PFM500V-NS
SURFACE MOUNT SMALL SIGNAL TYPE
SOD-323S
0.106(2.70)
0.091(2.30)
0.008(0.20)Typ.
0.014(0.35)
0.010(0.25)
0.083(2.10)
0.067(1.70)
0.057(1.45)
0.041(1.05)
0.005(0.12)
0.003(0.08)
0.031(0.80)
0.024(0.60)
Dimensions in inches and (millimeters)
FEATURES
Extremely thin package
Low stored charge
Majority carrier conduction
MECHANICAL DATA
Case JEDEC SOD-323S molded plastic
Terminals Solder plated, solderable per
MIL-STD-750, Method 2026
Polarity Indicated by cathode band
Mounting Position Any
Weight 0.0001482 ounce, 0.0042gram
MAXIMUM RATING
(at T
A
=25 C unless otherwise noted)
o
PARAMETER
Rectified peak reverse voltage
Continuous reverse voltage
Mean rectified current
Forward surge current
Capacitance between terminals
Storage temperature
Operating temperature
CONDITIONS
SYMBOL
V
RM
V
R
I
O
Min.
Typ.
Max.
UNITS
V
V
40
40
100
1000
20
-40
-40
+125
+125
mA
mA
pF
0
8.3ms Single Half Sine-Wave Superimposed
on Rated Load (JEDEC Method)
F=1MHz and applied 4vDC reverse voltage
I
FSM
C
T
T
J
T
STG
C
C
0
ELECTRICAL CHARACTERISTICS
(at T
A
=25 C unless otherwise noted)
o
PARAMETER
Forward voltage
Reverse current
I
F
= 10mADC
V
R
= 10V
CONDITIONS
SYMBOL
V
F
I
R
Min.
Typ.
Max.
UNITS
V
A
0.45
1.0
www.paceleader.tw
1
