DG909MF1 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> The connector> DG909MF1

DG909MF1: DescriptionRectangular Connector Adapter, 9 Contacts(Side1), 9 Contacts(Side2), Male-Female, ROHS COMPLIANT; CategoryThe connector The connector; File Size160KB，1 Pages; ManufacturerL-com Global Connectivity; Environmental Compliance

Download Datasheet Parametric View All

DG909MF1 Overview

Rectangular Connector Adapter, 9 Contacts(Side1), 9 Contacts(Side2), Male-Female, ROHS COMPLIANT

DG909MF1 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
package instruction	ROHS COMPLIANT
Reach Compliance Code	unknown
ECCN code	EAR99
Connector type	RECTANGULAR CONNECTOR ADAPTER
Contact to complete cooperation	NOT SPECIFIED
Contact point gender	MALE-FEMALE
Contact material	NOT SPECIFIED
DIN compliance	NO
empty shell	NO
Filter function	NO
IEC compliance	NO
MIL compliance	NO
Mixed contacts	NO
触点数量:侧 1	9
触点数量:侧 2	9
Options	GENERAL PURPOSE
Shell material	ACRYLONITRILE BUTADIENE STYRENE
direct connection	NO
Base Number Matches	1

Preview

Download Datasheet

View All

REV

DESCRIPTION

INITIAL RELEASE

ECN# 2731 - ADDED ROHS STAMP

ECN4271: CN RELEASE

REVISIONS

DATE

APPROVED

M.LAHEY

D.GRIFFIN

D. CASTRO

04/01/05

10/23/07

12/21/09

THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE

PROPERTY OF L-COM, INC. ANY REPRODUCTION IN PART OR WHOLE

WITHOUT THE WRITTEN PERMISSION OF L-COM, INC. IS PROHIBITED.

WIRING MAP

"P1"

"J1"

SHELL

MOLDED GRAY

PVC HOOD

(PANTONE 424C)

HARDWARE CONFIGURATIONS

1.00

25.4

2X .20

5.08

1.30

33.02

2X .984

STANDARD HARDWARE CONFIGURATION

"P1"

DB9 MALE

CONNECTOR

PIN 1

2X #4-40

HEX STANDOFF

1.00

25.4

BACK HEX NUTS

2X #4-40 UNC-2A

PIN 1

ALTERNATE HARDWARE CONFIGURATION

2X .149±.010

3.8±0.25

"J1"

DB9 FEMALE

CONNECTOR

RoHS Compliant



UNLESS OTHERWISE SPECIFIED,

DIMENSIONS ARE IN INCHES [mm]

OVERALL CABLE LENGTH TOLERANCE:

≤12 [305] = +1 [25] / -0

>12 [305] ≤60 [1524] = +2 [51] / -0

>60 [1524] ≤120 [3048] = +4 [102] / -0

>120 [3048] ≤300 [7620] = +6 [152] / -0

>300 [7620] = +5% / -0%

ALL OTHER DIMENSIONAL TOLERANCES:

.X = ± .2

.XX = ± .02

.XXX = ±.005

PROJECTION

APPROVALS

DRAWN BY

DATE

04/01/05
