DPX315950DT-5004A1 datasheet, PDF

EEWORLDEEWORLD

Datasheet

Datasheet> All Categories > Analog mixed-signal IC> filter> DPX315950DT-5004A1

Preview

DPX315950DT-5004A1: DescriptionDuplexer; CategoryAnalog mixed-signal IC filter; File Size50KB，3 Pages; ManufacturerTDK Corporation; Websitehttp://www.tdk.com

Download Datasheet Parametric View All

DPX315950DT-5004A1 Overview

Duplexer

DPX315950DT-5004A1 Parametric

Parameter Name	Attribute value
Reach Compliance Code	unknown
filter type	DUPLEXER
high	1.3 mm
Insertion loss (receive)	0.85 dB
Insertion loss (transmit)	1.4 dB
length	3.2 mm
Manufacturer's serial number	DPX315950DT-5004A1
Installation type	SURFACE MOUNT
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
physical size	L3.2XB1.6XH1.3 (mm)
width	1.6 mm
Base Number Matches	1

Preview

Download Datasheet

View All

Jun. /2003 Ver.5

TDK Corporation

3216 TYPE MULTILAYER DIPLEXER FOR 2.4GHz 5GHz W-LAN

P/N

:

DPX315950DT-5004A1

3.2+/-0.2

7

6

1.3+/-0.1

[MECHANICAL DIMENSIONS]

8

5

1.6+/-0.2

MARK

1

2

3

4

0.15min.

0.4+/-0.15 0.8+/-0.1 0.8+/-0.1

UNIT: mm

1. LOW (2.4GHz)

2. GND

3. GND

4. HIGH (5.0GHz)

5. GND

6. GND

7. ANT (COMMON)

8. GND

[ELECTRICAL CHARACTERISTICS]

No. PARAMETER

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

Insertion loss (25±5 C )

Insertion loss (-40 to +85 C )

Insertion loss (25±5 C )

Insertion loss (-40 to +85 C )

Attenuation

Return Loss

Operating temperature

Storage temperature

o

PORT

ANT-LOW

ANT-HIGH

ANT-LOW

ANT-HIGH

ANT

LOW

HIGH

FREQ (MHz)

2300-2500

4900-5950

4600-5000

6900-7500

2300-2500

9800-10700

10700-11700

11700-11900

2300-2500

4900-5950

2300-2500

4900-5950

MIN

-

25

18

30

15

10

-

10

9

10

9

-40

TYP

0.55

-

0.7

-

29

25

38

25

22

20

15

13

15

13

+85

MAX

0.7

0.85

1.2

1.4

-

o

UNIT

dB

C

*Note: This document is PRELIMINARY. All specifications are subject to change without notice and are not guaranteed.
