NJM2825 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > semiconductor> Analog mixed-signal IC> NJM2825

NJM2825: DescriptionTHREE TERM VOLTAGE REFERENCE, PDSO5; Categorysemiconductor Analog mixed-signal IC; File Size127KB，6 Pages; ManufacturerNew JRC; Websitehttps://www.njr.com

Download Datasheet Parametric Compare View All

NJM2825 Overview

THREE TERM VOLTAGE REFERENCE, PDSO5

NJM2825 Parametric

Parameter Name	Attribute value
Number of terminals	5
Processing package description	SOT-23, 5 PIN
state	ACTIVE
packaging shape	Rectangle
Package Size	SMALL OUTLINE
surface mount	Yes
Terminal form	GULL WING
Terminal location	pair
Packaging Materials	Plastic/Epoxy
Analog IC other types	Three TERM voltage reference

Preview

Download Datasheet

View All

NJM2825

Precision Micropower Shunt Voltage Reference

■GENERAL

DESCRIPTION

NJM2825

is a precision and low quiescent current shunt voltage

reference.

Reference voltage form bandgap circuit has guaranteed the high

accuracy of the ±0.5% with trimming. In addition the temperature drift of

10ppm/°C typ. was actualized by the temperature compensating circuit.

The reference voltage circuit operates by consumed low quiescent current

of the 0.7µA for low power technology.

The Output capacitor is unnecessary by the phase compensating circuit

which is built in. Tolerates capacitive loads, it is easy to use for application.

It is suitable for data converters, instrumentation, and other applications

where precision reference is required.

■PACKAGE

OUTLINE

NJM2825F

■FEATURES

●

Precision Reference Voltage

1,200mV±0.5%

●

Low temperature coefficient

10ppm/°C typ.

●

Low Quiescent Current

0.7µA max.

●

No Output Capacitor Required

●

Tolerates Capacitive Loads

●

Bipolar Technology

●

Package Outline

NJM2825F : SOT-23-5 (MTP5)

■PRODUCT

VARIATION

NJM2825

±0.5%,

MIN

=0.7µA

NJM2823

±0.4%,

MIN

=60µA

■BLOCK

DIAGRAM

CATHODE

■PIN

CONFIGURATION

NC 1

ANODE 2

REF

5 CATHODE

NC 3

NJM2825F

4 FB

ANODE

Ver.2009-03-05

-1-

NJM2825 Related Products

	NJM2825	NJM2825F
Description	THREE TERM VOLTAGE REFERENCE, PDSO5	THREE TERM VOLTAGE REFERENCE, PDSO5
Number of terminals	5	5
Processing package description	SOT-23, 5 PIN	SOT-23, 5 PIN
state	ACTIVE	ACTIVE
packaging shape	Rectangle	Rectangle
Package Size	SMALL OUTLINE	SMALL OUTLINE
surface mount	Yes	Yes
Terminal form	GULL WING	GULL WING
Terminal location	pair	pair
Packaging Materials	Plastic/Epoxy	Plastic/Epoxy
Analog IC other types	Three TERM voltage reference	Three TERM voltage reference
