DA0218LR5: DescriptionDouble Balanced Mixer, 2000MHz Min, 18000MHz Max, HERMETIC SEALED PACKAGE; CategoryWireless rf/communication Radio frequency and microwave; File Size54KB，2 Pages; ManufacturerMITEQ Inc

Download Datasheet Parametric View All

DA0218LR5 Overview

Double Balanced Mixer, 2000MHz Min, 18000MHz Max, HERMETIC SEALED PACKAGE

DA0218LR5 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Reach Compliance Code	unknown
Other features	SMA-F, LOW NOISE
Characteristic impedance	50 Ω
structure	COAXIAL
Maximum operating frequency	18000 MHz
Minimum operating frequency	2000 MHz
Maximum operating temperature	85 °C
Minimum operating temperature	-54 °C
RF/Microwave Device Types	DOUBLE BALANCED
Maximum voltage standing wave ratio	2
Base Number Matches	1

Preview

Download Datasheet

View All

2 TO 18 GHz MIXER/IF AMPLIFIER

MODEL: DA0218LR5

FEATURES

• Double-balanced mixer

with integrated IF amplifier

• RF/LO coverage ................... 2 to 18 GHz

• IF operation .......................... 10 to 250 MHz

• LO power range ................... +10 to +13 dBm

• Packaging............................. Hermetically sealed

MITEQ’s DA Series combines our double-balanced mixer with a low noise IF amplifier to provide an integrated con-

verter module. This design is particularly well suited to broadband downconverter receiver applications such as ESM

and ELINT systems or test equipment applications requiring flat RF to IF amplitude and phase characteristics (e.g.,

FMCW or narrow pulse systems).

MIXER PRODUCTS

ELECTRICAL SPECIFICATIONS

INPUT PARAMETERS

RF frequency range

RF VSWR

LO frequency range

LO power range

LO VSWR

DC bias

TRANSFER CHARACTERISTICS

Conversion gain

Single-sideband noise figure

LO-to-RF isolation

LO-to-IF isolation

RF-to-IF isolation

Output power at 1 dB compression

OUTPUT PARAMETERS

IF frequency range

IF VSWR

CONDITION

50 ohm reference

+12 volts

CONDITION

50 ohm reference

CONDITION

UNITS

GHz

Ratio

GHz

dBm

Ratio

UNITS

dBm

UNITS

MHz

Ratio

MIN.

TYP.

2:1

MAX.

250

MIN.

+10

2.5:1

TYP.

9.5

MAX.

MIN.

2.5:1

+13

TYP.

MAX.

100 Davids Drive, Hauppauge, NY 11788 • TEL: (631) 436-7400 • FAX: (631) 436-7430 •

www.miteq.com
