CTLH1005F Series
From 1.0 nH to 100 nH
Part
Number
Not shown at actual size.
SPECIFICATIONS
Please specify tolerance code when ordering.
CTLH1005F-5N6_
S = ±0.3nH, J = ±5%, K = ±10%
* S or K only, ** J or K only
Inductance
at 100MHz
(nH)
1.0
1.2
1.5
1.8
2.0
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
Q Min. at
(MHz)
100
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
Q Typ. at
(MHz)
100
800
9
9
10
10
10
10
11
11
11
11
11
11
12
12
12
12
12
12
12
10
10
10
10
10
10
10
28
28
28
28
29
29
30
30
31
31
31
33
32
32
31
30
29
28
27
25
25
22
21
19
16
10
SRF
Typ.
(MHz)
10000
10000
9000
8700
8100
8100
7700
6300
6100
5400
5100
4550
4100
3900
3000
2600
2350
2000
1900
1700
1600
1300
1250
1000
900
850
DCR
Max.
Ω
(Ω)
.10
.10
.10
.10
.15
.15
.15
.15
.20
.20
.20
.25
.30
.35
.40
.50
.55
.70
.80
1.0
1.2
1.3
2.0
2.2
2.5
2.5
IDC
Max.
(mA)
400
400
400
400
400
400
400
400
400
400
400
400
300
300
300
300
300
300
300
200
150
150
150
100
100
100
Compliant
RoHS
CTLH1005F-1N0S
CTLH1005F-1N2S
CTLH1005F-1N5S
CTLH1005F-1N8S
CTLH1005F-2N0S
CTLH1005F-2N2S
CTLH1005F-2N7S
CTLH1005F-3N3_*
CTLH1005F-3N9_*
CTLH1005F-4N7_*
CTLH1005F-5N6_*
CTLH1005F-6N8_**
CTLH1005F-8N2_**
CTLH1005F-10N_**
CTLH1005F-12N_**
CTLH1005F-15N_**
CTLH1005F-18N_**
CTLH1005F-22N_**
CTLH1005F-27N_**
CTLH1005F-33N_**
CTLH1005F-39N_**
CTLH1005F-47N_**
CTLH1005F-56N_**
CTLH1005F-68N_**
CTLH1005F-82N_**
CHARACTERISTICS
Description:
Ceramic core, multi-layer chip inductor for high
frequency applications
Applications:
RF Resonance and Impedance Matching Circuit.
RF and wireless communicaton. Information technology
equipment, computers, telecommunications, radar detectors,
automotive electronics, cellular phones, pagers, PDAs, keyless
remote systems. Use in L-C filter configurations.
Temperature Coefficient:
+250ppm/°C
Operating Temperature:
-40°C to + 100°C
Inductance Tolerance:
±0.3 nH, ±5% & ±10%
Testing:
Inductance and Q are tested on an HP4286A at
specified frequency
Packaging:
Tape & Reel
Marking:
Reels marked with inductance code and tolerance
Miscellaneous:
RoHS Compliant
Additional Information:
Additional electrical & physical
information available upon request
Samples available. See website for ordering information.
CTLH1005F-R10_**
PHYSICAL DIMENSIONS
Size
mm
inches
A
1.0±0.10
0.04±0.004
B
0.5±0.10
0.02±0.004
C
0.5±0.10
0.02±0.004
D
0.25±0.10
0.01±0.004
Polarity
Mark
PAD LAYOUT
Unit: mm(inch)
Top View
1.2~1.4
(0.047~0.055)
0.4
(0.0157)
(0.0157)
05.15.07
Technologies
Manufacturer of Passive and Discrete Semiconductor Components
800-684-5322
Inside US
949-453-1811
Outside US
Copyright © 2007 by CT Magnetics, DBA Central Technologies. All rights reserved.
CT Magnetics reserves the right to make improvements or change specifications without notice
