Power Inductors - Shielded
ctparts.com
CTCDRH5D18F Series
From 3.3 µH to 330 µH
Part
Number
SPECIFICATIONS
Please specify tolerance code when ordering.
CTCDRH5D18F-3R3_
M = ±20%, N = ±30%
L Test
Freq.
(kHz)
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
DCR
Max.
Ω
(mΩ)
50
57
76
96
115
116
124
153
196
210
290
330
386
520
595
665
840
978
1200
1500
1710
2240
2440
3380
4340
Rated DC
Current
(A)
2.15
1.95
1.60
1.40
1.35
1.25
1.20
1.10
0.97
0.85
0.80
0.75
0.65
0.57
0.54
0.50
0.43
0.41
0.36
0.33
0.31
0.28
0.23
0.21
0.18
Inductance
(µH)
3.3
4.1
5.4
6.2
6.8
8.9
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
ENGINEERING KIT #44
Not shown at actual size.
CTCDRH5D18F-3R3_
CTCDRH5D18F-4R1_
CTCDRH5D18F-5R4_
CTCDRH5D18F-6R2_
CTCDRH5D18F-6R8_
CTCDRH5D18F-8R9_
CTCDRH5D18F-100_
CTCDRH5D18F-120_
CTCDRH5D18F-150_
CTCDRH5D18F-180_
CTCDRH5D18F-220_
CTCDRH5D18F-270_
CTCDRH5D18F-330_
CTCDRH5D18F-390_
CTCDRH5D18F-470_
CTCDRH5D18F-560_
CTCDRH5D18F-680_
CTCDRH5D18F-820_
CTCDRH5D18F-101_
CTCDRH5D18F-121_
CTCDRH5D18F-151_
CTCDRH5D18F-181_
CTCDRH5D18F-221_
CTCDRH5D18F-271_
CTCDRH5D18F-331_
Compliant
RoHS
CHARACTERISTICS
Description:
SMD (shielded) power inductor
Applications:
Power supplies for VTR, OA equipment, LCD
televisions, PC notebooks, portable communication equipment,
DC/DC converters, etc.
Operating Temperature:
-40°C to +85°C
Inductance Tolerance:
±20%, ±30%
Testing:
Tested on a HP4284A at 10 KHz , 0.25Vrms , 0Adc
Packaging:
Tape & Reel
Marking:
Parts are marked with inductance code
Rated DC Current:
Indicates the current when the inductance
decreases to 65% of its initial value or D.C. current when the
temperature of coil is increased by 30% the smaller one is defined
as rated current.
Miscellaneous:
RoHS Compliant.
Additional Information:
Additional electrical & physical
information available upon request
Samples available. See website for ordering information.
PHYSICAL DIMENSIONS
Size
mm
inches
A
5.7±0.3
0.22±0.01
B
5.7±0.3
0.22±0.01
C
5.5
0.217
D
2.0
0.08
E
5.5
0.217
F
Max.
8.2
0.32
G
Max.
2.0
0.08
PAD LAYOUT
09.10.09
CENTRAL
Manufacturer of Passive Components
800-684-5322
Inside US
949-453-1811
Outside US
Copyright © 2009 by CT Magnetics, DBA Central Technologies. All rights reserved.
CT Magnetics reserves the right to make improvements or change specifications without notice
