SURFACE MOUNT GLASS
PASSIVATED RECTIFIER
MFPT05S – MFPT10S
Surface Mount Glass Passivated Rectifier
Features
•
Low leakage current
•
For surface mounted applications
•
Plastic package has Underwriters Laboratory Flammability
Classification 94V-0 Utilizing Flame Retardant Epoxy
Molding Compound
•
RoHS Compliance
MFP
Mechanical Data
Case:
Terminals:
Polarity:
Mounting Position:
Weight:
JEDEC SOD-123 / MINI-SMA, Molded plastic body
Solder plated, solderable per MIL-STD-750, Method 2026
Indicated by cathode band
Any
0.04 gram
Maximum Ratings and Electrical Characteristics
(T
A
=25ºC unless otherwise noted)
Symbol
Description
Maximum Repetitive
Peak Reverse
Voltage
Maximum RMS
Voltage
Continuous Reverse
Voltage
Maximum Forward
Voltage
Forward rectified
current
Peak Forward
Surge Current
MFPT
05S
50
35
50
MFPT
1S
100
70
100
MFPT
2S
200
140
200
MFPT
4S
400
280
400
1.1
1
MFPT
6S
600
420
600
MFPT
8S
800
560
800
MFPT
10S
1000
700
1000
Unit
V
V
V
V
A
Conditions
V
RRM
V
RMS
V
R
V
F
I
O
See Fig.1
8.3ms single half
sine-wave
superimposed on
rated load
(JEDEC method)
V
R
= V
RRM
T
A
= 25°C
V
R
= V
RRM
T
A
= 100°C
I
FSM
30
A
5.0
uA
uA
I
R
Reverse Current
50
TAITRON COMPONENTS INCORPORATED
www.taitroncomponents.com
Tel: (800)-247-2232
Fax: (800)-TAITFAX
(800)-TAITRON
(800)-824-8329
(661)-257-6060
(661)-257-6415
Rev. B/JY
Page 1 of 4
Surface Mount Glass Passivated Rectifier
MFPT05S – MFPT10S
Symbol
Description
Thermal
Resistance
Diode Junction
Capacitance
MFPT
05S
MFPT
1S
MFPT
2S
MFPT
4S
60
30
15
pF
MFPT
6S
MFPT
8S
MFPT
10S
Unit
Conditions
Junction to ambient
Junction to case
F = 1MHZ and
applied 4vDC
reverse voltage
Rth
JA
Rth
JC
C
J
°C / W
T
J,
T
STG
Operating Junction
and Storage
Temperature
Range
-55 to +150
°C
Typical Characteristics Curves
Fig.1- Forward Current Derating Curve
Peak Forward Surge Current, (A)
Average Forward Current, (A)
Fig.2- Maximum Non-Repetitive
Forward Surge Current
Ambient Temperature (°C)
Number of Cycles at 60Hz
Rev. B/JY
www.taitroncomponents.com
Page 2 of 4
Surface Mount Glass Passivated Rectifier
MFPT05S – MFPT10S
Fig.3- Typical Forward
Characteristics
Fig.4- Typical Reverse Characteristics
Instantaneous Forward Current, (A)
Reverse Leakage Current, (
u
A)
Forward Voltage, (V)
Percentage Rated Peak Reverse Voltage
Fig.5-Typical Junction Capacitance
Junction Capacitance, (pF)
Reverse Voltage, (V)
Rev. B/JY
www.taitroncomponents.com
Page 3 of 4
Surface Mount Glass Passivated Rectifier
MFPT05S – MFPT10S
Dimensions in inches (mm)
