Thin Film Chip Inductors
ctparts.com
SPECIFICATIONS
CTTF0402F Series
From 0.2 nH to 33 nH
Not shown at actual size.
Please specify tolerance code when ordering.
CTTF0402F-0N2_
B = ±0.1nH, C = ±0.2nH, S = ±0.3nH, F = ±1%, G = ±2%,
H = ±3%, J = ±5%
* = F, G, H or J only
Part
Number
CTTF0402F-0N2_
CTTF0402F-0N4_
CTTF0402F-0N8_
CTTF0402F-1N0_
CTTF0402F-1N2_
CTTF0402F-1N5_
CTTF0402F-1N6_
CTTF0402F-1N8_
CTTF0402F-2N0_
CTTF0402F-2N2_
CTTF0402F-2N7_
CTTF0402F-3N1_
CTTF0402F-3N3_
CTTF0402F-3N6_
CTTF0402F-3N9_
CTTF0402F-4N7_
CTTF0402F-5N6_
CTTF0402F-5N9_
CTTF0402F-6N8_
CTTF0402F-7N2_
CTTF0402F-8N0_
CTTF0402F-8N2_
CTTF0402F-9N1_
CTTF0402F-10N_*
CTTF0402F-12N_*
CTTF0402F-13N8_*
CTTF0402F-15N_*
CTTF0402F-17N_*
CTTF0402F-18N_*
CTTF0402F-20N8_*
CTTF0402F-22N_*
CTTF0402F-27N_*
CTTF0402F-33N_*
Inductance
(nH)
0.2
0.4
0.8
1.0
1.2
1.5
1.6
1.8
2.0
2.2
2.7
3.1
3.3
3.6
3.9
4.7
5.6
5.9
6.8
7.2
8.0
8.2
9.1
10
12
13.8
15
17
18
20.8
22
27
33
L Test
Freq.
(MHz)
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
Q
Min.
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
Q Test
Freq.
(MHz)
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
DCR
Max.
Ω
(Ω)
0.1
0.1
0.1
0.1
0.1
0.2
0.2
0.2
0.3
0.3
0.3
0.4
0.4
0.4
0.5
0.6
0.7
0.7
0.9
0.9
1.1
1.1
1.1
1.3
1.6
1.6
1.8
2.0
2.0
2.6
2.6
2.5
2.5
Rated DC
Max.
(mA)
800
800
700
700
700
700
560
560
560
440
440
380
380
380
340
320
280
280
260
260
220
220
220
200
180
180
130
100
100
90
90
75
75
SRF
Min.
(GHz)
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
5.5
5.5
5.5
4.5
3.7
3.7
3.3
3.1
3.1
2.8
2.8
3.25
3.75
Compliant
RoHS
CHARACTERISTICS
Description:
SMD thin film chip inductors
Applications:
Cellular Telephone, pagers, GPS products,
wireless LAN and other communication appliances, VCO, TCXO
circuit and RF Transceiver Module
Operating Temperature:
-40°C to +85°C
Inductance Tolerance:
±0.1nH, ±0.2nH & ±2%
Testing:
Tested on a HP4287A at 500 MHz
Packaging:
Tape & Reel
Miscellaneous:
RoHS Compliant.
Marking:
Reels are marked with inductance code and tolerance
Additional Information:
Additional electrical & physical
information available upon request
Samples available. See website for ordering information.
PHYSICAL DIMENSIONS
Size
mm
inches
A
1.0 ± 0.05
0.04 ± 0.002
B
0.5 ± 0.05
0.02 ± 0.002
C
0.35 ± 0.05
0.01 ± 0.002
D
0.2 ± 0.1
0.008 ± 0.004
10.26.06
Technologies
Manufacturer of Inductors, Chokes, Coils, Beads, Transformers & Toroids
800-684-5322
Inside US
949-453-1811
Outside US
Copyright © 2006 by CT Magnetics, DBA Central Technologies. All rights reserved.
CT Magnetics reserves the right to make improvements or change specifications without notice
