DDZX16TS-13 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> diode> DDZX16TS-13

DDZX16TS-13: DescriptionZener Diode, 16V V(Z), 2.55%, 0.2W, Silicon, Unidirectional, ROHS COMPLIANT, PLASTIC PACKAGE-6; CategoryDiscrete semiconductor diode; File Size162KB，6 Pages; ManufacturerDiodes Incorporated; Environmental Compliance

Download Datasheet Parametric View All

DDZX16TS-13 Overview

Zener Diode, 16V V(Z), 2.55%, 0.2W, Silicon, Unidirectional, ROHS COMPLIANT, PLASTIC PACKAGE-6

DDZX16TS-13 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
package instruction	R-PDSO-G6
Contacts	6
Reach Compliance Code	unknown
ECCN code	EAR99
Other features	LOW LEAKAGE CURRENT
Configuration	SEPARATE, 3 ELEMENTS
Diode component materials	SILICON
Diode type	ZENER DIODE
JESD-30 code	R-PDSO-G6
JESD-609 code	e3
Humidity sensitivity level	1
Number of components	3
Number of terminals	6
Maximum operating temperature	150 °C
Minimum operating temperature	-65 °C
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	260
polarity	UNIDIRECTIONAL
Maximum power dissipation	0.2 W
Certification status	Not Qualified
Nominal reference voltage	16 V
surface mount	YES
technology	ZENER
Terminal surface	MATTE TIN
Terminal form	GULL WING
Terminal location	DUAL
Maximum time at peak reflow temperature	40
Maximum voltage tolerance	2.55%
Working test current	10 mA
Base Number Matches	1

Preview

Download Datasheet

View All

Lead-free

DDZX5V1BTS - DDZX43TS

TRIPLE SURFACE MOUNT PRECISION ZENER

DIODE ARRAY

Features

Very Sharp Breakdown Characteristics

Very Tight Tolerance on V

Ideally Suited for Automated Assembly Processes

Very Low Leakage Current

Lead Free By Design/RoHS Compliant (Note 7)

SOT-363

Dim

Min

0.10

1.15

2.00

0.30

1.80

0.90

0.25

0.10

0°

Max

0.30

1.35

2.20

0.40

2.20

0.10

1.00

0.40

0.25

8°

KXX

B C

Mechanical Data

Case: SOT-363

Case Material: Molded Plastic. UL Flammability

Classification Rating 94V-0

Moisture sensitivity: Level 1 per J-STD-020C

Terminals: Finish - Matte Tin annealed over Alloy 42

leadframe. Solderable per MIL-STD-202, Method 208

Orientation: See Diagram

Marking & Type Code Information: See Electrical

Specifications Table

Ordering Information: See Last Page

Weight: 0.006 grams (approximate)

@ T

= 25°C unless otherwise specified

0.65 Nominal

TOP VIEW

All Dimensions in mm

Maximum Ratings

Forward Voltage

Characteristic

@ I

= 10mA

Operating and Storage Temperature Range

Symbol

STG

Value

0.9

-65 to +150

Unit

°C

Thermal Characteristics

Characteristic

Power Dissipation (Note 1)

@ T

= 25°C unless otherwise specified

Symbol

qJA

Value

200

625

Unit

°C/W

Thermal Resistance, Junction to Ambient Air (Note 1)

Notes:

1. Device mounted on FR-4 PC board with recommended pad layout, which can be found on our web at

http://www.diodes.com/datasheets/ap02001.pdf.

DS30416 Rev. 6 - 2

1 of 6

www.diodes.com

DDZX5V1BTS - DDZX43TS

Diodes Incorporated
