CME2-17 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Analog mixed-signal IC> filter> CME2-17

CME2-17: DescriptionData Line Filter; CategoryAnalog mixed-signal IC filter; File Size16KB，1 Pages; ManufacturerInductor Supply Inc

Download Datasheet Parametric Compare View All

CME2-17 Overview

Data Line Filter

CME2-17 Parametric

Parameter Name	Attribute value
Reach Compliance Code	unknown
filter type	DATA LINE FILTER
Base Number Matches	1

Preview

Download Datasheet

View All

Common

Mode Choke

.40

.80

max

.15

0.032

Dia.

1.10

max

1.10

.62 max

CME2

Schematic

INDUCTANCES

0.12 mhy to 10 mhy

CONSTRUCTION

EE core

Varnish impregnated

APPLICATIONS

Reduce EMI emissions

INDUCTANCE TOLERANCE ±25%

DIELECTRIC WITHSTANDING VOLTAGE 3750 Vrms.

OPERATING TEMPERATURE RANGE -55°C to +130°C.

Notes:

(1) Inductance values are per section.

(2) Leakage values are measured between 1 & 2 with 3 & 4 shor ted.

PART

NUMBER

INDUCTANCE

(mH)

CURRENT

RATING (AMPS)

DC RESISTANCE

OHMS

MAX (Ω)

LEAKAGE

INDUCTANCE

(µhy) MAX

CME2-1

CME2-2

CME2-3

CME2-4

CME2-5

CME2-6

CME2-7

CME2-8

CME2-9

CME2-10

CME2-11

CME2-12

CME2-13

CME2-14

CME2-15

CME2-16

CME2-17

CME2-18

CME2-19

CME2-20

CME2-21

CME2-22

CME2-23

0.12

0.15

0.18

0.22

0.27

0.33

0.47

0.56

0.68

0.82

1.0

1.2

1.5

1.8

2.2

2.7

3.3

3.9

4.7

5.6

6.8

8.2

5.50

4.50

3.50

2.80

2.20

1.70

1.40

1.10

0.88

0.70

0.015

0.016

0.019

0.023

0.026

0.028

0.033

0.038

0.040

0.063

0.068

0.099

0.115

0.131

0.174

0.188

0.331

0.438

0.500

0.525

0.625

0.813

0.875

4.8

6.5

7.2

7.75

9.5

12.5

14.0

18.0

23.0

26.0

35.0

40.0

43.0

54.0

61.5

118

135

155

168

216

246

257

293
