Series 801 USB 3.0 Cordsets
Mighty Mouse
High-Speed
Connector to L-COM eSATA Connector
with Double-Start ACME Threads
801-078 Odering Information
801-078: Series 801 Mighty Mouse
High-Speed
USB 3.0 Overmolded Cordset
"LENGTH" MIN (SEE P/N DEVELOPMENT)
P
Series 801
High-Speed
P1
PROTECTIVE COVER,
667-217 OR 667-218
"PART NUMBER"
GLENAIR YYWW 06324
P2
BRADY LABEL,
LAT-18 OR EQ.
APPROX LOCATION:
CENTER OF CABLE
POLYAMIDE
OVERMOLD
GLENAIR HIGH-SPEED CONNECTOR,
801-036-16 PLUG OR 801-037-01 RECEPTACLE
7-10 INSERT ARRANGEMENT (GROMMET REMOVED)
L-COM USB 3.0
CABLE ASSY,
CAU3AX
How To Order
Sample Part Number
Series
Table I: Shell Key Positions
-A
NF
N
A
-48
X
801-078
P1 Connector
Shell Material / Finish
801-078
= Series 801 Mighty
Mouse to L-COM USB 3.0
cordset
-A
= Plug with Pin Contacts
-B
= Plug with Socket Contacts
-C
= Receptacle with Pin Contacts
-D
= Receptacle with Socket Contacts
M
= Aluminum / Electroless Nickel RoHS
Compliant
NF
= Aluminum / Cadmium with Olive Drab
Chromate
ZNU
= Aluminum / Zinc-Nickel with Black
Chromate
MT
= Aluminum / Nickel-PTFE, RoHS
Compliant
Z1
= Stainless Steel / Passivated RoHS
Compliant
B°
A°
Key Position
Normal (A)
B
C
D
E
F
Key Rotation
A°
150°
75°
95°
140°
75°
95°
B°
210°
210°
230°
275°
275°
210°
Protective Cover
Shell Key Position (See Table I)
Length
Wiring
P
= Metal Protective Covers Included
N
= No Covers Supplied
A
(Normal),
B, C, D, E, F
Overall Length In Inches 115" Max
X
= Crossover
Omit
= Standard
WIRING DIAGRAM - STANDARD
P1
1
5
8
4
9
10
6
7
3
2
RED 24 AWG
WHT 30 AWG
GRN 30 AWG
BLK 24 AWG
BLU 30 AWG
YEL 30 AWG
DRAIN WIRES
VIO 30 AWG
ORN 30 AWG
P2
1
2
3
4
5
6
7
8
9
P1
1
5
8
4
7
3
6
9
10
2
WIRING DIAGRAM - CROSSOVER
P2
RED 24 AWG
WHT 30 AWG
GRN 30 AWG
BLK 24 AWG
BLU 30 AWG
YEL 30 AWG
DRAIN WIRES
VIO 30 AWG
ORN 30 AWG
1
2
3
4
5
6
7
8
9
Dimensions in Inches (millimeters) are subject to change without notice.
© 2014 Glenair, Inc.
Series 80 Mighty Mouse
U.S. CAGE Code 06324
Printed in U.S.A.
GLENAIR, INC.
•
1211 AIR WAY
•
GLENDALE, CA 91201-2497
•
818-247-6000
•
FAX 818-500-9912
www.glenair.com
P-18
