D15SB80: DescriptionBridge Rectifier Diode, 15A, 800V V(RRM),; CategoryDiscrete semiconductor diode; File Size60KB，2 Pages; ManufacturerLRC; Websitehttp://www.lrc.cn

Download Datasheet Parametric Compare View All

D15SB80 Overview

Bridge Rectifier Diode, 15A, 800V V(RRM),

D15SB80 Parametric

Parameter Name	Attribute value
Reach Compliance Code	unknown
Configuration	BRIDGE, 4 ELEMENTS
Diode type	BRIDGE RECTIFIER DIODE
Maximum forward voltage (VF)	1.1 V
Maximum non-repetitive peak forward current	250 A
Number of components	4
Maximum operating temperature	150 °C
Maximum output current	15 A
Maximum repetitive peak reverse voltage	800 V
surface mount	NO
Base Number Matches	1

Preview

Download Datasheet

View All

LESHAN RADIO COMPANY, LTD.

D15SB10 – D15SB100

15A(SIP)

15A(SIP) BRIDGE RECTIFIERS

MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS

Ratings at 25°C ambient temperature unless otherwise specified. Single phase,half wave,

60Hz,resistive or inductive load. For capacitive load,derate current by 20%.

TYPE

Maximum

Peak

Reverse

Voltage

PRV

Maximum

Average

Forward

Output

Current

=70°C

Maximum

Forward Peak

Surge Current

@ 8.3ms

Superimposed

(Surge)

Maximum DC

Forward Voltage

drop per element

at I

=7.5ADC

Maximum DC

Reverse Current

at rated DC

Blocking Voltage

per element

25°CTA

µADC

125°CTA

µADC

Operating

Junction

Temperature

Package

Dimensions

°C

D15SB10

D15SB20

D15SB40

D15SB60

D15SB80

D15SB100

100

200

400

600

800

1000

250

1.1

500

150

D15SB

.142(3.6)

.126(3.2)

1.193(30.3)

1.169(29.7)

.189(4.8)

.173(4.4)

.160(3.8)

.134(3.4)

.779(20.3)

.775(19.7)

.779(20.3)

.776(19.7)

.098(2.5)

.079(2.0)

.043(1.1)

.036(0.9)

.197(5.0)

.441(11.2)

.425(10.8)

.789(18.0)

.669(17.0)

.142(3.6)

.126(3.2)

.709(18.0)

.669(17.0)

.405(10.3)

.382(9.7)

.303(7.7)

.287(7.3)

.032(0.8)

.024(0.6)

D15SB

19C–1/2
