REVISION CK
DO NOT
SCALE FROM
THIS PRINT
(SEE NOTE 11)
-BE OPTION
(SAME AS FIG 1 EXCEPT INSULATOR)
PATENT NUMBERS
5713755
5961339
CLT-1XX-02-XX-D-XX
No OF POS. PER ROW
-02 THRU -50
-P: PICK & PLACE PAD
AVAILABLE ON POSITIONS
04 THRU 50 ONLY
(SEE FIG. 2, SHT 2. USE LMP-03)
-TR: TAPE AND REEL PACKAGING
(02 THRU 36 POS ONLY)
-BE: BOTTOM ENTRY
(SEE FIG. 6, USE CLT-XX-DBE-XX)
-A: ALIGNMENT PIN (MOLDED OR STAKED)
(SEE FIGS. 3 & 4, SHT 2)
(STAKED MIN 5 POS)
(MOLDED MIN 3 POS)
-K: POLYIMIDE FILM PAD
(AVAILABLE ON POS. 4 THRU 50 ONLY)
(SEE FIG 5, SHT 2)
(USE K-DOT-.197-.344-.005)
OPTION
FIG 6
-02: SURFACE MOUNT
(SEE TABLE 1)
LEAD STYLE
PLATING SPECIFICATION
C
(No OF POS x .0787[2.00]) .008[0.20]
(CUT TO POSITION) SEE NOTE 4, 9, 10
(No OF POS x .07874[2.00]) - .07874[2.00] REF
-F: 3µ" SELECTIVE GOLD IN CONTACT AREA,
MATTE TIN ON TAIL
-L: 10µ" SELECTIVE GOLD IN CONTACT AREA,
SEE TABLE 1
MATTE TIN ON TAIL
-G: 10µ" GOLD IN CONTACT AREA,
.1575 4.00 REF
3µ" GOLD ON TAIL
-S: 30µ" SELECTIVE GOLD IN CONTACT AREA,
MATTE TIN ON TAIL
.07874 2.00 REF
-H: 30µ" GOLD IN CONTACT AREA,
3µ" GOLD ON TAIL
-FM: 3µ" SELECTIVE GOLD IN CONTACT AREA,
MATTE TIN ON TAIL
-LM: 10µ" SELECTIVE GOLD IN CONTACT AREA,
MATTE TIN ON TAIL
-SM: 30µ" SELECTIVE GOLD IN CONTACT AREA,
MATTE TIN ON TAIL
"A"
C
L
2.5 MAX SWAY
(ANY DIRECTION)
"A"
-D DOUBLE ROW
(USE CLT-XX-D EXCEPT
FOR -BE OPTION)
ROW SPEC.
'C'
(SEE NOTE 10)
.0200 0.51 x .0050[.127] REF
.0835 2.12
REF
.024 0.61 SQ REF
C
L
C
.090±.002 2.27±0.05
(MEASURE AT BEND)
BURR SIDE (SEE NOTE 8)
4°
SEE NOTE 2
3°
C
CLT-XX-D-XX
FIG 1
C
.0130±.0015 0.330±0.038
.203±.010 5.150±0.254
(SEE NOTE 6)
DETAIL 'C'
SCALE 16 : 1
'B'
SECTION "A"-"A"
SCALE 4 : 1
SEE NOTE 12
NOTES:
1.
C
REPRESENTS A CRITICAL DIMENSION.
2. COPLANARITY TO BE .004 FOR POSITIONS 2-25,
.006 FOR POSITIONS 26-34, AND .008 FOR 35-50.
3. MINIMUM PUSHOUT FORCE: .4 LB.
4. WILL LOSE A POSITION FOR EVERY CUT MADE ON A SOCKET STRIP.
5. ALL OPTIONS:PACKAGE POSITIONS -04 THRU -50 IN
PT-CLX002-D TUBE AS SHOWN IN VIEWS, WITH TWO TP-12 PLUGS
PER TUBE. LAYER PACKAGE POSITIONS -02 & -03.
6. SHEAR TAILS TO DIMENSION SHOWN.
7. PARTS TO BE SYMMETRICAL ABOUT C
L
8. MAXIMUM BURR: .005[0.13]
9. MAXIMUM CUT FLASH: .010[0.25] WITH NO FLASH
ALLOWED IN HOLES OR EXTENDING BELOW LEADS
10. MINIMUM STANDARD BODY ENDWALL AFTER CUTTING: .0215[0.546]
11. -BE BODY ENDWALL AFTER CUTTING: .0169 .003 [0.429 0.08]
12. C-114-02 CAN BE USED FOR C-114-22. C-114-22-XX IS FOR
AUTOMATED ASSEMBLY PROCESSES ONLY.
C
.086±.004 2.184±0.102
C
.002 [.051]
MIN
.295±.008 7.494±0.203
(HANDFILL ONLY)
IN-PROCESS 1
DETAIL 'B'
SCALE 16 : 1
*
IN-PROCESS 2
(HANDFILL ONLY)
*
C
88°
90°
UNLESS OTHERWISE SPECIFIED,
DIMENSIONS ARE IN INCHES.
TOLERANCES ARE:
DECIMALS
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS CONFIDENTIAL AND
PROPRIETARY INFORMATION AND ALL DESIGN,
MANUFACTURING, REPRODUCTION, USE, PATENT RIGHTS
AND SALES RIGHTS ARE EXPRESSLY RESERVED BY SAMTEC,
INC. THIS DOCUMENT SHALL NOT BE DISCLOSED, IN WHOLE
OR PART, TO ANY UNAUTHORIZED PERSON OR ENTITY NOR
REPRODUCED, TRANSFERRED OR INCORPORATED IN ANY
OTHER PROJECT IN ANY MANNER WITHOUT THE EXPRESS
WRITTEN CONSENT OF SAMTEC, INC.
.XX: .01 [0.3]
2
.XXX: .005 [0.13]
.XXXX: .0020 [0.051]
ANGLES
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail info@SAMTEC.com
code 55322
DESCRIPTION:
DWG. NO.
.010 0.25
C
.012 0.30
MATERIAL:
DO NOT SCALE DRAWING
SHEET SCALE: 2:1
2MM LOW PROFILE SOCKET STRIP
(AUTOMATED ONLY)
IN-PROCESS
SCALE 8:1
INSULATOR: LCP, UL 94 VO, COLOR BLACK
CONTACT: PHOS BRONZE
F:\DWG\MISC\MKTG\CLT-1XX-02-XX-D-XX-MKT.SLDDRW
CLT-1XX-02-XX-D-XX
SHEET
1
OF
2
BY:
BRATCHER 10/03/1994
REVISION CK
[(NO OF POS x .07874[2.00]) / 2]
C
-.1125[2.858] .020[0.51]
.225 5.72
C
L
.098 2.477
.202 5.13 REF
LMP-03
"P"
C
(SEE NOTE)
"M"
(SEE NOTE)
C
L
.020±.020 0.50±0.51
.197 5.00
REF
C
L
-P: PICK & PLACE PAD
(4 POS MIN)
FIG 2
.095 2.400
NOTE: "M" = USED MEASURED DIMENSION (REF)
"P" = (("M" - .1969 [5.00]) / 2) .020[0.51]
-K OPTION
(4 POS MIN)
USE TP-12 PLUGS
C
((No OF POS -2) x .0787[2.00])
C
.030 0.762 REF
.035 0.889
SM-A7H
FIG 5
C
L
CLT-XX-D(-BE
*
)
-A OPTION (STAKED)
(5 POS MIN)
FIG 3
3 MAX SWAY
(ANY DIRECTION)
.025 0.64 REF
*
= FOR -BE OPTION ONLY
ALL OPTIONS EXCEPT -P
OPTION W/O -A OPTION
POSITIONS 04 - 50
-P OPTION W/O -A OPTION
PACKAGING VIEWS
(SEE NOTE 5)
PT-CLX002-D
CLT-XX-D(-BE
*
)
(No OF POS - 2) x .0787[2.00] REF
C
.0235 0.597
.025 0.64 REF
REF
*
PROPRIETARY NOTE
*
THIS DOCUMENT CONTAINS CONFIDENTIAL AND
PROPRIETARY INFORMATION AND ALL DESIGN,
MANUFACTURING, REPRODUCTION, USE, PATENT RIGHTS
AND SALES RIGHTS ARE EXPRESSLY RESERVED BY SAMTEC,
INC. THIS DOCUMENT SHALL NOT BE DISCLOSED, IN WHOLE
OR PART, TO ANY UNAUTHORIZED PERSON OR ENTITY NOR
REPRODUCED, TRANSFERRED OR INCORPORATED IN ANY
-A OPTION (MOLDED)
(3 POS MIN)
FIG 4
*
= FOR -BE OPTION ONLY
OTHER PROJECT IN ANY MANNER WITHOUT THE EXPRESS
WRITTEN CONSENT OF SAMTEC, INC.
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail info@SAMTEC.com
code 55322
DO NOT SCALE DRAWING
DESCRIPTION:
DWG. NO.
2MM LOW PROFILE SOCKET STRIP
SHEET SCALE: 4:1
CLT-1XX-02-XX-D-XX
SHEET
2
OF
2
F:\DWG\MISC\MKTG\CLT-1XX-02-XX-D-XX-MKT.SLDDRW
BY:
BRATCHER 10/03/1994
