THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE
PROPERTY OF L-COM, INC. ANY REPRODUCTION IN PART OR WHOLE
WITHOUT THE WRITTEN PERMISSION OF L-COM, INC. IS PROHIBITED.
D
1.55
.
D
C
.50
C
1.31
4X .094
B
B
2X 15 PIN FEMALE D-SUB
CONNECTOR
45 BEECHWOOD DRIVE
NORTH ANDOVER, MA
01845
PRODUCT DESCRIPTION
03/18/02
DRAWING TITLE
A
NOTES:
1. CONTACTS: GOLD PLATED BRASS
2. EXPOSED STEEL SURFACES: TIN PLATTED
3. INSULATORS: GLASS FILLED PBT (BLUE)
U.L. RECOGNIZED MATERIAL, 94-V0 RATED.
APPROVALS
DRAWN
MCCORMICK
CHECKED
DATE
DB15 TO D-SUB SLIDE LATCH ADAPTOR
A
03/18/02
D.PARHAM
UNLESS OTHERWISE SPECIFIED, APPROVED BY
DIMENSIONS ARE IN INCHES
TOLERANCES ARE:
03/18/02
R.CARRICK
.X .1
.XX .05
.XXX .005
CONFIGURATION DETAILS OF
UNDIMENSIONED FEATURES
CABLE LENGTH TOLERANCE
MAY VARY
<300" ±5% >300" ±2%
OUTLINE DRAWING
SIZE
SCALE
A
43321
2
FSCM NO.
DWG. NO.
DGCL15F-OD1
SHEET 1
OF
REV.
CAD FILE:
1:1
DGCL15F-OD1.SLDDRW
A
1
8
7
6
5
4
3
1
