10 BASE ISOLATION TRANSFORMERS PCMCIA
462 Boston St - Topsfield, MA 01983 - Phone: 978-887-8050 - Fax: 978-887-5434
SMD and PCMCIA AUI isolation Modules to meet the requirements of IEEE 802.3
for 10 Base2 10 Base5 and 10 Base-t
Storage temperature range: -40℃to +125℃
BOTHHAND
USA.
Electrical Specifications @ 25℃ Operating Temperature range: 0℃ to +70℃
Note:NS060
1. OCC: 7pF Max @ 15MHz
2. OCZ
PEAK-TX
: 400ΩMin @ 5MHz to 20MHz
3. OCZ
PEAK-CK
: 400ΩMin @ 5MHz to 20MHz
4. OCZ
PEAK-RX
: 900ΩMin@ 5MHz to 20MHz
5. Interwinding Capacitance: C
TX , RX & CK
: 7pF Max
6. Input Power : P
AC TYP
: 20mW
7. Common Mode Rejection: -30dB Min @ 5MHz
Part
Number
NS060
NS100
Turn ratio
(±5%)
RX
1:1
1:1
TX
OCL
CW/W
(uH Min) (pF Max)
60
100
7
10
DCR
(Ω Max)
-
0.32
L.L
(uH Max)
-
0.2
HI-POT Rise Time
(Vrms) (nS Max)
1500
2000
-
3.0
Insulation resistance
(MΩ)
-
10.000
Mechanical & Schematics
NSXXX
Bothhand USA
. e-mail: sales@bothhandusa.com http://www.bothhand.com
462 Boston St - Topsfield, MA 01983 - Phone: 978-887-8050 - Fax: 978-887-5434
