DBTC-1-13/15-16-LC-9L-1 datasheet, PDF

Datasheet> All Categories > Wireless rf/communication> Optical fiber> DBTC-1-13/15-16-LC-9L-1

DBTC-1-13/15-16-LC-9L-1: DescriptionSplitter/Coupler, 1270nm Min, 1350nm Max, 1X16 Port, LC/SPC Connector,; CategoryWireless rf/communication Optical fiber; File Size282KB，1 Pages; ManufacturerDicon Fiberoptics Inc; Websitehttp://www.diconfiberoptics.com

Download Datasheet Parametric View All

DBTC-1-13/15-16-LC-9L-1 Overview

Splitter/Coupler, 1270nm Min, 1350nm Max, 1X16 Port, LC/SPC Connector,

DBTC-1-13/15-16-LC-9L-1 Parametric

Parameter Name	Attribute value
Reach Compliance Code	unknown
Other features	IT ALSO OPERATES FROM 1510 TO 1590NM
body width	50 mm
body height	8 mm
Body length or diameter	100 mm
Communication standards	GR-1221
Connection Type	LC/SPC CONNECTOR
Fiber optic equipment types	SPLITTER/COUPLER
Maximum insertion loss	15.5 dB
Maximum operating wavelength	1350 nm
Minimum operating wavelength	1270 nm
Nominal operating wavelength	1310 nm
Port configuration	1X16
Base Number Matches	1

Preview

Download Datasheet

View All

Dual Window Broadband 1xN Coupler

DiCon’s Dual Window Broadband 1xN Couplers are designed for

splitting power signals in the 1550 nm and 1310 nm windows.

DiCon’s Dual Window Broadband 1xN couplers have excellent

uniformity, low excess loss, and low PDL.

Specifications

Directivity

Back-reflection

Fiber type

Operating temperature

Storage temperature

50 dB min.

-50 dB max.

9/125 Corning SMF-28

-40

C to + 70

-40

C to + 85

Ordering Information

DBTC -

Grade

Premium

Standard

1270 - 1350 nm &

1510 - 1590 nm

Specify value

1. All specifications referenced without connectors.

Passband

13/15

Coupling Ratio Table

Insertion loss

Premium Standard

1x4

1x8

1x16

1x32

7.3

10.8

14.4

18.2

7.7

11.5

15.5

19.5

Uniformity

PDL

Premium Standard Premium Standard

1.6

2.4

3.2

4.0

2.1

3.1

3.7

4.5

0.2

0.3

0.4

0.5

0.3

0.4

0.5

0.6

Port Configuration

1x4

1x8

1x16

1x32

Connector Type

FC/APC

FC/UPC

SC/APC

SC/UPC

ST/UPC

LC/UPC

MU/UPC

FC/SPC

FC/APC

FC/UPC

SC/SPC

SC/APC

SC/UPC

ST/SPC

ST/UPC

LC/SPC

LC/UPC

MU/UPC

None

250 micron, 200 kpsi bare fiber

900 micron, loose tube

1 meter

Specify X meters

Housing Dimensions

Features

Preliminary Datasheet

•

Low insertion loss

Low PDL

Low wavelength dependence loss

Tested to Telecordia GR-1221 (bare fiber version)

Fiber Jacket

Applications

DiCon’s Dual Window Broadband 1xN Couplers are designed for

use in telecommunication equipment, CATV networks, and test

equipment.

Pigtail Length

Units: mm

DiCon Fiberoptics, Inc. 1689 Regatta Blvd. Richmond, CA 94804

Tel. (510)620-5000

Fax. (510)620-4100

www.diconfiber.com

0065A

Fused Fiber Couplers

Dual Window Broadband 1xN Coupler

Fused Fiber Couplers
