SanRex
ISOLATED DIODE MODULE (SOFT RECOVERY DIODE)
DKA300AA50/60
V
RRM
=500/600V, I
FAV
=150A, t
rr
=230
ns, Softness=0.8
SanRex
Soft Recovery Diode Module
DKA300AA
is designed
for applications requiring fast switching and soft recovery
wave shape to reduce or eliminate the need for snubber
components in the circuit. The modules are isolated for easy
mounting with other components or a common heatsink.
Features
* Very Fast Reverse Recovery Time
* Soft Recovery Characteristics
* Low Forward Voltage Drop
* UL registered E76102
Typical Applications
* Welding and Plasma Cutting Machines
* DC chopper
* Rectifier in Switch Mode Power Supplies (SMPS)
* Uninterruptible Power Supplies (UPS)
* Free Wheeling Diode in converters and motor control circuits
°
< Maximum Ratings >
Symbol
Item
V
RRM
V
R(DC)
Symbol
I
F(AV)
I
FSM
I
2
t
T
j
T
stg
V
ISO
Repetitive Peak Reverse
Voltage
Reverse D.C. Voltage
Item
Average Forward Current
Surge Forward Current
I
2
t (for fusing)
Junction Temperature
Storage Temperature
Isolation Voltage (R.M.S.)
Mounting
Torque
Mass
Mounting M6
Terminal M5
DKA300AA50
500
400
Conditions
D.C., T
C
= 72°C
Ratings
(T
j
= 25 C unless otherwise specified)
Unit
DKA300AA60
600
V
480
Ratings
150
2500
26000
-40 to +150
-40 to +125
2500
4.7(48)
2.7(28)
170
°
V
Unit
A
A
A
2
s
°C
°C
V
Nžm
(kgfžcm)
g
½ cycle, 60Hz, Peak value, non-repetitive
Value for one cycle surge current
A.C. 1 minute
Recommended 2.5-3.9 (25-40)
Recommended 1.5-2.5 (15-25)
Typical Value
< Electrical Characteristics >
Symbol
Item
I
RRM
V
FM
t
rr
Repetitive Peak Reverse
Current
Forward Voltage Drop
Reverse Recovery Time
Conditions
V
R
= V
RRM,
T
j
= 125°C
I
F
= 150A, Inst. Measurement
(T
j
= 25 C unless otherwise specified)
Ratings
Unit
Min.
Typ. Max.
150
mA
1.18
230
1.30
300
V
Ns
I
F
= 150A, V
R
=300V, -di / dt = 100A/
Fs
t
b
/ t
a
Softness
0.80
I
F
= 150A, V
R
=300V, -di / dt = 100A/
Fs
R
th(j-c)
Thermal Resistance
Junction to case, ½ module
0.40
°C/W
_________________________________________________________________________________________________________
SanRex
50 Seaview Blvd. Port Washington, NY 11050-4618 PH.(516)625-1313 FAX(516)625-8845 E-mail: semi@sanrex.com
