DIODE
(THREE PHASES BRIDGE TYPE)
DF60AA120/160
UL;E76102 M
Power Diode Module
DF60AA
is designed for three phase full wave rectification, which
has six diodes connected in a three phase bridge configuration. The mounting base of the
module is electrically isolated from semiconductor elements for simple heatsink
construction Output DC current is 60Amp (Tc=112 ) Repetitive peak reverse voltage is
up to 1,600V.
TjMax=150
Isolated Mounting Base
High reliability by unique glass passivation
Applications
AC. DC Motor Drive/AVR/Switching
for three phase rectification
Unit
a
Maximum Ratings
Symbol
V
RRM
V
RSM
Symbol
I
D
I
FSM
Tj
Tstg
V
ISO
Item
Repetitive Peak Reverse Voltage
Non-Repetitive Peak Reverse Voltage
Item
Output current D.C.
Surge Forward Current
Junction Temperature
Storage Temperature
Isolation Breakdown Voltage R.M.S.
Mounting
Torque
Mass
Mounting M6
Terminal M5
Main Terminal to case 1minute
Recommended Value 2.5 3.9 25 40
Recommended Value 1.5 2.5 15 25
Typical Value
Ratings
DF60AA120
1200
1300
Conditions
Three phase. full wave. T
C
112
1 cycle, 50/60H
Z
, peak value, non-repetitive
DF60AA160
1600
1700
Ratings
60
910/1000
40
150
40
125
2500
4.7 48
2.7 28
200
Tj 25
Unit
V
V
Unit
A
A
V
N m
f
B
g
Electrical Characteristics
Symbol
I
RRM
V
FM
Rth j-c
Item
Repetitive Peak Reverse Current, max.
Forward Voltage Drop, max.
Thermal Impedance, max.
Tj 150
I
FM
60A, Tj 25
Junction to case
Conditions
at V
RRM
Inst. measurement
Ratings
12.0
1.3
0.24
Unit
mA
V
/W
