Wire-wound Chip Inductors
ctparts.com
CTMC1210S Series
From .010 µH to 1000 µH
Part
Number
CTMC1210S-10NM
CTMC1210S-12NM
CTMC1210S-15NM
CTMC1210S-18NM
CTMC1210S-22NM
CTMC1210S-27NM
CTMC1210S-33NM
CTMC1210S-39NM
CTMC1210S-47NM
CTMC1210S-56NM
CTMC1210S-68NM
CTMC1210S-82NM
CTMC1210S-R10M
CTMC1210S-R12K
CTMC1210S-R15K
CTMC1210S-R18K
CTMC1210S-R22K
CTMC1210S-R27K
CTMC1210S-R33K
CTMC1210S-R39K
CTMC1210S-R47K
CTMC1210S-R56K
CTMC1210S-R68K
CTMC1210S-R82K
CTMC1210S-1R0K
CTMC1210S-1R2K
CTMC1210S-1R5K
CTMC1210S-1R8K
CTMC1210S-2R2K
CTMC1210S-2R7K
CTMC1210S-3R3K
CTMC1210S-3R9K
CTMC1210S-4R7K
CTMC1210S-5R6K
CTMC1210S-6R8K
CTMC1210S-8R2K
CTMC1210S-100K
CTMC1210S-120K
CTMC1210S-150K
CTMC1210S-180K
CTMC1210S-220K
CTMC1210S-270K
CTMC1210S-330K
CTMC1210S-390K
CTMC1210S-470K
CTMC1210S-560K
CTMC1210S-680K
CTMC1210S-820K
CTMC1210S-101K
CTMC1210S-121M
CTMC1210S-151M
CTMC1210S-181M
CTMC1210S-221M
CTMC1210S-271M
CTMC1210S-331M
CTMC1210S-391M
CTMC1210S-471M
CTMC1210S-561M
CTMC1210S-681M
CTMC1210S-821M
CTMC1210S-102M
Not shown at actual size.
SPECIFICATIONS
Part numbers indicate available inductance tolerance.
K = ±10%, M = ±20%
Inductance
(µH)
0.010
0.012
0.015
0.018
0.022
0.027
0.033
0.039
0.047
0.056
0.068
0.082
0.10
0.12
0.15
0.18
0.22
0.27
0.33
0.39
0.47
0.56
0.68
0.82
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1000
L Test
Freq.
(MHz)
100
100
100
100
100
100
100
100
100
100
100
100
100
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
0.796
0.796
0.796
0.796
0.796
0.796
0.796
0.796
0.796
0.796
0.796
0.796
Q
Factor
Min.
10
10
10
15
15
15
15
20
20
20
20
20
30
35
35
35
40
40
40
40
50
50
50
50
50
60
60
60
60
60
60
60
60
60
60
60
60
50
50
50
50
50
50
50
50
50
50
50
50
25
25
25
25
25
25
25
25
25
25
25
25
Q Test
Freq.
(MHz)
100
100
100
100
100
100
100
100
100
100
100
100
100
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
0.796
0.796
0.796
0.796
0.796
0.796
0.796
0.796
0.796
0.796
0.796
0.796
SRF
Min.
(MHz)
2000
1750
1550
1450
1300
1150
1040
950
850
770
740
600
550
580
470
400
340
290
250
220
200
180
155
140
130
150
130
120
105
90
80
70
60
52
44
37
31
49
30
22
17
14.5
12.5
11.5
10.5
10
9.0
8.5
7.8
7.6
6.8
6.2
5.6
5.1
4.6
4.2
3.7
3.4
3.1
2.7
2.4
DCR
Max.
Ω
(Ω)
0.19
0.20
0.23
0.25
0.28
0.30
0.34
0.37
0.41
0.47
0.50
0.55
0.52
0.24
0.26
0.29
0.33
0.37
0.39
0.42
0.46
0.51
0.55
0.60
0.68
0.52
0.59
0.64
0.71
0.77
0.85
0.94
1.00
1.10
1.25
1.35
1.50
1.50
1.75
1.95
2.15
2.35
2.65
2.90
3.15
3.40
3.80
4.30
4.70
3.05
3.50
3.95
4.20
4.80
5.55
6.00
6.70
7.50
8.35
9.55
11.0
Rated
DC
(mA)
725
705
655
630
595
575
540
515
490
460
445
425
435
645
620
585
550
515
505
485
465
440
425
405
380
435
360
330
310
300
240
230
220
180
160
130
120
120
120
110
100
85
85
70
65
45
55
40
40
14
13
10
10
8.5
8.5
8.0
8.0
7.5
6.0
5.5
5.0
CHARACTERISTICS
Description:
Wire-wound shielded chip inductor
Applications:
TVs, VCRs, disk drives, computer peripherals,
telecommunication devices and electronic control boards
for automobiles
Inductance Tolerance:
±10%, ±20%
Testing:
Inductance and Q are tested on an HP4285A or
HP4286A at specified frequency
Packaging:
Tape & Reel
Marking:
Reels marked with inductance code and tolerance
Miscellaneous:
Magnetically shielded
Additional Information:
Additional electrical & physical
information available upon request
Samples available. See website for ordering information.
PHYSICAL DIMENSIONS
Size
mm
inches
A
0.126
3.2
B
0.098
2.5
C
0.098
2.5
D
0.004
0.1
E
0.028±0.008
0.7±0.2
Resin
Ferrite
E
C
D
A
B
11.16.06
Technologies
Manufacturer of Passive and Discrete Semiconductor Components
800-684-5322
Inside US
949-453-1811
Outside US
Copyright © 2006 by CT Magnetics, DBA Central Technologies. All rights reserved.
CT Magnetics reserves the right to make improvements or change specifications without notice
