REVISION N
DO NOT
SCALE FROM
THIS PRINT
PATENT NUMBERS
6979238 / 7137832
6969286 / 7178232
7159312 / 7172438
7052337 / 7125293
-04,
DPAM-XX-XX.X-X-X-X-XX
No OF POSITIONS
-06, -08, -15, -23, *** -30
(PER ROW)
LEAD STYLE
-07.0: (SEE TABLE 3)
*-09.0: (SEE TABLE 6, SHT3)
-11.0: (SEE TABLE 6, SHT3)
-14.0: (SEE TABLE 6, SHT3)
*-17.0: (SEE TABLE 6, SHT3)
PLATING SPECIFICATION
**-H: 30µ" GOLD IN CONTACT
AREA, MATT TIN ON TAIL
-S: 30µ" GOLD IN CONTACT
AREA, MATTE TIN ON TAIL.
.037 0.94 REF
.100 2.54
REF (TYP)
OPTION
-A: ALIGNMENT PIN
(SEE FIG. 3, SHT 4)
-K: KAPTON PAD
(SEE FIG. 4, SHT 4)
-TR: TAPE & REEL
(LEAVE BLANK FOR TRAYS)
*** -GP: GUIDE POST
(SEE FIG. 5, SHT 5)
(ONLY AVAILABE WITH -07.0
LEAD STYLE)
SOLDER CRIMP MATERIAL C
-1: 63%TIN/37%LEAD
(USE SUB-T-1M26-07.0-X-01 OR
USE SUB-T-1M32-XX.X-X-1)
-2: 96.5% TIN/3.5% SILVER
(USE SUB-T-1M26-07.0-X-02 OR
USE SUB-T-1M32-XX.X-X-2)
ROW
-8: 8 DIFFERENTIAL PAIR ROWS
-3: 3 DIFFERENTIAL PAIR ROWS
DPAM-23-07.0-X-8-X SHOWN
(SOME CENTER FEATURES REMOVED FOR CLARITY)
"A" REF
.107 2.71 REF
.0425 1.080
C
"C" SPCS @ .085 = "D"
C
FIG 1
.085 2.16 (TYP) C
G1
(Ground Pin)
"A"
G3
"G" REF
"F" REF
* = NOT TOOLED
= ONLY AVAILABLE WITH -07.0 LEAD STYLE
= ONLY AVAILABLE IN 3 ROW WITH -07.0 LEAD
STYLE & 23 POSITIONS
** = FOR EXISTING CUSTOMER ONLY
*** = NOT RELEASED FOR PRODUCTION
.100 2.54
REF
PIN 2 (PAIR 1)
PIN 1 (PAIR 1)
G2
PIN 4 (PAIR 2)
PIN 3 (PAIR 2)
"B" REF
"A"
'B'
DPAM-XX-070.0-X
.262 6.65 REF
(SEE NOTE 6)
C .085 2.16 (TYP)
C
.043 1.08
'C'
C
"E" (TYP)
UNLESS OTHERWISE SPECIFIED,
DIMENSIONS ARE IN INCHES.
TOLERANCES ARE:
DECIMALS
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
NOTES:
(SEE SHEET 2 FOR BOTTOM VIEW)
1.
C
REPRESENTS A CRITICAL DIMENSION.
2. MINIMUM PUSHOUT FORCE: .5 LBS.
3. PARTS PACKAGED IN TRAYS IF -TR OPTION IS NOT SELECTED
4. SOLDER CRIMP LOCATION MUST BE VERIFIED ON 6 CONSECUTIVE PINS.
5. SEE RECOMMENDED FOOTPRINT DRAWING FOR STENCIL REQUIREMENTS.
6. MEASURE ON ALL 4 CORNERS OF THE ASSEMBLY, INCLUDING ADJACENT ROW.
7. DIMENSION TO BE CHECKED AT TIPS
.XX: .01 [.3]
2
.XXX: .005 [.13]
.XXXX: .0020 [.050]
ANGLES
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail info@SAMTEC.com
code 55322
DESCRIPTION:
DWG. NO.
MATERIAL:
INSULATOR: L.C.P., COLOR: BLACK
TERMINAL: COPPER ALLOY
DO NOT SCALE DRAWING
SHEET SCALE: 2:1
.085 PITCH DP TERMINAL ASSEMBLY
DPAM-XX-XX.X-X-X-X-XX
6/3/2003
SHEET
1
OF
5
F:\DWG\MISC\MKTG\DPAM-XX-XX.X-X-X-X-XX-MKT.SLDDRW
BY:
CHAD F
REVISION N
C
.054
+.0070
1.37
+0.18
- .0050
- 0.13
(SEE NOTE 7)
'D'
.007 0.18 REF
.025 0.62 REF
SUB-T-1M26-07.0-X-XX
.034 0.85 REF (TYP)
C
(BOTTOM VIEW PROJECTED FROM SHEET 1)
(SOME CENTER FEATURES REMOVED FOR CLARITY)
SECTION "A"-"A"
SCALE 4 : 1
C
L
C
L
.058±.005 1.48±0.13 (TYP)
C
C
.002
+.001
0.05
+0.03
- .002
- 0.05
C
.0045±.0020 0.114±0.051
(SEE NOTE 6)
.002 0.05 REF
C
(SEE NOTE 7)
(ALL TERMINALS NOT
SHOWN FOR CLARITY)
DETAIL 'C'
SCALE 8 : 1
.010 [0.25]
.029 0.74
REF (TYP)
DETAIL 'B'
SCALE 4 : 1
.089 2.26
DETAIL 'D'
SCALE 10 : 1
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail info@SAMTEC.com
code 55322
DESCRIPTION:
DWG. NO.
DO NOT SCALE DRAWING
SHEET SCALE: 2:1
.085 PITCH DP TERMINAL ASSEMBLY
F:\DWG\MISC\MKTG\DPAM-XX-XX.X-X-X-X-XX-MKT.SLDDRW
BY:
CHAD F
DPAM-XX-XX.X-X-X-X-XX
6/3/2003
SHEET
2
OF
5
REVISION N
"A" REF
"D"
.0425 1.080
C
C
C
.002 0.05
(SEE NOTE 7)
C
.085 2.16 (TYP)
G1
(Ground Pin)
G3
.006±.003 0.15±0.08
(SEE NOTE 6)
"E"
C
(ALL TERMINALS NOT
SHOWN FOR CLARITY)
.100 2.54
REF (TYP)
DETAIL 'G'
SCALE 8 : 1
DETAIL 'F'
SCALE 8 : 1
C
"H" REF
"F" REF
.006 0.15 REF
.008 [0.20]
C
PIN 4 (PAIR 2)
PIN 2 (PAIR 1)1)
PIN 1 (PAIR
G2
PIN 3 (PAIR 2)
"E"
DPAM-23-14.0-X-8-X SHOWN
-09.0 THRU -17.0 LEAD STYLE
(SAME AS FIG1, EXCEPT AS SHOWN)
(SOME CENTER FEATURES REMOVED FOR CLARITY)
"B" REF
FIG 2
DETAIL 'H'
SCALE 4 : 1
.026 0.66
REF (TYP)
DPAM-XX-00.1-X-X
C
.054
+.007
1.37
+0.18
- .004
- 0.10
.018 0.45 REF
'F'
C
"J"
(SEE NOTE 6)
.035 0.90 REF
SUB-T-1M32-XX.X-X-X
C
C
.085 2.16
.043 1.08
'G'
C
'H'
"E"
DPAM-S-XX-XX.X-X-X
.034 0.86 REF (TYP)
.058±.005 1.47±0.13 (TYP)
C
SECTION "E"-"E"
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail info@SAMTEC.com
code 55322
DESCRIPTION:
DWG. NO.
DO NOT SCALE DRAWING
SHEET SCALE: 2:1
.085 PITCH DP TERMINAL ASSEMBLY
F:\DWG\MISC\MKTG\DPAM-XX-XX.X-X-X-X-XX-MKT.SLDDRW
BY:
CHAD F
DPAM-XX-XX.X-X-X-X-XX
6/3/2003
SHEET
3
OF
5
REVISION N
DPAM-23-07.0-X-8-1-A SHOWN
(SAME AS FIG 1, EXCEPT AS SHOWN)
(SOME CENTER FEATURES REMOVED FOR CLARITY)
.045 1.14 REF (TYP)
FIG 3
.044 1.12 REF
"K" REF
.034 0.86 REF
.044 1.12 REF
"L" REF
DPAM-23-07.0-X-8-X-A-K SHOWN
(SAME AS FIG 1, EXCEPT AS SHOWN)
(SOME CENTER FEATURES REMOVED FOR CLARITY)
FIG 4
"Q"
.020[0.51]
"P"
(INCL. K-DOT)
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail info@SAMTEC.com
code 55322
DESCRIPTION:
DWG. NO.
DO NOT SCALE DRAWING
"N"
.020 [0.51]
"M"
K-1000-800
F:\DWG\MISC\MKTG\DPAM-XX-XX.X-X-X-X-XX-MKT.SLDDRW
.085 PITCH DP TERMINAL ASSEMBLY
SHEET SCALE: 2:1
BY:
CHAD F
DPAM-XX-XX.X-X-X-X-XX
6/3/2003
SHEET
4
OF
5
REVISION N
*** DPAM-23-07.0-X-3-X-A-GP SHOWN
(ONLY AVAILABLE ON 3 ROW, 23 POSITIONS)
(SAME AS FIG 1, EXCEPT AS SHOWN)
(SOME CENTER FEATURES REMOVED FOR CLARITY)
*** = NOT RELEASED FOR PRODUCTION
FIG 5
"F"
"F"
2 MAX SWAY
(TYP)
T-1R34-XX-T
DPAM-XX-070.0-X-A-GP
.120 3.05 REF
.480 12.19
REF
.300 7.62 REF
.081 2.06
C
SECTION "F"-"F"
.062 1.57 REF
C
2.500±.002 63.50±0.05
.215 5.46 REF
2.690 68.33 REF
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail info@SAMTEC.com
code 55322
DESCRIPTION:
DWG. NO.
DO NOT SCALE DRAWING
SHEET SCALE: 2:1
.085 PITCH DP TERMINAL ASSEMBLY
F:\DWG\MISC\MKTG\DPAM-XX-XX.X-X-X-X-XX-MKT.SLDDRW
BY:
CHAD F
DPAM-XX-XX.X-X-X-X-XX
6/3/2003
SHEET
5
OF
5
