Wire-wound Chip Inductors - Open
ctparts.com
CT0402CSF Series
From 1.0 nH to 120 nH
ENGINEERING KIT #5F
Not shown at actual size.
Part
Number
SPECIFICATIONS
Please specify tolerance code when ordering.
CT0402CS-2N0_
G = ±2%, H = ±3%, J = ±5%, K = ±10%
* J or K only
Inductance
(nH)
1.0
1.8
1.9
2.0
2.2
2.4
2.7
3.3
3.6
3.9
4.3
4.7
5.1
5.6
5.8
6.2
6.8
7.5
8.2
8.7
9.0
9.5
10
11
12
13
15
16
18
19
20
22
23
24
27
30
33
36
39
40
43
47
51
56
62
68
82
100
120
L Test
Freq.
(MHz)
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
Q
Fact.
Min.
13
14
16
16
16
16
16
19
19
17
18
20
21
20
20
20
23
23
24
18
22
18
25
25
25
26
26
26
26
24
26
26
22
26
26
26
26
26
26
24
26
26
26
26
22
22
26
26
26
Q Test
Freq.
(MHz)
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
SRF
Min.
(MHz)
>6000
>6000
>6000
>6000
>6000
>6000
>6000
>6000
>6000
5800
5800
5800
5800
4800
4800
4800
4400
4400
4400
4100
4160
4000
3700
3700
3600
3600
3200
3200
3000
3040
3000
2700
2720
2700
2500
2200
2200
2200
2200
2240
2100
2000
2000
1900
1620
1620
1700
1300
1200
DCR
Max.
Ω
(Ω)
.04
.07
.07
.07
.07
.07
.07
.06
.06
.11
.11
.11
.11
.08
.083
.08
.14
.14
.14
.20
.10
.20
.18
.18
.18
.18
.21
.21
.25
.20
.25
.36
.30
.36
.36
.41
.41
.46
.46
.44
.50
.55
.55
.77
1.12
1.1
1.33
1.87
2.35
Rated
DC
(mA)
1000
1700
1040
1040
840
840
840
840
840
800
800
800
800
760
760
760
680
680
680
480
680
480
600
600
600
600
560
560
480
480
480
375
400
375
375
320
320
310
310
320
300
260
260
200
100
100
180
160
140
Compliant
RoHS
CT0402CSF-1N0K
CT0402CSF-1N8K
CT0402CSF-1N9K
CT0402CSF-2N0_*
CT0402CSF-2N2_*
CT0402CSF-2N4_*
CT0402CSF-2N7_*
CT0402CSF-3N3_*
CT0402CSF-3N6_
CT0402CSF-3N9_
CT0402CSF-4N3_
CT0402CSF-4N7_
CT0402CSF-5N1_
CT0402CSF-5N6_
CT0402CSF-5N8_
CT0402CSF-6N2_
CT0402CSF-6N8_
CT0402CSF-7N5_
CT0402CSF-8N2_
CT0402CSF-8N7_
CT0402CSF-9N0_
CT0402CSF-9N5_
CT0402CSF-10N_
CT0402CSF-11N_
CT0402CSF-12N_
CT0402CSF-13N_
CT0402CSF-15N_
CT0402CSF-16N_
CT0402CSF-18N_
CT0402CSF-19N_
CT0402CSF-20N_
CT0402CSF-22N_
CT0402CSF-23N_
CT0402CSF-24N_
CT0402CSF-27N_
CT0402CSF-30N_
CT0402CSF-33N_
CT0402CSF-36N_
CT0402CSF-39N_
CT0402CSF-40N_
CT0402CSF-43N_
CT0402CSF-47N_
CT0402CSF-51N_
CT0402CSF-56N_
CT0402CSF-62N_
CT0402CSF-68N_
CT0402CSF-82N_*
CT0402CSF-R10_*
CT0402CSF-R12_*
CHARACTERISTICS
Description:
SMD ceramic core wire-wound chip inductor
Applications:
Telecommunication equipment, mobile phones,
small size pagers, computers, printers and relevant equipment.
Also, audio & video applications, the automotive electronics
industry and high frequency applications
Operating Temperature:
-40°C to +125°C
Inductance Tolerance:
±2%, ±3%, ±5%, ±10%
Testing:
Inductance and Q are tested on an HP4287A at
250 MHz
Packaging:
Tape & Reel
Marking:
Reels are marked with inductance code and tolerance
Additional Information:
Additional electrical & physical
information available upon request
Samples available. See website for ordering information.
PAD LAYOUT
Size
mm
inches
A
1±0.1
0.04± 0.004
PHYSICAL DIMENSIONS
B
0.68±0.1
0.03±0.004
C
0.55±0.05
0.02±0.001
D
0.55±0.05
0.02±0.001
E
0.2±0.05
0.007±0.001
F
0.6
0.02
09.02.08
CENTRAL
Manufacturer of Passive and Discrete Semiconductor Components
800-684-5322
Inside US
949-453-1811
Outside US
Copyright © 2008 by CT Magnetics, DBA Central Technologies. All rights reserved.
CT Magnetics reserves the right to make improvements or change specifications without notice
TECHNOLOGIES
