© L-com, Inc. 2000 Master Cataog 1.0
106
MODEL
DESCRIPTION
GENDER
1-9
10-24
25-99
Deluxe Series Serial Adaptors - Featuring L-com’s Exclusive Steel Case Design
All of the EIA232 devices shown on this page make use of a proprietary sturdy steel case with heavy nickel
plate. This design not only makes it more compact but also makes the unit almost indestructible and provides
full shielding. All units come with appropriate fastening hardware.
DLMS-2
Data Cabling
Deluxe Data Line Monitor - With Bipolar Red and Green LEDs to Test EIA232 Lines
The DLMS-2 provides the user with the ability to determine the true status of the operating port. When the
Data Line Monitor is inserted between the data terminal and the data transmission equipment, it continuously
monitors and displays the seven most critical lines of the EIA232 data path. The indicators show red for a
positive high and green for a negative low. The monitored lines are: Transmit Data (TD) pin 2, Receive Data
(RD) pin 3, Request to Send (RTS) pin 4, Clear to Send (CTS) pin 5, Data Set Ready (DSR) pin 6, Data Carrier
Detect (DCD) pin 8, and Data Terminal Ready (DTR) pin 20. Each LED circuit draws about 3 ma and
operates in the EIA range of 3.5 to 25 volts. A prime feature is the chrome plated metal enclosure that provides
shielding and has the ability to take extensive abuse.
DAS25M
DLMS-2
Deluxe Data Line Monitor
Male / Female
19.95
18.35
16.76
Deluxe Gender Changers - Are Fully Shielded to Maintain An RFI/EMI Integrity
Gender Changers avoid modifications or replacement of incompatible EIA232 Cables. The all-metal
construction not only provides a shield but is more rugged to withstand handling abuse.
DAS25F
DAS25M
Converts Male Cable to Female
Converts Female Cable to Male
Female / Female
Male / Male
12.95
12.65
11.91
11.64
10.88
10.63
Deluxe Null Modems - Adaptors Make Good Substitutes for Crossover Cables
DAS25D
Our newest Null Modems enable two DTE devices or two DCE devices to communicate in minutes. Just plug
the correct Null Modem between the two devices. Its metal construction provides an effective shield and
withstands abuse. All Null Modems have Male / Female connections for In-Line application.
DAS25R
DAS25A
DAS25B
DAS25C
DAS25D
DAS25H
IBM PC Null Modem
Pins 2 & 3 Reversed
M1
2
3
4
1F
2
3
4
EIA232 Reverser, Pins 2 & 3
Apple to Printer / Terminal
IBM PC to Printer / Terminal
Computer to Terminal with Additional Handshake
Equivalent to DEC #H312A
Equivalent to H.P. #13232U
PC (Apple, etc.) to
printer or terminal
M1
2
3
5
6
8
20
1F
3
2
20
5
6
8
7
12.65
12.65
12.65
12.65
12.65
12.65
Equivalent to
DEC #H312A
M1
2
3
4
5
7
1F
3
2
11.64
11.64
11.64
11.64
11.64
11.64
10.63
10.63
10.63
10.63
10.63
10.63
Equivalent to HP
#13232U
(5061-2403)
M1
2
3
4
5
1F
3
2
IBM PC to
printer/terminal.
M1
2
3
4
8
20
5
6
7
1F
3
2
8
4
5
6
20
7
Computer to term.
with additional
handshaking
M1
2
3
4
5
6
8
20
7
1F
3
2
5
4
20
6
8
7
8
7
DIYS
25
25
8
20
22
6
4
5
22
6
8
4
5
20
7
22
15
12
11
17
8
6
7
22
17
11
12
15
24
20
7
20
DAS25R
DAS25A
DAS25B
DAS25C
DAS25D
DAS25H
6
Do-It-Yourself Kits - Make It Easy to Build Your Own Custom EIA232 Adaptors
The DIYS Series allows the creation of practically any type of EIA232 Adaptor. Choice of three kit models,
depending on gender and whether your needs require shielding. The DB25 connectors have solder cup
terminations to accept soldered wire leads. Each kit comes with the following basics: Two DB25 connectors
(gender specified below), two snap-on half covers (chrome plated metal), and two sets of hardware for the
connector ends. No wires are supplied.
DIYS
DIYS-F
DIYS-M
EIA232 Adaptor Kit, Metal
EIA232 Adaptor Kit, Metal
EIA232 Adaptor Kit, Metal
Male / Female
Female / Female
Male / Male
9.65
9.95
9.25
8.88
9.15
8.51
8.11
8.36
7.77
Data Jumper Box - PCB Simplifies Design of Custom EIA232 Adaptor Assembly
The DJBS Series provides the easiest way to customize EIA232 interface devices. All 25 pins of the DB25
connector terminations are already soldered to the PCB. The board layout, with numbered traces and predrilled
holes, makes it easy to wire your own adaptor. The 25 pre-stripped connection jumpers are supplied, more than
you need to solder for permanent wiring. Many interfaces can be built such as, null modems, pin reversers,
you name it. Metal chrome covers provide shielding and longer useful life. Appropriate hardware is provided
with each unit.
DJBS
DJBS-F
DJBS-M
EIA232 Jumper Box, Metal
EIA232 Jumper Box, Metal
EIA232 Jumper Box, Metal
Male / Female
Female / Female
Male / Male
12.65
12.95
12.75
11.64
11.91
11.73
10.63
10.88
10.71
DJBS
Serial Adaptors
Serial Line Protectors - Ultimate Protection Against Transient Voltages and Spikes
Silicon Avalanche Zener Diodes on each crucial line provide the most reliable protection against transient
voltages to eliminate downtime and equipment damage. Avalanche diodes are faster reacting than MOVs and
are voltage sensitive to provide a more accurate 27V threshold level for your sensitive micro processing
circuits. The eight critical lines protected are as listed. All lines are wired through with pin #1 and shield
grounded. All metal case construction. Male and female connectors for in-line operation.
DLPS8
DLPS8
Protector for DB25 Lines 2, 3, 4, 5, 6, 7, 8 & 20
28.95
27.79
26.63
Order Toll Free:
800-343-1455
Web: www.L-com.com
MON. - THURS. 8am-6pm, FRI. 8am-5pm EST
L-com
N . A N D OV E R , M A 0 1 8 4 5
24 Hour Fax Service:
978-689-9484
E-mail: sales@L-com.com
PRICES AND SPECIFICATIONS SUBJECT TO CHANGE.
