.453
0.453
0.453
0.453
0.453
0.453
0.453
0.453
0.453
0.453
0.453
0.453
0.453
0.453
0.453
0.453
0.453
0.512
0.512
0.512
0.453
0.453
0.472
0.472
0.571
0.571
0.630
0.630
0.693
0.693
0.693
0.693
0.768
0.768
0.866
0.866
1.024
1.024
1.161
1.161
(11.5)
(11.5)
(11.5)
(11.5)
(11.5)
(11.5)
(11.5)
(11.5)
(11.5)
(11.5)
(11.5)
(11.5)
(11.5)
(11.5)
(11.5)
(11.5)
(11.5)
(11.5)
(13.0)
(13.0)
(13.0)
(11.5)
(11.5)
(12.0)
(12.0)
(14.5)
(14.5)
(16.0)
(16.0)
(17.5)
(17.5)
(17.5)
(17.5)
(19.5)
(19.5)
(22.0)
(22.0)
(26.0)
(26.0)
(29.5)
(29.5)
0.591
0.591
0.591
0.591
0.591
0.591
0.591
0.591
0.591
0.591
0.591
0.591
0.591
0.591
0.591
0.591
0.591
0.591
0.591
0.591
0.591
0.689
0.689
0.689
0.689
0.689
0.689
0.689
0.689
0.689
0.689
1.004
1.004
1.004
1.004
1.004
1.004
1.201
1.201
1.201
1.201
(15.0)
(15.0)
(15.0)
(15.0)
(15.0)
(15.0)
(15.0)
(15.0)
(15.0)
(15.0)
(15.0)
(15.0)
(15.0)
(15.0)
(15.0)
(15.0)
(15.0)
(15.0)
(15.0)
(15.0)
(15.0)
(17.5)
(17.5)
(17.5)
(17.5)
(17.5)
(17.5)
(17.5)
(17.5)
(17.5)
(17.5)
(25.5)
(25.5)
(25.5)
(25.5)
(25.5)
(25.5)
(30.5)
(30.5)
(30.5)
(30.5)
0.492
0.492
0.492
0.492
0.492
0.492
0.492
0.492
0.492
0.492
0.492
0.492
0.492
0.492
0.492
0.492
0.492
0.492
0.492
0.492
0.492
0.591
0.591
0.591
0.591
0.591
0.591
0.591
0.591
0.591
0.591
0.886
0.886
0.886
0.886
0.886
0.886
1.083
1.083
1.083
1.083
(12.5)
(12.5)
(12.5)
(12.5)
(12.5)
(12.5)
(12.5)
(12.5)
(12.5)
(12.5)
(12.5)
(12.5)
(12.5)
(12.5)
(12.5)
(12.5)
(12.5)
(12.5)
(12.5)
(12.5)
(12.5)
(15.0)
(15.0)
(15.0)
(15.0)
(15.0)
(15.0)
(15.0)
(15.0)
(15.0)
(15.0)
(22.5)
(22.5)
(22.5)
(22.5)
(22.5)
(22.5)
(27.5)
(27.5)
(27.5)
(27.5)
0.024
0.024
0.024
0.024
0.024
0.024
0.024
0.024
0.024
0.024
0.024
0.024
0.024
0.024
0.024
0.024
0.024
0.024
0.024
0.024
0.024
0.024
0.024
0.024
0.024
0.024
0.024
0.024
0.024
0.031
0.031
0.031
0.031
0.031
0.031
0.031
0.031
0.031
0.031
0.031
0.031
(0.60)
(0.60)
(0.60)
(0.60)
(0.60)
(0.60)
(0.60)
(0.60)
(0.60)
(0.60)
(0.60)
(0.60)
(0.60)
(0.60)
(0.60)
(0.60)
(0.60)
(0.60)
(0.60)
(0.60)
(0.60)
(0.60)
(0.60)
(0.60)
(0.60)
(0.60)
(0.60)
(0.60)
(0.60)
(0.80)
(0.80)
(0.80)
(0.80)
(0.80)
(0.80)
(0.80)
(0.80)
(0.80)
(0.80)
(0.80)
(0.80)
