PE76D Series 3.3 V
PECL Clock Oscillators
January 2008
This device is obsolete, January 2008
This is replaced by the PE96xxDV device
For new designs use the PE99xxDV device
• Pletronics’ PE76D Series is a quartz crystal
controlled precision square wave generator with a
PECL output.
• FR4 base with a mechanical metal cover.
• Solder pad compatible with many 9x14mm plastic
J lead packages.
• Has internal bypass capacitor on the Vcc lead
• Tape and Reel or cut tape packaging is available.
• 40 to 250 MHz
• 9.04mm x 8.91mm (S package)
• Enable/Disable Function on pad 1
(see PE78D for E/D on pad 2)
• Disable function includes low standby power
mode
• 3
rd
Overtone Crystals used
• Low Jitter
• 5x7 mm LCC ceramic oscillator inside
Pletronics Inc. certifies this device is in accordance with the
RoHS 5/6 (2002/95/EC) and WEEE (2002/96/EC) directives.
Pletronics Inc. guarantees the device does not contain the following:
Cadmium, Hexavalent Chromium, Lead, Mercury, PBB’s, PBDE’s
Weight of the Device: 0.4 grams
Moisture Sensitivity Level: 1 As defined in J-STD-020C
Second Level Interconnect code: e4
Absolute Maximum Ratings:
Parameter
V
CC
Supply Voltage
Vi
Vo
Input Voltage
Output Voltage
Unit
-0.5V to +7.0V
-0.5V to V
CC
+ 0.5V
-0.5V to V
CC
+ 0.5V
Thermal Characteristics
The maximum die or junction temperature is 155
o
C
The thermal resistance junction to board is 60 to 100
o
C/Watt depending on the solder pads, ground plane
and construction of the PCB.
Product information is current as of publication date. The product conforms
to specifications per the terms of the Pletronics standard warranty. Production
processsing does not necessarily include testing of all parameters.
Copyright © 2006, 2007, 2008 Pletronics Inc.
PE76D Series 3.3 V
PECL Clock Oscillators
January 2008
Part Number:
PE76
45
D
E
V
-125.0M
-XX
Packaging code or blank
T250 = 250 per Tape and Reel
T500 = 500 per Tape and Reel
T1K = 1000 per Tape and Reel
Frequency in MHz
Supply Voltage V
CC
V
= 3.3V _ 10%
+
Optional Enhanced OTR
Blank
= Temp. range -10 to +70
o
C
E
= Temp. range -40 to +85
o
C
Series Model
Frequency Stability
45
= + 50 ppm
_
44
= + 25 ppm
_
20
= + 20 ppm
_
Series Model
Marking Legend:
PLE = Pletronics
FF.FFF
M = Frequency in MHz
YYWW or YWW or
YMD
= Date of Manufacture (year and week, or year-month-day)
All other marking is internal factory codes
Specifications such as frequency stability, supply voltage and operating temperature range, etc. are
not identified from the marking. External packaging labels and packing list will correctly identify the
ordered Pletronics part number.
Codes for Date Code YMD
Code
Year
Code
Month
Code
Day
Code
Day
Code
Day
1
1
D
13
T
25
6
2006
A
JAN
2
2
E
14
U
26
7
2007
B
FEB
3
3
F
15
V
27
8
2008
C
MAR
4
4
G
16
W
28
9
2009
D
APR
E
MAY
5
5
H
17
X
29
0
2010
F
JUN
6
6
J
18
Y
30
1
2011
G
JUL
7
7
K
19
Z
31
H
AUG
8
8
L
20
2
2012
J
SEP
9
9
M
21
K
OCT
A
10
N
22
L
NOV
B
11
P
23
M
DEC
C
12
R
24
Part Marking:
PLE
PE76D
FF.FFF
M
C
YMDXX
or
PE76DX
FF.FFF
M
PLE XX
C
YYWWXX
www.pletronics.com
425-776-1880
2
PE76D Series 3.3 V
PECL Clock Oscillators
January 2008
Electrical Specification for 3.30V _10% over the specified temperature range
+
Item
Frequency Range
Frequency Accuracy
“45"
“44"
“20"
Output Waveform
Output High Level (0
o
C to 85
o
C)
2.275
0.975
Output High Level (-40
o
C)
Min
40
-50
-25
-20
Max
250
+50
+25
+20
PECL /ECL
2.420
1.120
volts
volts
volts
volts
volts
volts
volts
volts
volts
volts
volts
volts
%
pS RMS
pS RMS
nS
mA
Kohm
volts
volts
uA
uA
nS
nS
mS
o
o
o
Unit
MHz
ppm
Condition
Consult factory for higher frequency
For all supply voltages, load changes, aging for 1
year, shock, vibration and temperatures
Referenced to Ground, V
CC
= 3.3 V
Referenced to termination voltage, V
CC
= 3.3 V
Referenced to Vcc, V
CC
= 3.3 V
Referenced to Ground, V
CC
= 3.3 V
Referenced to termination voltage, V
CC
= 3.3 V
Referenced to Vcc, V
CC
= 3.3 V
Referenced to Ground, V
CC
= 3.3 V
Referenced to termination voltage, V
CC
= 3.3 V
Referenced to Vcc, V
CC
= 3.3 V
Referenced to Ground, V
CC
= 3.3 V
Referenced to termination voltage, V
CC
= 3.3 V
Referenced to Vcc, V
CC
= 3.3 V
at 50% point of V
CC
(See load circuit)
-1.025 -0.880
2.216
0.916
-1.084
Output Low Level (0
o
C to 85
o
C)
1.490
0.190
Output Low Level (-40
o
C)
2.420
1.120
-0.88
1.680
0.380
-1.810 -1.620
1.470
0.170
1.745
0.445
-1.830 -1.555
Output Symmetry
Jitter
45
-
-
Output T
RISE
and T
FALL
V
CC
Supply Current (I
CC
)
Enable/Disable Internal Pull-up
V disable
V enable
Output leakage
V
OUT
= V
CC
V
OUT
= 0V
Enable time
Disable time
Start up time
Operating Temperature Range
-
-
50
-
2.40
-10
-10
-
-
-
-10
- 40
Storage Temperature Range
Standby Current I
CC
-55
-
55
0.13
2.8
1
90
-
0.6
-
+10
+10
10
10
10
+70
+85
+125
3
12 KHz to 20 MHz from the output frequency
10 Hz to 1 MHz from the output frequency
Vth is 10% and 90% of waveform
to V
CC
Referenced to pad 3
Referenced to pad 3
Pad 1 low, device disabled
Time for output to reach a logic state
Time for output to reach a high Z state
Time for output to reach specified frequency
Standard Temperature Range
Extended Temperature Range
“E” Option
C
C
C
uA
Pad 1 low, device disabled
Specifications with Pad 1 E/D open circuit
www.pletronics.com
425-776-1880
3
PE76D Series 3.3 V
PECL Clock Oscillators
January 2008
Typical Phase-Noise Response
0
-20
-40
dBc/Hz
-60
-80
-100
-120
-140
-160
10
1,000
100,000
10,000,000
Frequency (Hz)
Load Circuit
Test Waveform
Symmetry
Vhigh
80%
50%
20%
Vlow
Trise
Tfall
Out
Out*
Showing Out Measurement only
www.pletronics.com
425-776-1880
4
PE76D Series 3.3 V
PECL Clock Oscillators
January 2008
Reliability
: Environmental Compliance
Parameter
Mechanical Shock
Vibration
Solderability
Thermal Shock
Condition
MIL-STD-883 Method 2002, Condition B
MIL-STD-883 Method 2007, Condition A
MIL-STD-883 Method 2003
MIL-STD-883 Method 1011, Condition A
ESD Rating
Model
Human Body Model
Charged Device Model
Minimum Voltage
1500
1000
Conditions
MIL-STD-883 Method 3115
JESD 22-C101
Package Labeling
Label is 1" x 2.6" (25.4mm x 66.7mm)
Font is Courier New
Bar code is 39-Full ASCII
Label is 1" x 2.6" (25.4mm x 66.7mm)
Font is Arial
Layout and application information
Recommend connecting Pad 1 and Pad 2 together to permit the design to accept both Enable/Disable
input pad versions to be used (See PE78D for E/D on pad 2)
For Optimum Jitter Performance, Pletronics recommends:
•
a ground plane under the device
•
no large transient signals (both current and voltage) should be routed under the device
•
do not layout near a large magnetic field such as a high frequency switching power supply
•
do not place near piezoelectric buzzers or mechanical fans.
www.pletronics.com
425-776-1880
5
