SMT POWER INDUCTORS
Flat Coils - PG0155NL Series
All Inductors are RoHS Compliant
Height:
3.7mm Max
Footprint:
11.0mm x 10.4mm Max
Current Rating:
up to 24A
Inductance Range:
0.30µH to 0.91µH
High temperature core material, no thermal aging below 150°C
Electrical Specifications @ 25°C — Operating Temperature -40°C to +130°C
1
Part
Number
PG0155.331NL
PG0155.601NL
PG0155.102NL
Inductance
@Irated
2
(μH TYP)
0.30
0.53
0.91
Irated
3
(A)
24
19
14
DCR
(m
Ω)
TYP
1.7
2.8
5.3
MAX
2.2
3.2
5.8
Inductance
@0A
D C
(μH ±20%)
0.33
0.60
1.0
Saturation
4
Current
I
S A T
(A)
38
27
21.5
Heating
5
Current I
D C
(A)
24
19
14
Core Loss
6
Factor
(K2)
81.36
108.47
142.73
Mechanical
.433 MAX
11,00
H
Schematic
.410
10,40
MAX
PG0155.XXXNL
Date Code
Country of Origin
1
2
.228
± .005
5,80
± 0.12
Part No.
PG0155.331NL
PG0155.601NL
PG0155.102NL
Max. Height
“H” (in./mm)
.146/3,7
.146/3,7
.142/3,6
Weight
. . . . . . . . . . .1.6 grams
Tape & Reel
. . . . . . . .850/reel
Dimensions:
Inches
mm
Unless otherwise specified,
all tolerances are ± .010
0,25
2x .118
± .005
3,00
± 0.12
.276
± .005
7,00
± 0.12
SUGGESTED PAD LAYOUT
.014
± .002
0,35
± 0,05
.079
2,00
.157
4,00
.069
1,75
.453
11,50 .945
± .012
24,00
± 0,30
.158
4,00
TAPE & REEL LAYOUT
.630
16,00
USER DIRECTION OF FEED
USA 858 674 8100
•
Germany 49 7032 7806 0
•
Singapore 65 6287 8998
•
Shanghai
86 21 54643211 / 2
•
China 86 755 33966678
•
Taiwan 886 3 4641811
www.pulseeng.com
P613.C (10/07)
SMT POWER INDUCTORS
Flat Coils - PG0155NL Series
Notes from Tables
1. The temperature of the component (ambient plus temperature
rise) must be within the standard operating temperature range.
2. Inductance at Irated is a typical inductance value for the
component taken at rated current.
3. The rated current listed is the lower of the saturation current
@ 25°C or the heating current.
4. The saturation current, Isat, is the current at which the
component inductance drops by 20% (typical) at an ambient
temperature of 25°C. This current is determined by placing the
component in the specified ambient environment and applying a
short duration pulse current (to eliminate self-heating effects) to
the component.
5. The heating current, I
DC
, is the DC current required to raise the
component temperature by approximately 40°C. The heating
current is determined by mounting the component on a typical
PCB and applying current for 30 minutes. The temperature is
measured by placing the thermocouple on top of the unit under
test. Take note that the component’s performance varies depend-
ing on the system condition. It is suggested that the component
be tested at the system level, to verify the temperature rise of the
component during system operation.
6. Core loss approximation is based on published core data:
Core Loss
= K1 * (f)
1.30
* (K2ΔI)
2.41
Where: Core Loss
= in Watts
K1
= 1.20E-10
f
= switching frequency in kHz
K1 & K2
= core loss factors
Δ
I
= delta I across the component in Ampere
Δ
K2ΔI
= one half of the peak to peak flux density
across the component in Gauss
7. Unless otherwise specified, all testing is made at 100kHz, 0.1V
AC
.
8. Add suffix
"T"
to the part number for Tape & Reel packaging
(ex: PG0155.331NLT).
Inductance vs Current Characteristics
1.5
INDUCTANCE(µH)
1.0
PG0155.102NL
0.5
PG0155.601NL
PG0155.331NL
11
13
15
17
19
21
23
25
27
29
31
33
35
37
39
41
43
45
47
49
51
53
CURRENT(A)
Typical Core Loss vs Peak Flux Density
1.80
1.60
400
kHz
300
kHz
200
kHz
1.40
1.20
1.00
0.80
0.60
0.40
0.20
0.00
100
200
300
400
500
600
700
800
900
1000
1.0
MHz
CoreLoss (W)
500
kHz
100
kHz
DB
(Gauss) where
DB
= K2DI
For More Information:
Pulse Worldwide
Headquarters
12220 World Trade Dr.
San Diego, CA 92128
U.S.A.
www.pulseeng.com
Tel: 858 674 8100
Fax: 858 674 8262
Pulse
Europe
Einsteinstrasse 1
D-71083 Herrenberg
Germany
Pulse China Headquarters
B402, Shenzhen
Tech-Innovation International
Tenth Kejinan Rd.
High-Tech Industrial Park
Nanshan District, Shenzhen
China
Tel: 86 755 33966678
Fax: 86 755 33966700
Pulse North China
Room 1503
XinYin Building
No. 888 YiShan Rd.
Shanghai 200233
China
Tel: 86 21 54643211/2
Fax: 86 21 54643210
55
1
3
5
7
9
0.0
Pulse South Asia
150 Kampong Ampat
#07-01/02
KA Centre
Singapore 368324
Pulse North Asia
No. 26
Kao Ching Rd.
Yang Mei Chen
Tao Yuan Hsien
Taiwan, R. O. C.
Tel: 886 3 4641811
Fax: 886 3 4641911
Tel: 49 7032 7806 0
Fax: 49 7032 7806 12
Tel: 65 6287 8998
Fax: 65 6280 0080
Performance warranty of products offered on this data sheet is limited to the parameters specified. Data is subject to change without notice. Other brand and product
names mentioned herein may be trademarks or registered trademarks of their respective owners. © Copyright, 2007. Pulse Engineering, Inc. All rights reserved.
www.pulseeng.com
P613.C (10/07)
