Toroidal Common Mode Choke
ctparts.com
CTCTX-2 Series
From 0.42 µH to 300.80 µH
Part
Number
CTCTX_0.47-2
CTCTX_0.68-2
Not shown at actual size.
CTCTX_1-2
CTCTX_2-2
CTCTX_5-2
CTCTX_8-2
CTCTX_10-2
CTCTX_15-2
CTCTX_20-2
CTCTX_25-2
CTCTX_33-2
CTCTX_50-2
CTCTX_68-2
CTCTX_100-2
CTCTX_150-2
CTCTX_200-2
CTCTX_300-2
SPECIFICATIONS
Parts are available in ±20% tolerance only.
CTCTXF~~~-2 Please specify “F” for RoHS compliant.
PARALLEL
DCR
Max.
Ω
(Ω)
0.005
0.006
0.007
0.010
0.021
0.027
0.031
0.059
0.107
0.117
0.105
0.210
0.303
0.457
0.560
0.796
1.231
Full Load
Current
(Adc)
6.50
5.50
4.60
4.50
3.00
2.60
2.50
1.70
1.30
1.00
1.40
0.92
0.78
0.63
0.43
0.39
0.38
SERIES
DCR
Max.
Ω
(Ω)
0.019
0.024
0.028
0.038
0.084
0.108
0.125
0.236
0.426
0.466
0.420
0.839
1.214
1.828
2.241
3.184
4.929
Full Load
Current
(Adc)
3.25
2.75
2.30
2.25
1.50
1.30
1.25
0.85
0.65
0.50
0.70
0.46
0.39
0.32
0.22
0.20
0.19
Height
C
(mm)
6.9
6.9
6.9
6.9
6.9
6.9
6.9
6.9
6.9
6.9
6.9
6.9
6.9
5.0
5.0
5.0
5.0
OCL
(µH±20%)
0.42
0.75
1.18
2.30
4.70
7.94
10.58
15.23
20.73
24.86
31.77
51.18
67.87
99.45
147.39
198.58
300.80
OCL
(µH±20%)
1.69
3.01
4.70
9.21
18.80
31.77
42.30
60.91
82.91
99.45
127.09
204.73
271.47
397.81
589.57
794.30
1203.20
PHYSICAL DIMENSIONS
Size
A
Nom.
9.0
0.35
B
Nom.
11.4
0.45
C
Max.
See ordering
info
D
Max.
3.05
0.12
E
Max.
3.56
0.14
F
Min.
0.762
0.03
CHARACTERISTICS
Description:
SMD Toroidal Common Mode Choke
Applications:
Single inductors, 1:1 coupled inductors, & 1:1
isolation transformers
Operating Temperature:
-40°C to +85°C
Storage Temperature:
-40°C to +125°C
Inductance Tolerance:
±20%
Testing:
Inductance is tested on an HP4285A at 100 kHz
Packaging:
Tape & Reel
Marking:
Parts marked with inductance code & series type
Miscellaneous:
RoHS Compliant available.
Additional Information:
Additional electrical & physical
information available upon request
Samples available. See website for ordering information.
mm
inches
