Preset counters electronic
1 preset, timer programmable
Display LED, 5-digits, programmable
NE210
Features
– Preset counter with one preset
– Display 5-digits
– Operating mode, start count, scaling factor
programmable
– Connection: Incremental encoder or digital sensors
– Time meter with four time ranges
– Time relay with operation and release delay
– Programmable as a time counter
NE210 - LED Preset counter
Technical data - electrical ratings
Voltage supply
22...50 VAC (50/60 Hz)
85...265 VAC (50/60 Hz)
24 VDC ±10 %
5 VA, 5 W
24 VDC ±20 % / 100 mA
LED, 7-segment display
5-digits
7.6 mm
Preset counter
Main counter with 1 preset
0.001...99.999
Adding or subtracting
A-B (difference counting)
A+B total (parallel counting)
Up/Down
A 90° B phase evaluation
15 Hz, 10 kHz (set by Dip
switch)
Main preset, Time meter / time
relay
>10 years in EEPROM
Button, electric or automatic
NPN / PNP transistor switch
Potential-free change-over
contact
0.01...99.99 s
Protection class II
Overvoltage category II
Pollution degree 2
DIN EN 61000-6-4
DIN EN 61000-6-2
Approvals
Technical data - electrical ratings
Programmable
parameters
Operating modes
Sensor logic
Scaling factor
Count mode
Time relay function
UL/cUL, CE conform
Power consumption
Sensor supply
Display
Number of digits
Digit height
Function
Scaling factor
Count modes
Technical data - mechanical design
Operating temperature
Storing temperature
Relative humidity
E-connection
Core cross-section
Protection DIN EN 60529
Operation / keypad
Housing type
Dimensions W x H x L
Installation depth
Mounting
Cutout dimensions
Materials
Weight approx.
0...+50 °C
-20...+70 °C
80 % non-condensing
Plug-in screw terminals
1.5 mm²
IP 65 face with seal
Membrane with softkeys
Built-in housing
48 x 48 x 108 mm
108 mm
Clip frame
45 x 45 mm (+0.6)
Housing: Makrolon 6485 (PC)
Keypad: Polyester
150 g
Subject to modification in technic and design. Errors and omissions excepted.
30/10/2008
Counting frequency
Operating modes
Data memory
Reset
Outputs electronic
Outputs relay
Output holding time
Standard
DIN EN 61010-1
Emitted interference
Interference immunity
1
www.baumerivo.com
Preset counters electronic
1 preset, timer programmable
Display LED, 5-digits, programmable
NE210
Part number
NE210.0
AXA1
Voltage supply
1
22...50 VAC
2
85...265 VAC
3
24 VDC
1
2
3
4
Accessories
Adaptor plates
(page %S)
Z 118.033
Z 118.034
Z 118.035
Adaptor plate for screw mount,
face 60 x 75 mm
Adaptor plate for clip mount,
face 53.2 x 53.2 mm
Adaptor plate for clip mount,
face 60 x 75 mm
Outputs
Relay output
Relay, signal output PNP
Relay, signal output NPN
Without relay, signal output PNP
Block circuit diagram
Voltage
supply
-
+
Signal input
A
B
Reset
Coding for
input logic
NPN Br. 11-13
PNP Br. 11-12
7
8
9
A 90°B
Sensor
supply
-
12
13
Main counter
with 1 preset
start count
scaling factor
+
2
3
4
5
6
10
electr.
output
Relay
output
Timer
Time relay
11
Trigger level
Optocoupler inputs
Control inputs
Count input
Trigger current
Switch-off current
Input resistance
Reset input
Trigger current
Switch-off current
Input resistance
Relay output
Switching voltage max.
Switching current max.
Switching capacity max.
Relay responding time
5...8 mA
<0.5 mA
3.3 kΩ
Output circuit
250 VAC / 110 VDC
1A
150 VA / 30 W
5 ms
Subject to modification in technic and design. Errors and omissions excepted.
30/10/2008
Input circuit
PNP- / NPN-logic
9...16 mA
<0.5 mA
1.65 kΩ
Connection diagram
13
12
11
10
9
8
7
+24V 0V
NPN Br. 11-13
PNP Br. 11-12
Electr. output
B
A
Count
Reset
Sensor
supply
Electronical outputs
Output circuit
PNP-switching transistor Open collector
Supply voltage
2
1
6
5
4
3
Switching voltage
Switching current max.
24 VDC ±20%
10 mA (AC)
50 mA (DC)
35 V
50 mA
End contact
NPN-switching transistor Open collector
max. 265 V
terminal - terminal /
- terminal
Switching voltage max.
Switching current max.
Dimensions
60.8
48
108
18.5
1-6
7
48
2
