10W DC-DC Regulated Dual Output
■
Features :
Wide 4:1 DC input range
NSD10-D
Protections: Short circuit / Overload / Over voltage
1000VDC I/O isolation
Built-in EMI filter
Cooling by free air convection
Built-in remote ON-OFF control
100% full load burn-in test
Lost cost
High reliability
2 years warranty
series
SPECIFICATION
MODEL
DC VOLTAGE
RATED CURRENT
CURRENT RANGE
RATED POWER
OUTPUT
CAPACITIVE LOAD (max.)
NSD10-12D5
5V
1A
10W
±1000uF
±2.5%
±2.0%
±2.5%
±1.0%
±3.0%
±2.0%
48VDC
22 ~ 72VDC
78%
0.4A/48VDC
±2.5%
±2.0%
±2.5%
±1.0%
-5V
1A
NSD10-12D12
12V
0.42A
10.08W
-12V
0.42A
NSD10-12D15
15V
0.33A
9.9W
-15V
0.33A
NSD10-48D5
5V
1A
10W
-5V
1A
NSD10-48D12
12V
0.42A
10.08W
-12V
0.42A
NSD10-48D15
15V
0.33A
9.9W
-15V
0.33A
0.05 ~ 1A 0.05 ~ 1A 0.02 ~ 0.42A 0.02 ~ 0.42A 0.016 ~ 0.33A 0.016 ~ 0.33A 0.05 ~ 1A 0.05 ~ 1A 0.02 ~ 0.42A 0.02 ~ 0.42A 0.016 ~ 0.33A 0.016 ~ 0.33A
RIPPLE & NOISE (max.)
Note.2
75mVp-p(10% ~ 100% load)
VOLTAGE TOLERANCE
Note.3
±4.0%
LINE REGULATION
LOAD REGULATION
SETUP TIME
RATED DC INPUT
VOLTAGE RANGE
EFFICIENCY (Typ.)
DC CURRENT
SHUTDOWN IDLE CURRENT
OVERLOAD
PROTECTION
FUNCTION
±1.0%
±3.0%
100ms
/
RATED DC INPUT at full Load
12VDC
9.8 ~ 36VDC
76%
77%
1.4A/12VDC
20mA/12VDC
INPUT
77%
77%
77%
Above 105% rated output power
Protection type : Over power limiting, recovers automatically after fault condition is removed
-5.75 ~ -7.5V 13.8 ~ 18V -13.8 ~ -18V 17.3 ~ 22.5V -17.3 ~ -22.5V
OVER VOLTAGE(CLAMP)
5.75 ~ 7.5V -5.75 ~ -7.5V 13.8 ~ 18V -13.8 ~ -18V 17.3 ~ 22.5V -17.3 ~ -22.5V 5.75 ~ 7.5V
Recovers automatically after fault condition is removed
Note.4
SHORT CIRCUIT
Logic "1" OPEN: ON logic "0" GND: OFF
ON/OFF CONTROL
-25 ~ +70℃
WORKING TEMP.
WORKING HUMIDITY
STORAGE TEMP., HUMIDITY
0% ~ 95% RH max.
-40 ~ +85
℃
, 0 ~ 95% RH
±
0.03%/
℃
(0~60
℃
)
UL60950-1
,
EAC TP TC 004
approved, Design refer to TUV EN60950-1
I/P-O/P:1KVDC
I/P-O/P:100M Ohms / 500VDC / 25
℃
/ 70% RH
Compliance to EN55032 (CISPR32) Class B, EAC TP TC 020
ENVIRONMENT
TEMP. COEFFICIENT
SAFETY STANDARDS
SAFETY & ISOLATION VOLTAGE
ISOLATION RESISTANCE
EMC
(Note 5)
EMC EMISSION
EMC IMMUNITY
MTBF
OTHERS
DIMENSION
PACKING
NOTE
Compliance to EN61000-4-2,3,4,6,8; EN55024, light industry level, criteria A, EAC TP TC 020
1878.5K hrs min. MIL-HDBK-217F (25
℃
)
50.8*25.4*10mm (2"*1"*0.394") (L*W*H)
0.02Kg; 300pcs/7Kg/0.97CUFT
1. All parameters NOT specially mentioned are measured at 12, 48VDC input, rated load and 25
℃
of ambient temperature.
2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.
3. Tolerance : includes set up tolerance, line regulation and load regulation.
4. Short circuit not more than 60 seconds.
5. The power supply is considered a component which will be installed into a final equipment. All the EMC tests are been executed by mounting the unit on
a 230mm*230mm metal plate with 1mm of thickness. The final equipment must be re-confirmed that it still meets EMC directives. For guidance on how to
perform these EMC tests, please refer to EMI testing of component power supplies. (as available on http://www.meanwell.com)
6. To insure proper operation, a 220uF/100V electrolytic capacitor with Esr <1
Ω
must be added to the input line.
7. EMC filter suggestion:
80uH
+
Vin
-
680uF
+
+
PSU
Vo
-
8. The ambient temperature derating of 3.5
℃
/1000m with fanless models and of 5
℃
/1000m with fan models for operating altitude higher than 2000m(6500ft).
File Name:NSD10-D-SPEC 2018-01-12
