P600A THRU P600M
PLASTIC SILICON RECTIFIERS
Reverse Voltage - 50 to 1000 V
Forward Current - 6 A
Features
• Low forward voltage
• High current capability
• High reliability
• High forward surge current capability
Mechanical Data
•
Case:
Molded plastic, R-6
•
Epoxy:
UL 94V-0 rate flame retardant
•
Lead:
Axial leads, solderable per MIL-STD -202,
method 208 guaranteed
•
Polarity:
Color band denotes cathode
•
Mounting Position:
Any
Maximum Ratings and Electrical Characteristics
Ratings at 25
O
C ambient temperature unless otherwise specified. Single phase, half wave, 60 Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
Parameter
Symbols
P600A P600B P600D P600G P600J P600K P600M Units
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Rectified Current at
0.375" (9.5 mm) Lead Length, T
A
= 60
O
C
Peak Forward Surge Current 8.3 ms Single Half
Sine-Wave Superimposed on Rated Load
(JEDEC Method)
Maximum Forward Voltage at 6 A
Maximum Reverse Current
at Rated DC Blocking Voltage
Typical Junction Capacitance
1)
Typical Thermal Resistance
2)
Operating and Storage Temperature Range
1)
2)
V
RRM
V
RMS
V
DC
I
F(AV)
I
FSM
V
F
50
35
50
100
70
100
200
140
200
400
280
400
600
420
600
800
560
800
1000
700
1000
V
V
V
A
6
400
1
A
V
µA
pF
O
at T
A
= 25
O
C
at T
A
= 100
O
C
I
R
C
J
R
θJA
T
J
,T
S
5
1000
150
10
- 55 to + 150
C/W
O
C
Measured at 1 MHz and applied reverse voltage of 4 V D.C.
Thermal resistance from junction to ambient at 0.375" (9.5 mm) lead length P.C.B. Mounted with 1.1 X 1.1 (30 X 30 mm) copper pads.
SEMTECH ELECTRONICS LTD.
(Subsidiary
of Sino-Tech International Holdings Limited, a company
listed on the Hong Kong Stock Exchange, Stock Code: 724)
®
Dated :21/03/2008 H
