SanRex
®
Fast &
Soft Recovery Diode
DBA100UA40
I
F(AV)
= 2x50A, V
RRM
=400V, t
rr=
90ns
SanRex
Fast & Soft Recovery Diode Module
DBA100UA40
is designed for applications requiring fast switching and soft
recovery wave shape to reduce or eliminate the need for
snubber components in the circuit. The modules are isolated
for easy mounting with other components or a common heatsink.
Features
* Very Fast Reverse Recovery Time
* Soft Recovery Characteristics
* Low Forward Voltage Drop
* Compact isolated SOT-227 package
Isolated
SOT-227 Package
Typical Applications
* Welding and Plasma Cutting Machines
* DC chopper
* Rectifier in Switch Mode Power Supplies (SMPS)
* Uninterruptible Power Supplies (UPS)
* Free Wheeling Diode in converters and motor control circuits
Internal schematic diagram
< Maximum Ratings >
Symbol
Item
V
RRM
V
R(DC)
I
F(AV)
I
FSM
I
2
t
T
j
T
stg
V
ISO
Repetitive Peak Reverse
Voltage
Reverse D.C. Voltage
Average Forward Current
Surge Forward Current
I
2
t (for fusing)
Junction Temperature
Storage Temperature
Isolation Voltage (R.M.S.)
Mounting Mounting M4
Torque
Terminal M4
Mass
Conditions
Tj = 25 C (unless otherwise noted) per diode
Ratings
Unit
400
320
50
490
1000
-40 to +150
-40 to +125
2500
1.5
1.5
30
V
V
A
A
A
2
s
°C
°C
V
N
·
m
g
°
D.C., T
C
= 99°C
½ cycle, 60Hz, Peak value, non-repetitive
Value for one cycle surge current
A.C. 1 minute
Recommended 1.0-1.4
Recommended 1.0-1.4
Typical Value
SanRex
50 Seaview Blvd. Port Washington, NY 11050-4618 PH.(516)625-1313 FAX(516)625-8845 E-mail: semi@sanrex.com
SanRex
®
Fast & Soft Recovery Diode
< Electrical Characteristics >
Symbol
Item
I
RRM
V
FM
t
rr
°
DBA100UA40
Tj= 25 C (unless otherwise noted) per diode
Ratings
Unit
Min.
Typ. Max.
100
mA
1.10
90
1.20
130
0.85
V
ns
°C/W
Conditions
V
R
= V
RRM,
T
j
= 150°C
I
F
= 50A, Inst. measurement
Repetitive Peak Reverse
Current
Forward Voltage Drop
Reverse Recovery Time
Thermal Resistance
R
th(j-c)
I
F
= 50A, V
R
=200V, -di / dt = 100A/
Fs
Junction to case
* Dimensions in millimeters
