DMF-12A Series
DO
UBLEBALANC D MIXE S
E
R
500 kHz to 2 G / +20 to +27 dBmLO/ +28 dBmThird O Intercept / Flatpack
Hz
rder
PRINCIPAL SPECIFICATIONS
Model
Number
DMF-12A-250
RF/LO
Frequency,
MHz
0.5 - 500
IF
Frequency,
MHz
DC - 500
Operating
Range,
MHz
0.5 - 1
1 - 300
300 - 500
10 - 50
50 - 500
500 -1000
10 - 600
600 -1000
1000 -1500
500 - 2000
Conversion
Loss, dB,
Max. Typ.
8.0
7.0
7.0
6.0
8.0
7.0
7.5
6.5
7.5
6.5
8.5
7.5
8.0
7.0
8.0
7.0
9.5
8.5
8.0
6.0
Port Isolation, Min.
L-R
L-X
R-X Polarity
dB
dB .
dB
Sense
40
30
23
Pos.
40
30
23
35
20
20
35
30
25
Pos.
30
25
20
25
15
15
30
20
15
Neg.
20
12
15
20
12
8
25
20
15
Neg.
DMF-12A-500
10 - 1000
DC - 1000
DMF-12A-700
10 - 1500
DC - 1000
DMF-12A-1700
500 - 2000
DC - 1000
All specifications are as measured in a 50Ω system, at nominal LO power, in a down converter application.
Package Outline
GENERAL SPECIFICATIONS
LO Drive:
Impedance:
Noise Figure:
+24 dBm nom.
50
Ω
nom.
Within
±1
dB of
Conversion Loss
1 dB Comp. Point:
+16 dBm input typ.
Input Intercept Point:
+28 dBm typ.
Maximum Input Power: 900 mW @ 25°C
(derate linearly to 0 mW @ 125°C)
NOTES:
1. Tolerance on 3 place decimals .010(.25) except as noted.
2. Dimensions in inches over millimeters.
3. Dimensions marked with * apply only at body.
4. All unmarked pins are case ground.
DC Offset Voltage:
8 mV typ.
Weight:
0.1 oz (2.8 g)
Operating Temperature: – 55° to +85°C
General Notes:
1. The DMF-12A series of Double Balanced Mixers covers the frequency range of of 0.5 to 2000 MHz using a 12 diode ring modulator to produce
an extremely high level mixer with high third order intercept points.
2. Merrimac offers a broad selection of Double Balanced Mixers ideal for a variety of signal processing functions with frequencies ranging from
20 kHz to 20 GHz.
3. Merrimac mixers comply with MIL-M-28837 and may be supplied screened for compliance with additional specifications for military and space
applications requiring the highest reliability.
29Apr96
