DMH-4R
-1000
DO
UBLEBALANC D MIXE
E
R
10 to 2500 MHz / +7 to + 17 dBmL / Wide BW / L Distortion / PC Applications / Half Relay
O
ow
S
PRINCIPAL SPECIFICATIONS
Model
Number
RF/LO
*IF
Frequency, Frequency,
MHz
MHz
10 - 500
Operating
Range,
MHz
10 - 500
500 - 1000
1000 - 2500
Conversion
Loss, dB,
Max. Typ.
9.0
9.0
10.0
8.5
8.0
8.5
Port Isolation, Min.
L-R
L-X
R-X
dB
dB
dB
35
30
25
30
25
20
20
20
20
Polarity
Sense
Positive
DMH-4R-1000 10 - 2500
All specifications are as measured in a 50Ω system, at nominal LO power, in a down converter application.
Package Outline
NOTES:
1. Tolerance on 3 place decimals
±
.010(.25) except as noted.
2. Dimensions in inches over millimeters.
3. Dimensions marked with * apply only at body.
4. All unmarked pins are case ground.
General Notes:
1. The DMH-4R-1000 Double Balanced Mixer covers the frequency band
of 10 to 2500 MHz using two parallel ring modulators to produce a wide
bandwidth circuit with very low intermodulation. This mixer is ideal for
cellular radio receiver systems. Although designed for drive levels of +13
dBm, it operates well at drive levels ranging from +7 to +17 dBm.
2. This mixer is provided in a half relay package that may be mounted
directly to the PCB. In situations where component height is a constraint,
the leads may be conformally formed allowing the package to be soldered
flush to the PCB.
3. Merrimac mixers comply with MIL-M-28837 and may supplied screened
for compliance with additional specifications for military and space
applications requiring the highest reliability.
22Feb96
GENERAL SPECIFICATIONS
LO Drive:
Impedance:
Noise Figure:
+13 dBm nom.
50
Ω
nom.
Within
±1
dB of
Conversion Loss
Maximum Input Power: 600 mW @ 25°C
(derate linearly to 0 mW @ 125°C)
1 dB Compression Point:+7 dBm input, typ.
Input Intercept Point:
+19 dBm typ.
DC Offset Voltage:
8 mV typ.
Weight:
0.1 oz (2.8 g)
Operating Temperature: – 55° to +85°C
RRIMAC/ 41 Fairfield Pl., West Caldwell, NJ, 07006 /
F further inform
or
ation contact
ME
973-575-1300
/ FAX
973-575-0531
