DAT-15R5-SN+K datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Wireless rf/communication> Radio frequency and microwave> DAT-15R5-SN+K

DAT-15R5-SN+K: DescriptionRF/Microwave Attenuator, CMOS; CategoryWireless rf/communication Radio frequency and microwave; File Size593KB，12 Pages; ManufacturerMini-Circuits; Websitehttps://www.minicircuits.com; Environmental Compliance

Download Datasheet Parametric Compare View All

DAT-15R5-SN+K Overview

RF/Microwave Attenuator, CMOS

DAT-15R5-SN+K Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
package instruction	LCC20,.16SQ,20
Reach Compliance Code	unknown
JESD-609 code	e3
Installation features	SURFACE MOUNT
Number of terminals	20
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Package body material	PLASTIC/EPOXY
Encapsulate equivalent code	LCC20,.16SQ,20
power supply	+-3 V
Maximum slew rate	0.1 mA
surface mount	YES
technology	CMOS
Terminal surface	Tin (Sn)
Base Number Matches	1

Preview

Download Datasheet

View All

DAT-15R5-SN+K Related Products

	DAT-15R5-SN+K	2KDAT-15R5-SNT	2KDAT-15R5-SNT+	1KDAT-15R5-SNK	1KDAT-15R5-SNK+	DAT-15R5-SNK	DAT-15R5-SNE+	DAT-15R5-SNPR+
Description	RF/Microwave Attenuator, CMOS	Variable Attenuator, 0MHz Min, 4000MHz Max, 4.7dB Insertion Loss-Max, 4 X 4 MM, DG983-1, 20 PIN	Variable Attenuator, 0MHz Min, 4000MHz Max, 4.7dB Insertion Loss-Max, 4 X 4 MM, ROHS COMPLIANT, DG983-1, 20 PIN	Variable Attenuator, 0MHz Min, 4000MHz Max, 4.7dB Insertion Loss-Max, 4 X 4 MM, DG983-1, 20 PIN	Variable Attenuator, 0MHz Min, 4000MHz Max, 4.7dB Insertion Loss-Max, 4 X 4 MM, ROHS COMPLIANT, DG983-1, 20 PIN	RF/Microwave Attenuator, CMOS	Variable Attenuator, 0MHz Min, 4000MHz Max, 4.7dB Insertion Loss-Max, 4 X 4 MM, ROHS COMPLIANT, DG983-1, 20 PIN	Variable Attenuator, 0MHz Min, 4000MHz Max, 4.7dB Insertion Loss-Max, 4 X 4 MM, ROHS COMPLIANT, DG983-1, 20 PIN
Is it Rohs certified?	conform to	incompatible	conform to	incompatible	conform to	incompatible	conform to	conform to
Reach Compliance Code	unknown	unknow	unknow	unknown	unknown	unknown	unknown	unknown
Maximum operating temperature	85 °C	85 °C	85 °C	85 °C	85 °C	85 °C	85 °C	85 °C
Minimum operating temperature	-40 °C	-40 °C	-40 °C	-40 °C	-40 °C	-40 °C	-40 °C	-40 °C
JESD-609 code	e3	e0	-	e0	-	-	e3	e3
Terminal surface	Tin (Sn)	Tin/Lead (Sn/Pb)	-	Tin/Lead (Sn/Pb)	-	-	Tin (Sn)	Tin (Sn)
Base Number Matches	1	1	1	1	1	1	-	-
Other features	-	CMOS COMPATIBLE	CMOS COMPATIBLE	CMOS COMPATIBLE	CMOS COMPATIBLE	-	CMOS COMPATIBLE	CMOS COMPATIBLE
Nominal attenuation	-	15.5 dB	15.5 dB	15.5 dB	15.5 dB	-	15.5 dB	15.5 dB
Characteristic impedance	-	50 Ω	50 Ω	50 Ω	50 Ω	-	50 Ω	50 Ω
structure	-	COMPONENT	COMPONENT	COMPONENT	COMPONENT	-	COMPONENT	COMPONENT
Maximum input power (CW)	-	23.98 dBm	23.98 dBm	23.98 dBm	23.98 dBm	-	23.98 dBm	23.98 dBm
Maximum insertion loss	-	4.7 dB	4.7 dB	4.7 dB	4.7 dB	-	4.7 dB	4.7 dB
Maximum operating frequency	-	4000 MHz	4000 MHz	4000 MHz	4000 MHz	-	4000 MHz	4000 MHz
RF/Microwave Device Types	-	VARIABLE ATTENUATOR	VARIABLE ATTENUATOR	VARIABLE ATTENUATOR	VARIABLE ATTENUATOR	-	VARIABLE ATTENUATOR	VARIABLE ATTENUATOR
Maximum voltage standing wave ratio	-	2.1	2.1	2.1	2.1	-	2.1	2.1
